WhiteLabel BSH557 Manual

Bluetooth stereo headset
Hide thumbs

Advertisement

Quick Links

Download this manual
Bluetooth stereo
headset
Model Name: BSH557
FCC ID: ZG8BSH557

Advertisement

loading
Need help?

Need help?

Do you have a question about the BSH557 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for WhiteLabel BSH557

Summary of Contents for WhiteLabel BSH557

  • Page 1 Bluetooth stereo headset Model Name: BSH557 FCC ID: ZG8BSH557...
  • Page 2 CONTENTS USB to Micro USB WhiteLabel BSH557 Audio Cable Bluetooth Headset Data Cable...

  • Page 3: Product Features

    PRODUCT FEATURES 3. USB charging Port 8. ANC (Active Noise Cancellation) 4. 3.5mm Audio Input Switch 5. Volume + 9. Folding Hinges 1. Power Switch 6. Volume - 10.LED Indicator 2. Pair Button 7. Mic 11.Multi-Function...
  • Page 4 TURN ON THE HEADPHONES To turn on the Headphones ON simply slide the Power Switch to the down position. The LED Indicator will flash BLUE times, and you’ll hear a tone through the Headphones. To turn on the Headphones ON simply slide the Power Switch to the down position. The LED Indicator will flash RED times, and you’ll hear a tone through the Headphones.

  • Page 5: Connecting With Bluetooth

    The Headphones are ready to connect to the device. 3. Go to the Bluetooth option in the settings of your Bluetooth Audio device or Smartphone and in the list of Devices select BSH557 4. The Headphones are now ready to use Connecting with Audio Cable To connect the Headphones to devices that do not support Bluetooth.
  • Page 6 CONNECTING WITH BLUETOOTH device. Note: The audio cable will allow you to listen to music even if the Headphone Battery is out of power. Also allows you to use the Headphones in places where wireless signals are restricted such as Hospitals and Aircraft.
  • Page 7 DESCRIPTION OF HEADPHONE FUNCTIONS Adjust volume Press the volume +/- key to adjust the volume. One short press will adjust one level. When the volume reaches max or minimum volume the Headphones will play a chime. Play/Pause music Press Multifunction Button one time to Play or Pause music. Previous/Next song When playing music you can press “forward”...
  • Page 8 DESCRIPTION OF HEADPHONE FUNCTIONS Active Noise Cancellation To enable the Active Noise Cancellation feature slide the ANC switch to the down position. The LED indicator will illuminate to show the ANC is active. Active Noise Cancellation is a feature that reduces the background noise and is suitable for listening to music in noisy environments such as Train, Aircraft or walking in the street.
  • Page 9 DESCRIPTION OF HEADPHONE FUNCTIONS Receive a Phone Call If you are listening to music when there is incoming Phone call or you are making a Phone call, the Headphones will automatically switch the connection from the music player to the Phone. The Music will be paused temporarily.
  • Page 10 DESCRIPTION OF HEADPHONE FUNCTIONS Voice dialing (dialing a number by saying a name) It is possible to make a call directly from the Headphones using voice recognition. To use this voice dialing function, your Phone must provide this option. 1.Enable voice recognition function of your Phone and set the Phone to hands free mode. 2.Double press the Multifunction Button of the Headphones, you will hear a tone.
  • Page 11 DESCRIPTION OF HEADPHONE FUNCTIONS Refuse a call When there is incoming call, press and hold Multifunction Button for about 2 seconds until you hear prompt from the Headphones. Release the Button and the call is refused. Redial the last Number Press and hold volume + Button for 2 second to redial the last dialed number.
  • Page 12 DESCRIPTION OF HEADPHONE FUNCTIONS Switch Phone call between Phone and Headphones In call state press and hold Multifunction Button for 2 seconds until there is prompt from the Headphones. The call will be switched from Headphones to Phone or vice versa. Charging the Headphones To charge the Headphone use the supplied USB cable and insert into any powered USB Port normal charging process takes abort 2-3 hours.
  • Page 13 DESCRIPTION OF HEADPHONE FUNCTIONS charged and fully released at the beginning three times of use to ensure the battery the best performance. After charging is complete please remove the cable from the Headphones and the USB Cable from the USB port. Do not keep the Headphones connected to the USB port for a long time when charging complete as this will shorten the lifetime of the Battery.
  • Page 14 CAUTION • Avoid placing this product near extreme temperatures or humidity. • Do not use this product while operating a motor vehicle • Do not submerse or allow this product to come into contact with water. Use in dry locations only.
  • Page 15 CONTACT US Irvine Mobility,Inc. IRVINE MOBILITY 2013. The product and packaging are www.whitelabel.co trademarks or registered trademarks of IRVINE MOBILITY, INC. in support@whitelabel.co the United States or other countries. All rights reserved. The Bluetooth word mark and logos are owned by Bluetooth SIG, Inc.
  • Page 16 Important Regulatory Information This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
