Hamilton Engineering EVO 129–599 Manual

Hamilton Engineering EVO 129–599 Manual

Fmt-914 control configurations

Advertisement

FMT-914 Control Configurations
WARNING
If the information in this manual
is not followed exactly, a fire or
explosion may result causing
property damage, personal
injury or death.
ANSI STD Z21-13/Z21.13A
Certified to CSA 4.9-2004
ANSI STD Z21.10.3/Z21.10.3.b
Certified to CSA 4.1-2004, add.A,B
These appliances MUST be installed by a properly licensed individual in the City and State which the
unit is being installed. All start up adjustments and subsequent service work must be done by a similarly
licensed contractor or a factory trained service individual. Failure to comply could result in loss of
warranty and or severe personal injury, death and or substantial property damage. These instructions
are required to be kept with the appliance on the left side, in the pocket provided.
34000 Autry Street, Livonia, MI 48150 | 800.968.5530 | Fax 734.419.0209 | www.hamiltonengineering.com | LIT91110 REV 06/2018
Hamilton Engineering
EVO 129 –599
ANSI Z21.13-2014/CSA 4.9-2014
UL 795-2011/CSA 3.4
SCAQMD 1146.2
New York
Massachusetts
MEA 425-05-E
Boilers: G1-06-06-24A
Heaters: G1-06-06-24B
WARNING
Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance
• Do not touch any electrical switch
• Do not use any phone in your building
Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier
instructions. If you can not reach your gas
supplier, call the fire department.
SCAQMD
Compliant Rule1146.2
CEC Listed
California Energy Commission

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EVO 129–599 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hamilton Engineering EVO 129–599

  • Page 1 Hamilton Engineering EVO 129 –599 FMT-914 Control Configurations Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. WARNING WHAT TO DO IF YOU SMELL GAS: If the information in this manual •...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS TABLE OF CONTENTS GENERAL DESCRIPTION CONFIGURATION #9 Components & Operations Central Heating w/3-way Valve DHW Multiple Boiler Cascade™ CONFIGURATION #1 WIRING DIAGRAM Domestic Hot Water Single Heater HWD 129-199.8 Standard Wiring CONFIGURATION #2 WIRING DIAGRAM Domestic Hot Water Multiple Heater Cascade™...
  • Page 3: General Description

    GENERAL DESCRIPTION PRIMARY APPLIANCE CONTROL – is done utilizing the FMT 914 PCB as custom manufactured by SIT Controls of the Netherlands for Hamilton Engineering, Inc. POWER SUPPLY In all scenarios shown below, 208 – 240 volt single phase power is connected to leads labeled Power L, Power L and Ground.
  • Page 4 GENERAL DESCRIPTION The following pages contain drawings that apply to all models of EVO products: That are represented by: In addition, most drawings reference a Low Loss Header, which may also be replaced by properly implemented Primary-Secondary Piping: From Zones Boilers From Boilers...
  • Page 5: Configuration #1

    CONFIGURATION #1 Configuration #1 – DOMESTIC WATER HEATING (DHW) – model prefix HWD STAND ALONE WATER HEATER • If an external temperature sensor (10k ohm thermistor) is connected to terminals 1 & 2 (or 3 & 4, 28 & 29 depending on model), the heater will be automatically controlled by this sensor.
  • Page 6: Configuration #2

    CONFIGURATION #2 Configuration #2 – CASCADE WATER HEATERS • In this configuration, an external sensor on terminals 1 & 2 (or 3 & 4, 28 & 29 depending on model) or an aquastat on terminals 5 & 6 (or 13 & 14, 57 & 58 depending on model) MUST be connected to the LEAD HEATER ONLY. In this configuration the following can be done on the LEAD HEATER ONLY: 1. Adjust the heater minimum and maximum temperature setting via the red wheel located on the display panel, within the range of 50 –...
  • Page 7: Central Heating

    CENTRAL HEATING CENTRAL HEATING (CH) – Model prefix HWH In these configurations the room thermostat reference can be a: On/off—Thermostat is connected and the input is closed. The flow setpoint temperature is determined by a heat curve. The heat curve determines the flow setpoint temperature by using the temperature of S6 (outside)(terminals 1 & 2 or 9 & 10, 26 & 27 depending on model). When no outside sensor is connected (automatically detected), the flow setpoint temperature is determined by the red wheel setting. *Power being switched is 30 VDC. Connection is made at terminals 5 & 6 (or 13 & 14, 57 & 58 depending on model) (X1–9,18). Note: if this circuit is not opened pump P3 will run all of the time except during a call for DHW.
  • Page 8: Configuration #3

    CONFIGURATION #3 Configuration #3 – STAND ALONE BOILER (NO DOMESTIC HOT WATER) • A room thermostat is to be connected to terminals 5 & 6 (or 13 & 14, 57 & 58 depending on model). If no yellow jumper wire is attached to 5 & 6 (or 13 & 14, 57 & 58 depending on model), which will be removed to connect room thermostat, additional wiring is required.
  • Page 9: Configuration #4

    CONFIGURATION #4 Configuration #4 – CASCADE BOILERS (NO DOMESTIC HOT WATER) • In this configuration an external sensor MUST be connected to terminals 1 & 2 (or 3 & 4, 28 & 29 depending on model) on the LEAD BOILER ONLY and be positioned to sense common loop temperature (after/at low loss header). • A room thermostat is to be connected to terminals 5 & 6 (or 13 & 14, 57 & 58 depending on model) of the LEAD BOILER ONLY.
  • Page 10: Configuration #5

    CONFIGURATION #5 Configuration #5 – STAND ALONE RESIDENTIAL BOILER WITH DOMESTIC HOT WATER PUMP (Model number will always end in 9.8, ex. HWH 129.8) • A room thermostat is to be connected to terminals 5 & 6 (or 13 & 14, 57 & 58 depending on model). If no yellow jumper wire is attached to 5 &...
  • Page 11: Configuration #6

    CONFIGURATION #6 Configuration #6 – STAND ALONE BOILER WITH DOMESTIC HOT WATER PUMP (Requires additional heating wiring harness – p/n WRE 74090) • A room thermostat is to be connected to terminals 5 & 6 (or 13 & 14, 57 & 58 depending on model). If no yellow jumper wire is attached to 5 &...
  • Page 12: Configuration #7

    CONFIGURATION #7 Configuration #7 – CASCADE BOILERS WITH DOMESTIC HOT WATER PUMP (Requires additional wiring harness – p/n WRE 74090 on the Lead boiler only) • A room thermostat is to be connected to terminals 5 & 6 (or 13 & 14, 57 & 58 depending on model) of the LEAD BOILER ONLY.
  • Page 13: Configuration #8

    CONFIGURATION #8 Configuration #8 - STAND ALONE BOILER WITH DOMESTIC HOT WATER DIVERTING VALVE (Requires additional heating wiring harness – p/n WRE 74090) • A room thermostat is to be connected to terminals 5 & 6 (or 13 & 14, 57 & 58 depending on model). If no yellow jumper wire is attached to terminals 5 &...
  • Page 14: Configuration #9

    CONFIGURATION #9 Configuration #9 - CASCADE BOILERS WITH DOMESTIC HOT WATER DIVERTING VALVE (Must add heating harness WRE74090 to the Lead Boiler only) • A room thermostat is to be connected to terminals 5 & 6 (or 13 & 14, 57 & 58 depending on model) of the LEAD BOILER ONLY.
  • Page 15: Hwd 129-199.8

    HWD 129–199.8 STANDARD WIRING 34000 Autry Street, Livonia, MI 48150 | 800.968.5530 | Fax 734.419.0209 | www.hamiltonengineering.com | LIT91110 REV 06/2018...
  • Page 16: Hwh 129-199.8

    HWH 129–199.8 W/O 3-WAY Pump P-2 240v switched DHW Indirect to Pump High Temp. Pump P2 L Pump P2 L 240v 3-way Close switched K6 K2 K7 to Pump 3-way Open to CH CONTROL K6 K2 Pump P-3 WELL Central Heat 3-way L Pump P3 L Low Temp.
  • Page 17 HWH 129–199.8 W/3-WAY 34000 Autry Street, Livonia, MI 48150 | 800.968.5530 | Fax 734.419.0209 | www.hamiltonengineering.com | LIT91110 REV 06/2018...
  • Page 18 HWD 199-599 STANDARD WIRING Heater Pump Outlet sensor Model 599 only Inlet sensor Pump L Gas valve-1 Gas valve-2 Pump G Pump L fan-1 fan-2 K2 K6 Fixed High Limit Open switch indicates H-1 Pump L Pump G Printed Circuit Board FMT914 Pump L Pressure Switch Fuse...
  • Page 19: Hwh 199-599

    HWH 199-599 W/O 3-WAY 240v switched DHW Indirect Pump to Pump High Temp Pump P2 L CONTROL WELL Pump P2 L 240v Tank Sensor 3-way Close Outlet sensor switched to Pump 3-way Open to CH Inlet sensor Heating Pump 3-way L Pump P3 L Low Temp Boiler Pump...
  • Page 20 HWH 199-599 W/3-WAY 24V Transformer Open CONTROL WELL Close 240v Tank Sensor Outlet sensor switched 3-way Close to Pump 3-way Open to CH Inlet sensor Heating Pump 3-way L Pump P3 L Low Temp Boiler Pump Model 599 only Pump P3 L Gas valve-1 Gas valve-2 Pump P1 L...
  • Page 21 HWH 79-599 UNIVERSAL Gas Valve-1 Gas Valve-2 BURNER Molex2020 AMP universal flow sensor MALE N LOK 350766-1 pwm/hall power supply signal Molex2020 fan-1 fan-2 return sensor Fuse 3.15A supply L1 supply L2 X 10 Main switch Transformer Pump-1 Pump-1 Pump-2/comm. open High limit thermostat...
