Status Pro R280 Instruction Manual

Bluetooth laser receiver
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
R28
Bluetooth Laser Receiver
Instruction Manual
Another fine solution by

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R280 and is the answer not in the manual?

Questions and answers

Summary of Contents for Status Pro R280

  • Page 1 Bluetooth Laser Receiver Instruction Manual Another fine solution by...
  • Page 2 (BG 831500) Software version V 1.00 We would like to congratulate you on the purchase of your Status Pro R310 Laser receiver. Before initial usage you should carefully read the safety instructions as well as the user guidelines contained in this manual. We wish you every success when using this Measurement Instrument.

  • Page 3: Table Of Contents

    3.3 R280 Monitor Control Software ........

  • Page 4: S Fety Instructions

    This can damage the structure or the optics of the instrument resulting in false measurements. Do not touch rotating parts when in use! 1.2 Standards ll Status Pro Laser and Receiver Instruments are developed and manufactured according to the following CE Standards: • EN 55 011 •...

  • Page 5: Instrument Care

    1.5 Maintenance The mechanical components of your equipment are prone to natural wear and tear! If the Instrument appears to have a technical defect, contact the Manufacturer. Do not try to Status – R280 Instruction Manual...

  • Page 6: Calibration And Repair

    The date of the next service check for your equipment is stamped on the Status Pro calibration sticker. To ensure trouble-free processing of the service and calibration checks, simply fill in the form you will find using the following link www.statuspro.com/machine_geometry/service_support/calibration_repair.

  • Page 7: Getting St Rted

    GETTING STARTED 2. Getting started 2.1 Power Supply The R280 can only be powered using a Type BT 800071 re-chargeable cell. completely charged cell will provide enough energy for around 8 hours usage. discharged cell can be recharged in approximately 1,5 hours using the external charger (BT 800072) . Constant operation is possible if a second cell is available (optional extra).

  • Page 8: Ssembly

    Remove cell before prolonged storage (Danger of corrosion) 2.2 Assembly The R280 Laser receiver has two M8 threads (V) on the underside and two on the top side. The threads enable correct fitting of the Magnet dapter Typ BG 831510, usually used when measuring objects.
  • Page 9 To rotate the R280 in the laser axis when using the BG 831550 (X) dapter, simply loosen the knurled screw (XIII), rotate as wished and then re-tighten the knurled screw.

  • Page 10: H Ndling

    Measurement triggering button Detection area To turn on the R280 simply press the On/Off button, to turn Off press and hold for 1 second or longer. The rotating beam of the laser sweeps across the detector area(E) and a value is delivered to the Display Unit over BlueTooth.

  • Page 11: Led Signals From The R280

    Battery condition LED fter turning on the sensor (Button ) this LED signifies the condition of the Battery Pack and measurement availability of the R280: Constant green: Power good – Constant use possible Flashing green with 1Hz (once per second): ca. 30 minutes of battery power remaining –...

  • Page 12: R280 Monitor Control Software

    If both LED s are lit constantly, the beam is exactly at Zero (0,00) 3.3 R280 Monitor – Control Software The R280 can be remotely controlled using the Status Pro Software. The Software offers the following possibilities: The User Panel can be started by pressing the Button in the Toolbox: IR –...

  • Page 13: Me Surements

    Start the Software Monitor and press the button. Press the button in the Monitor. Position the R280 Receiver as far away as possible from the Laser in the same Laser axis, (POS 2) then turn the IR mirror on the laser towards the R280. Manual: Navigate the laser plane towards 0,00 in the Monitor using the arrow buttons on the Laser panel or use the Remote Control RC310.

  • Page 14: Checking And Calibrating The T330 Self-Levelling Function

    To achieve this, start the R280 „Remote Control“ using your software. T330: Calibration check Place the T330 and R280 on an appropriate surface and turn them on (Distance between instruments ca. 5-10 m). ctivate the self-levelling function on the T330. (Sensor reading, eg.: 2,14) „Zero“...
  • Page 15 Status Pro personnel (R&K). Be sure to attend the appropriate training courses at Status Pro or by arrangement in your company. This ensures best possible handling and usage of your equipment and of your...

  • Page 16: Technic L D T

    Meas. Distance: Up to 50 m Protection Class: IP 54 Weight: 298 g (without Battery) Weight: 343 g (with Battery) Housing: luminium, anodised Dimensions (b x h x d): 58 x 100 x 38 mm Status – R280 Instruction Manual...
  • Page 17 TECHNICAL DATA 2 x M5 8 deep 2 x M5 8 deep middle of sensor Status – R280 Instruction Manual...

  • Page 18: Ccessories

    Power cell for the R280. fully charged cell offers around 8 hours of operation. External charger (BT 800072) Charger (BT 800071) for the R280. The Battery Pack will be fully charged in around 1,5 hours. Magnet dapter (BG 831510) The standard adapter for the R280.
  • Page 19 600N. 40 x 40 x 40mm. Fitting for dapter (BG 831550) This adapter enables use of the R280 with all fittings for the R310 Sensor enabling a greater range of moun- ting possibilities. Fit dapter to the Screw dapter (BT 948336) and tighten using knurled screw.
  • Page 20 Software from Status Pro Status Pro software has been developed specially for use with Status Pro Instruments. The sensors connect automatically with the PC and deliver secure and stable measuring. The software offers comfortable documenting and exporting of the taken measurements.
  • Page 21 “hot swap” feature and communication over Bluetooth. lignment Packages SP ProFlange 10 SP ProFlange 20 SP ProFlange 30 Starter Package for Starter Package with Professional Package Flange Flatness IT for Flange with IT for Flange Flatness Flatness and Parallelism Status – R280 Instruction Manual...

  • Page 22: Products Nd Service

    The use of a laser beam reference together with tradition industrial measurement techniques has made it possible to build tools which simplify these alignment procedures. Status Pro develops and manufactures laser alignment equipment and we are committed to this process. Most of our customers are machine builders, assembly and quality con- trol people.

  • Page 23: Memo

    MEMO 8. Memo Status – R280 Instruction Manual...
  • Page 24 B 1037D 08/11 · Design / DTP: Seichter & Steffens Grafikdesign, D-44229 Dortmund Copyright 2011 Status Pro Maschinenmesstechnik GmbH. This brochure or parts thereof may not be copied or reproduced in any other way without prior approval by Status Pro GmbH. Technical correctness and completeness remain reserved and may be subject to changes without prior information.
