Sengye 98801 User Manual

Model：98801(RX), YKQ05(TX)

1) Profile

12V(TX) by battery
1.1、Input：DC
1.2、The receiver is a UL listed product with grounded outlet
1.3、The Transmitter is a light sensor.
2) Description：
2.1、 Install the receiver to outlet. And connect the controlled device to the outlet of the receiver.
2.2、 Put the light sensor to proper place which can receives the light change of sun or other
light source.
1、 Install a 23A battery into light sensor. The led will flash once and send out an off signal.。
set AUTO position，the CDS will detect the environment light. If the lux of the light is less than
15lux, it will send out an ON signal. Receiver will turn on after receiving the ON signal from
light sensor. If the environment lux level is bigger than 60lux, the sensor will send out an off
signal to turn off the receiver.。
2、2 hours position: The light sensor resets first and send out an OFF signal to turn off
receiver. If the environment lux level is less than 15lux, the Sensor will send out a signal to turn
on the receiver. After 2 hours, it will send out a signal to turn off the receiver. Then the sensor will
continue to monitor the lux level of environment. If the lux level is bigger than 60 lux, the sensor
is ready to repeat next ON/OFF activity
3、5 hours position: The light sensor resets first and send out an OFF signal to turn off
receiver. If the environment lux level is less than 15lux, the Sensor will send out a signal to turn
on the receiver. After 5 hours, it will send out a signal to turn off the receiver. Then the sensor will
continue to monitor the lux level of environment. If the lux level is bigger than 60 lux, the sensor
is ready to repeat next ON/OFF activity
Manual
98801 RF Receiver YKQ05 TX
