- Page 1 Multifunctional Portable Video Magnifier Aumax-S User Manual...
-
Page 2: Table Of Contents
3) Aumax-S Connection Mode ................9 4) Aumax-S Placement ................... 9 5) Aumax-S Using Mode ..................10 6) Aumax-S Camera Rotation Angle ..............11 7) Software Installation ..................11 8) Computer Keyboard Shortcuts Operation and File Save ....... 14 5. How to Use ....................17 1) Power On/Off ..................... -
Page 3: Introduction
Please read the safety tips below carefully: Before initial use: Please inspect the unit for any damage after you open the package of Aumax-S. If there is any problem, please contact the local agent or distributor. Do not attempt to repair the product yourself;... - Page 4 Attentions: Please ensure the product is placed on a stable surface to prevent it from falling off and damaging the unit or causing injury to the user. Please keep it dry. Keep it away from moisture, rain, dust, and high temperatures. Do not put the product beside flammable fluid.
-
Page 5: Components
3. Components 1) Overall Appearance 1. Arm 2. Arm rotating shaft 3. Direct Control area 4. USB computer interface 5. Power interface 6. Control pad interface 7. Camera 8. Close-up lens 9. Camera rotating shaft 10. LED lamp 11. Body 12. -
Page 6: Standard Fittings
1280 * 960 pixels is the best. Any standard LCD monitor on the market should work fine for use with the unit. b) USB connection: System requirements for the operation of Aumax-S software: Windows 2000 (Service Pack 4), Windows XP (Service Pack 2 or higher), Windows Vista 32bit or 64bit, and Windows 7 32bit or 64bit. -
Page 7: Installation And Preparation
Display card: Support DirectX 9.0 and higher versions Hard Disk: Installation requires at least 50 MB space available Note: When using Aumax-S with some screen magnifying software on a computer of low hardware configuration, the computer system may run out of resources and cause the image unsmooth. -
Page 8: Folding Aumax-S
Unfold the arm at a 90° angle from the machine body, as shown in the picture below: 2) Folding Aumax-S a) Fold the main body: First, press the side button and hold. Then fold the arm downward, as shown in the picture below: b) Put away the support leg: Fold the support leg downward. -
Page 9: Aumax-S Connection Mode
3) Aumax-S Connection Mode Aumax-S has two connection modes: One is to connect with the display and the other is to connect with the computer. This is shown in the picture below: 4) Aumax-S Placement Aumax-S can be placed in three different placement positions: a. -
Page 10: Aumax-S Using Mode
Left side b. Centered c. Right side 5) Aumax-S Using Mode Aumax-S has three using modes: a. Distance Viewing b. Reading and Writing c. Self Viewing The using modes can be changed by rotating the camera. a. Distance Viewing b. -
Page 11: Aumax-S Camera Rotation Angle
The following installation steps are described using Windows XP as an example. b) Put the Aumax-S installation CD into the CD drive. Double click on the drive icon. Open the CD; Note: The installation software can also be downloaded from the website. - Page 12 You can now choose your preferred language. Aumax-S provides a total of 8 languages (Simplified Chinese, Traditional Chinese, English, French, German, Italian, Japanese, Spanish) for you to choose. You can choose from the drop-down menu. d) As shown in the picture below, click on “Next”;...
- Page 13 As shown in the picture below, there are a total of two options for you to choose. The first option allows you to create a shortcut of Aumax-S on the desktop. The second option allows you to create a shortcut of Aumax-S on the Quick Launch Bar;...
-
Page 14: Computer Keyboard Shortcuts Operation And File Save
After the software installation is finished, the shortcut icon (pictured below) will appear in the desktop or Quick Launch Bar. Click on the icon to run the Aumax-S software. 8) Computer Keyboard Shortcuts Operation and File Save a) The following are the operations that can be performed only when Aumax-S is connected to the computer. - Page 15 minimize or maximize window Mode Mode toggle Ctrl+ ← The right edge of window leftward Ctrl+ → The left edge of window rightward Ctrl +↑ The bottom edge of window upward Ctrl+↓ The top edge of window downward Shift+ ← The whole window leftward Shift+ →...
- Page 16 b) The following are image storage operations: i) <Ctrl + S> image storage function: Will save the image according to the directory selected by the user. The image storage type is bitmap. ii) <Ctrl + O> image open function: Will open the view of the image according to the file folder the user selected.
-
Page 17: How To Use
The indicator light on the “Power” button will turn on and the auxiliary illuminating LED lamp will also be on. After you are finished using AUMAX-S, press the "Power" button to shutdown. The button of the indicator light will turn off after shutdown is complete. -
Page 18: Image Freeze
a) true color b) grayscale c) black lettering on white background d) white lettering on black background e) white lettering on blue background f) yellow lettering on black background g) yellow lettering on blue background h) green lettering on black background 4) Image Freeze This function is mainly used to freeze the current image in such situations as "looking into the mirror,"... -
Page 19: Left/Right Handed Toggle
circular ring, as shown in the figure on the right. When the machine is first turned on, the camera will be in auto focus. Press the “Focus Lock” button to stop the auto focus. The words “Focus Lock” will display on the upper left corner of the screen. -
Page 20: Line Marker/Mask Adjustment
When the battery power is low, the battery symbol will flash on the display like the battery symbol shown in the figure on the right. The red indicator light will continue to flash until the battery is completely depleted and Aumax-S will shutdown. While the battery is charging,... -
Page 21: Memory Function
Q: What should be done if the brightness of the image is too bright, the contrast is too low, and the image is unclear? A: 1). Aumax-S is designed for indoor use. If you are using Aumax-S in an area where it is too bright, we suggest you to move the machine to a shaded area. -
Page 22: Specifications
A: When installing the drive, you must connect it with the computer. Please check if it is connected or contacting the computer properly. For more information, please visit website: www.aumed.cn or www.aumedgroup.com. 7. Specifications Focus: auto focus & focus lock Magnification: 2.2X-60X (15-inch, 16:9) - Page 23 8. Warranty Statement Aumed warrants the Aumax-S effectively from the date of delivery, to be free of any defects in material and workmanship. Aumed offers two-year Limited Warranty from the date of original purchase, please always keep your purchase receipt safely, and it will be needed when warranty claims.
- Page 24 This device bears the CE and FCC approval mark. 10. Contact / product support If you have questions about the operation, installation or setting of your system, please contact your Aumax-S distributor. Your Aumax-S distributor:...
