CX901
WIRELESS GSM PIR MOTION ALARM USER MANUAL
Introduction
CX901 is a portable battery operated GSM PIR motion detector alarm. When the PIR detects movement,
the unit will emit a 130 decibel siren.
SMS and dial up-to 3 preset telephone numbers.
easy installation.
What's in the box
Check and identify the contents of your package :
1 x Main unit
1 x Remote fob
2 x Fixing screws to secure rotary bracket to the wall
1 x Fixing screw to secure rotary bracket to battery back cover
User manual
Note: The screws will be found in a plastic bag in the battery compartment "M".
Product Image
If a GSM SIM card (not included) is installed, CX901 will send a
Either wall mounting or free standing is available for
1
PIR unit
Remote fob
Advertisement
Table of Contents
Summary of Contents for Beyond CX901
- Page 1 WIRELESS GSM PIR MOTION ALARM USER MANUAL Introduction CX901 is a portable battery operated GSM PIR motion detector alarm. When the PIR detects movement, the unit will emit a 130 decibel siren. If a GSM SIM card (not included) is installed, CX901 will send a SMS and dial up-to 3 preset telephone numbers.
- Page 2 Operation Battery & GSM SIM Card installation Open the battery cover by removing the two screws on the reverse of the unit. Insert 3 x AA Alkaline batteries (not included) as below diagram M . Once the last battery is installed, a beep will be sounded as an indication that the batteries are installed correctly.
- Page 3 Programming the phone numbers To programme a set of telephone numbers under the disarm mode, assuming the phone number is “123456789” as an example: Press * * to store the 1 telephone number ; Press * to store the 2 telephone number ;...
- Page 4 Pairing with other devices CX901 (the wireless GSM PIR motion alarm) is a master unit. It can be paired with different slave units such as PIR video camera, PIR motion sensor alarm, door and window sensor alarm, mini siren box etc.
