- Page 1 REVOLUTION DCC SYSTEM INSTALLATION AND OPERATION MANUAL TENTATIVE DCC 5A Command / Booster Station /Mobile Receiver #59002 Revolution DCC Transmitter 'TX' #59001 15 AMP Station Command/Booster RX #59005 2.4GHz DCC R/C System <TENTATIVE>...
-
Page 2: Operation Overview
There are two primary modes of programming: programming Track (service mode) and Main(Power On Main) programming mode. The programming track mode requires a programming track which is isolated electrically. Refer to the wiring diagram in FIG-1 and FIG-3. 2.4GHz DCC R/C System <TENTATIVE>... - Page 3 DCC Command Station-Booster RX for N, HO,O, S, G scale track or mobile setup. Works with any NMRA-DCC multi-function / accessory / sound decoders. Wide input voltage up to 24V DC. Maintains 2500 locomotives and 2500 accessories. Programmable output current and power limit. Wireless firmware upgrade-able. 2.4GHz DCC R/C System <TENTATIVE>...
-
Page 4: Diagram For Battery Installation Set Up
DIAGRAM FOR RECEIVER INSTALLATION SET UP 5A DCC RX TRACK POWER MODE (FIG-1) (FIG-2) DIAGRAM FOR BATTERY INSTALLATION SET UP 2.4GHz DCC R/C System <TENTATIVE>... - Page 5 Increase Speed ▼ Decrease speed ◄ Direction change ► Direction change Asterisk Quick Program Qiuck menu (0) all stop Function Control Emergency all stop MENU Select menu 1--9 Function control ON/OFF Power ON/OFF TRANSMITTER KEYPAD LABEL 2.4GHz DCC R/C System <TENTATIVE>...
- Page 6 There are three concepts how to use the Revolution-DCC R/C System that need to be understand. Refer to the LCD screen menu descriptions for details. SELECT MODE BANK: 35 1) LOCO CONT/ROL 2) ACCESSORY CONTROL 3) SET UP (FIG-4) 2.4GHz DCC R/C System <TENTATIVE>...
- Page 7 For more information, see the corresponding menu description. Press the [MENU] button to return. SET UP: Various parameters can be set on the SET UP menu screen. For more information, see the corresponding menu descriptions. Press the [MENU] button to return 2.4GHz DCC R/C System <TENTATIVE>...
- Page 8 Press [STOP] button to toggle between TRACK or MAIN function. TRACK (Service mode) PROGRAMMING : Press the [STOP] button, if successfully written the data to the decoder then the LCD shows “ACK OK” (Note: The locomotive must placed on the programming track) 2.4GHz DCC R/C System <TENTATIVE>...
-
Page 9: Speed Steps
Press◄ or ► button to select the desired DCC speed step. d) RX ID NUMBER: You can select the RX ID # 1 to 10 to link the receiver. Press◄ or ► button to select the desired receiver number. 2.4GHz DCC R/C System <TENTATIVE>... - Page 10 (b) CV VALUE: Use the keypad to type numbers to set the CV value. (c) WRITE: After select CV number and CV value, press the [STOP] button on the TX to write the accessory decoder. SCREEN-1 2.4GHz DCC R/C System <TENTATIVE>...
-
Page 11: Prog Mode
Press [STOP] button, then wait until the reading value displayed one the LCD screen. (Note: To Read the locomotive it must be on the programming track) ➢ WRITE This function allows to send the programming DCC packet to a decoder. 2.4GHz DCC R/C System <TENTATIVE>... -
Page 12: Program Mode
Press ◄ or ► button to select the desired current CAB number to program. 2.3) CONSIST MODE: Press ◄ or ► button to select consist mode as shown below. OFF:Single Locomotive mode UNI: Universal Consist mode ADV:Advanced consist mode SCREEN-9 2.4GHz DCC R/C System <TENTATIVE>... - Page 13 Press the [STOP] button and select to “DEL”. ADD/DEL CONSIST (DEL) Press ▼ button and select PROGRAM. Select WRITE, then press the [STOP] button. This procedure will clear the CV19=0 and the locomotive advanced consist address will be deleted. 2.4GHz DCC R/C System <TENTATIVE>...
- Page 14 ➢ DCC ADDR Read only ➢ OUTPUT DIR This setting allows the accessory output to be controlled to reverse or normal direction. Press ◄ or ► button to select the NOR (normal) or REV (reverse) 2.4GHz DCC R/C System <TENTATIVE>...
- Page 15 7.1) SOURCE TX: Select “SOURCE” then Press [STOP] button 7.2) DESTINATION: Select “DESTINATION” then Press [STOP] button. Then wait until both TX are powered OFF. When the transmitters turn ON both will have the same memory data. 2.4GHz DCC R/C System <TENTATIVE>...
- Page 16 Transmitter yourself. For more information on Update Firmware go to our web site and look for The USB programmer item #57020 user's manual is on our web site 2.4GHz DCC R/C System <TENTATIVE>...
- Page 17 2.4GHz DCC R/C System <TENTATIVE>...
