Model #AF 940119 •Portable 2 Wheeled 20 Gallon Liberty Sprayer
REQUIREMENTS
Ready-to-Use Chemical Solution
Compressed Air
Hose
Nozzle
OPTIONS
Alternate Air Pump Diaphragm - Santoprene
Standard
Viton Diaphragm Upgrade For Flojet Air Pump
Kalrez Diaphragm Upgrade For Flojet Air Pump
Proportioning / Filling Options
1-Way Ball Valve Mixing Station (4 GPM)
1-Way Push Lever Mixing Station (4 GPM)
High Volume Mixing Station (9.9 GPM)
Overview
The Portable 2-Wheel 20 Gallon Liberty Sprayer is a chemical spray applicator for projecting ready-to-use chemical solution on to a variety of surfaces. This
unit features a stainless steel enclosure and cart and uses a cost-effective Flojet air-operated, double-diaphragm pump to draw pre-diluted chemical from the
20 gallon tank. The solution is then discharged through the hose, wand and fan pattern spray nozzle. Includes 2 spray nozzles providing either 16 or 28
minutes of spraying time depending on the nozzle used.
AFCO • 5000 Letterkenny Rd • Chambersburg, PA. 17201 • 1-800-345-1329
Installation & Operation Instructions
4 CFM
1/2'' x 50'
2506 & 2510
# 710756
# 710755
# 985100
# 981100
# 985835
AFCO
http://www.afcocare.com
READ ALL
INSTRUCTIONS BEFORE
USING EQUIPMENT!
