- Page 1 6-Channel measuring amplifier GSV-6BT Operation manual date: 19/06/2018 edition ba-gsv6bt-v1.3-en editor changes Changelog Seite 13 ME-Meßsysteme GmbH Neuendorfstr. 18a Tel.: +49 3302 89824 60 Mail: info@me-systeme.de 16761 Hennigsdorf Fax: +49 3302 89824 69 Web: www.me-systeme.de...
- Page 2 ME-Meßsysteme GmbH Neuendorfstr. 18a Tel.: +49 3302 89824 60 Mail: info@me-systeme.de 16761 Hennigsdorf Fax: +49 3302 89824 69 Web: www.me-systeme.de...
-
Page 3: Table Of Contents
Measuring amplifier GSV-6BT Contents Measuring amplifier GSV-6BT......................4 Description............................4 More functions..........................5 Software / Communication......................6 Current consumption........................8 Sensor connection..........................8 Pin assignment..........................9 Strain gauge full bridges......................9 SG half bridges..........................10 SG quarter bridge........................10 voltage input UE 0-10V......................10 Input for incremental encoder....................11 Battery and maintenance charging..................11... -
Page 4: Measuring Amplifier Gsv-6Bt
The GSV-6BT is a 6-channel measuring amplifier with Bluetooth interface and data logger function. The dimensions are only 50mm x 20mm x 17mm. The GSV-6BT has 6 measuring channels, of which the first channel is for full-bridge strain gauges, while channels 2 to 6 can be individually configured as voltage input (single-ended) or as strain gauge bridge input including half and quarter-bridge configuration. -
Page 5: More Functions
• the temperature in the device and the battery voltage can be measured • The simultaneous zeroing of all channels can be triggered via a digital input („tare“). • The GSV-6BT is protected against vibration by a full encapsulation in a plastic housing. -
Page 6: Software / Communication
Firstly, the GSV-6BT has to be searched and found (with the battery plugged in) by the Bluetooth driver of the BT adapter of the PC. The device name to display the GSV-6BT after it has been found is the same as the serial number of the device indicated on the nameplate. - Page 7 For self-programming users, a Windows function library (MEGSV8w32.dll) with annotated C header is available and for programming with LabView © a library with wrapper VIs for this DLL. For the use of the GSV-6BT in energy-saving mode "Bluetooth LE" Windows app is available. ME-Meßsysteme GmbH Neuendorfstr. 18a Tel.: +49 3302 89824 60...
-
Page 8: Current Consumption
Current consumption 59 sec. 2 min. GSVonoff=2 GSVonoff=2 Timeintervall>0 Timeintervall=0 Period Period Logger Logger seconds Minutes BT LE GSV off 1,2 mA 1,2 mA 1,2 mA BTmode=0 GSV on 53 mA 48 mA 48 mA BT Classic GSV off 0,78 mA 0,78 mA 0,78 mA GSV on... -
Page 9: Pin Assignment
Pin assignment The connection of the sensors, the rechargeable battery and the voltage for charge / trickle charging of the rechargeable battery is done via solder pads. For the configuration, solder bridges are closed, e.g. for configuring the inputs of the inputs for strain gage half bridges or strain gage quarter bridges Strain gauge full bridges Designation... -
Page 10: Sg Half Bridges
SG half bridges Designation Ch 1 Ch 2 Ch 3 Ch 4 Ch 5 Ch 6 Positive bridge supply US+ Positive bridge supply US+ Negative bridge output UD- half bridge Negative bridge supply US- The active strain gauges R3 and R4 are connected to the terminals + Us, + Ud and -Us. -
Page 11: Input For Incremental Encoder
Input for incremental encoder Designation incremental encoder / I_index (Home/Index/Z) incremental encoder / A-signal incremental encoder / B-signal Battery and maintenance charging Designation Battery charging connection ground Battery charging port 4,5 – 5,5V 0,5A Battery negative pole Battery positive pole Tare (Zero Setting) Auxiliary voltage supply for active sensors Designation... -
Page 12: Function Of The Leds
Function of the LEDs Designation Description Bluetooth Status: On: connected POW. GSV-6CPU On/Off GSV6 GSV-6CPU Status: flash codes, e.g. for TEDS. constantly on / slowly flashing: File open on SD card for writing. Do NOT remove the card! CHRG Battery charging indicator USER IO_4 per BGscript freely programmable LED E ME-Meßsysteme GmbH... -
Page 13: Changelog
Changelog version date amendments ba-gsv6bt-v1.0.odt 25.02.18 First german version (Kab) ba-gsv6bt-v1.1.odt 05.03.18 description extended (SW) ba-gsv6bt-v1.2.odt 02.04.18 Power consumption added (Kab) ba-gsv6bt-v1.3 03.04.18 Added (SW) ba-gsv6bt-v1.0-en.odt 13.06.18 first english version (AE) ba-gsv6bt-v1.3-en.odt 19.06.18 english version edited and added contents (AK) ME-Meßsysteme GmbH Neuendorfstr. - Page 14 Änderungen vorbehalten. Alle Angaben beschreiben unsere Produkte in allgemeiner Form. Sie stellen keine Eigenschaftszusicherung im Sinne des §459 Abs. 2, BGB, dar und begründen keine Haftung.
- Page 16 Made in Germany Copyright © 2018 ME-Meßsysteme GmbH Printed in Germany...
