Air Curtains

Installation manual

DELTA 100-A
DELTA 150-A
DELTA 200-A
Thanks for purchasing this Air Curtain,
Please read these instructions carefully before use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DELTA 100-A and is the answer not in the manual?

Questions and answers

Summary of Contents for Havaco DELTA 100-A

  • Page 1: Installation Manual

    Air Curtains Installation manual DELTA 100-A DELTA 150-A DELTA 200-A Thanks for purchasing this Air Curtain, Please read these instructions carefully before use.
  • Page 2 MODEL [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] DELTA 100-A 1000 102,5 DELTA 150-A 1500 105,0 DELTA 200-A 2000 107,5 3. INSTALLATION CAUTION Follow below recommendations when installing the air curtain: 3.1 Please install the unit in a stable place to avoid the shaking and ensure its security (because it maybe causes vibrations, loosen- ing or noise).
  • Page 3 3.3 Don’t install the unit too low, no less than 2.3 meter from the ground. When the entrance is wider than the unit, it is recommended to install two or more units in parallel. In this case, provide 20-40 mm gaps between the units.
  • Page 4 4.1.2 Drill out the holes for the dowels or plugs (proper position in accordance with the mounting plate): CONCRETE 4.1.3 Fit the mounting plate (use dowels or plugs for concrete, washers and nuts according to the below drawing): WASHER...
  • Page 5 B. Installing on the wooden wall 4.2.1 Fix the mounting plate in the proper positions with tapping screw. WOODEN SCREW MOUNTING PLATE 4.2.2 Follow according to the step 4 of part A C. Hanging from the ceiling 4.3.1 Remove the mounting plate from main body (look at the step 4.1.1)
  • Page 6 4.3.2 Fixing of the ceiling brackets (which are not a part of a delivery), as shown below: WASHER SPRING WASHER 4.3.3 Set and tighten the mounting plate on the ceiling brackets: WASHER SPRING WASHER MOUNTING PLATE 4.3.4 Install the main body, according to part A of such manual:...
  • Page 7 Max. air speed Air volume Noise level Net weigh [V ~ /Hz] [m/s] [dB] [Kg] min. max. min. max. min. max. DELTA 100-A 1400 1700 13,0 10,0 DELTA 150-A 230/50 2200 2700 17,0 DELTA 200-A 2800 3350 21,5 6. WIRING DIAGRAM...
  • Page 8 7. OPERATION OF THE DEVICE 7.1 Turn on the power switch 7.2 Select the proper fan speed: High[H], Low[L] 7.3 According to the installation place, adjust the air defl ectors direction to obtain the best effect. 8. CAUTIONS a) Use the unit at the right voltage and frequency indicated on the nameplate.
