Dear customer,
Thank you for choosing our product. For your safety, please take few minutes to
get through this manual before the installation.
WARNING
1) Children who are under the age of 15teen, are only allowed to use the bathtub
accompany of an adult.
2) Please note, people with hypertension, diabetes or cardiovascular disease are not
allowed to use the bathtub.
3) To avoid damages and scratches do not hit or rub against the bathtub with a hard object.
4) To avoid stumbling, please pay attention to the drop height while entering the bathtub.
5) Please pay double attention in case of wet surface with soapsuds.
6) Do not use any acidic and strong alkaline, acetone, ammonia detergent, as well as any
other which can cause corrosion. Clean it with a soft cloth and a mild detergent suitable
to use on this type of surface.
7) If sealant falls off from the glass, please repair it as fast as possible to avoid any leakage
and other damage.
8) Manual can be varied without any customer notice.
1
Advertisement
Summary of Contents for Avandeo MONACO
- Page 1 Dear customer, Thank you for choosing our product. For your safety, please take few minutes to get through this manual before the installation. WARNING 1) Children who are under the age of 15teen, are only allowed to use the bathtub accompany of an adult.
- Page 2 Please use tools to open this parcel. Make sure all accessories are inside the packing.
- Page 3 PREPARATIONS Bathtub configuration: ITEM NUMBER DESCRIPTION SKIRT BIG JET FAUCET SUCTION ON/OFF SWITCH BODY WATERFALL HAND SHOWER AIR REGULATOR Installation of Electric Appliance 1. Electric parameter RATED VOLTAGE RATED FREQUENCY MAX RATED POWER RATED CURRENT 220 V 50Hz 2500W 11.4A 2.
- Page 4 Installation of water supply Installation Process...
- Page 5 1. Hoses connection The fittings of bathtub were already connected before shipment except faucet. Users need to install the faucet according to basic procedures, after that connect the cold/hot water hose to the corresponding water supply tube which should be in the shelter of the bathtubs back. A.
- Page 6 1. Please lay the bathtub upside down and wrap the drainer with thread PTFE tape, then screw the drainer. Please see the drawing below: Installation of Bathtub...
- Page 7 2. Look on the drawing bellow and install the waterfall shaped faucet and handheld shower, after that, connect to the water hose intake. 3. Adjust the tub feet to make it horizontal. Move the bathtub to the wall corner. Put the drainer to the sewer and seal the drainer with a sealant.
- Page 8 How to Use the Product 1. Switch on the power supply. 2. Turn on the cold/hot water switch and adjust to the suitable temperature. Use the switch to choose the faucet or handheld shower to start water flow through the tap, waterfall or the shower head.
-
Page 9: Troubleshooting
1. When the bathtub fails to work, please check the troubleshooting list first if it can help to solve the problem. If one is incapable of recognizing or dealing with the fault, please contact your service agent, store where the bathtubs was purchased in. 2. - Page 10 1. Use mild liquid detergent and soft cloth for daily cleaning. Do not use a detergent with acetone or ammonia. Disinfector with formic acid and formaldehyde is forbidden during disinfection. 2. Screw of the water circulation and jets for cleaning when plug up by litter such as hair. 3.
- Page 11 Function Description for AA-07 Computer Control Panel 1) Constant temperature control ON/OFF switch 2) Ozone pasteurize 3) Water pump button 4) Waterfall button 5) Volume (up) or function adjustment button (upwards) 6) Radio channel switching and storing button 7) Function switch button 8) Volume (down) or function adjustment button (downwards) 9) Radio 10) CD connector button...
-
Page 12: Volume Adjustment
ON mode). Panel is lighten up by a green-yellow light. To turn it OFF please press the button again. 2) Underwater light Underwater light is automatically turned on with the massaging function and turned off with the same button. 3) Telephone When there is an incoming call in the open status egg. - Page 13 7) Constant Temperature When the water level reaches to the point when it covers all jets, you can turn on the heating function by pressing the button on the display panel or remote control. You can turn the function OFF by pressing the same button one more time. When the symbol of constant temperature is flashing or when you press button, you can adjust the temperature of water with this...
