GTO CS3BT Instruction Manual

Instructions for CS3BT
Three Button Entry Transmitter
The three button transmitter is used for the remote control of two GTO gate openers or one GTO gate
opener and two garage door openers. A GTO Universal Receiver (RB709U-NB) is required for use with
You can have as many transmitters as you want for family and guests to open your gate.
The DIP switches in all the transmitters for a particular gate opener must be set the same.

Cloning/Learning a DIP switch code:

1. Press and hold button 1 and button 3 at the
same time for about 5 seconds.
2. The LED will turn on, then release the buttons.
3. Press and release the button that you want to learn
a DIP switch transmitter to just ONCE.
4. Hold the DIP switch transmitter with the front/top
facing the clip side of the Smart Transmitter.
5. Press the button on the DIP switch transmitter
6. The LED on the Smart Transmitter will blink twice
when it has successfully learned the code.
The button you programmed will now transmit the
DIP switch code as indicated by the LED being solid
on when the button is pressed.

Creating a DIP switch code:

1. Press and hold button 1 and button 3 at the
same time for about 5 seconds.
2. The LED will turn on, then release the buttons.
3. Quickly press 2 times the button you wish to
create a DIP switch code for.
4. The LED will then blink twice showing
successful creation of a DIP switch code.
The button you programmed will now transmit the
DIP switch code as indicated by the LED being
solid on when the button is pressed.
non-GTO garage door openers.
1
3
4
1
3
ACCESS SYSTEMS
2
2
06-17-2015
