50 FT. AIR HOSE REEL
Stock Number M635
WARNING
It is the owner and/or operators' responsibility to study all WARNINGS, operating, and maintenance instructions contained on the product label
and instruction manual prior to operation of this hose reel. The owner/operator shall retain product instructions for future reference.
The owner and/or operator are responsible for maintenance, maintaining all decals or warning labels and while in use, maintaining the unit in
good working order. If the owner and/or operator are not fluent in English, the product warnings and instructions shall be read and discussed
with the operators' native language by the purchaser/owner or his designee. Make sure that the operator comprehends its contents. Safety
information shall be emphasized and understood prior to usage. The hose reel shall be inspected per the operating instructions.
Protect yourself and others by observing all safety information.
Failure to comply with instructions could result in personal injury and/or property damage!
On occasion, after printing of our literature is completed, our manufacturers may make changes and/or modifications to merchandise which will not be reflected in this manual. Although
we strive to maintain complete and accurate information, it is possible in some instances, that the product may differ slightly from printed specifications. Illustrations are intended for
reference only. Actual merchandise may vary. Wilmar is not responsible for typographical errors.
OWNERS MANUAL
Please read these instructions carefully and retain them for future use.
Advertisement
Table of Contents
Related Manuals for Performance Tool M635
Summary of Contents for Performance Tool M635
- Page 1 50 FT. AIR HOSE REEL Stock Number M635 OWNERS MANUAL WARNING It is the owner and/or operators’ responsibility to study all WARNINGS, operating, and maintenance instructions contained on the product label and instruction manual prior to operation of this hose reel. The owner/operator shall retain product instructions for future reference.
- Page 2 SPECIFICATIONS Maximum Working Pressure ..........250 PSI Reel Flange Air Outlet ...........Brass 1/4 in. Female NPT Air Inlet .............Brass 1/4 in. Female NPT Capacity ..............50 ft. x 3/8 in. Outlet to Hose Contents: Hose Reel Instruction Manual Handle Handle & Bolt Make sure all parts listed above are enclosed.
- Page 3 HANDLE ASSEMBLY Attach swivel handle to the reel using the hardware supplied. Match handle to receptacle hole in crank arm. Attach using supplied nylon threaded nut. Use hey key on outside of handle and wrench on nylon lock washer to tighten handle until secure. WARNING: This hose reel is suitable for 3/8 in.
- Page 4 90 days from the date of purchase, provided that product is returned to place of purchase immediately after discovery of defect. After 90 days and up to one year from date of purchase, PERFORMANCE TOOL® will replace at no charge any parts which our examination shall disclose to be defective and under warranty.
