GR-2000 Basic Operation
1. General Specification
- Power On/Off Volume
- PTT Key
: Side [ Tact SW ]
- Monitor Key
: Side [ Tact SW ]
- UP Key
: Top
- Down Key
: Top
- SCAN Key
: Top
- CALL Key
: Top
- Function Key
: Top
- EXT Mic/Charge Jack[ 2.5 ?]
- EXT Speaker Jack[ 3.5 ]
2. Function Flow Chart
F
Channel
Beep
Ringer
3. LCD Display
CTCSS
PWR Hi/Low
Tone
Vibration
DW
VOX
BEEP
F
01-12-20
Roger
1 of 8
Advertisement
Table of Contents
Related Manuals for Genex GR-2000
Summary of Contents for Genex GR-2000
-
Page 1: Lcd Display
GR-2000 Basic Operation 01-12-20 1. General Specification - Power On/Off Volume - PTT Key : Side [ Tact SW ] - Monitor Key : Side [ Tact SW ] - UP Key : Top - Down Key : Top - SCAN Key... - Page 2 GR-2000 Basic Operation 01-12-20 4. Front, Side, Top Overview 2 of 8...
- Page 3 - Volume setting : Rotate On/Off Volume switch to mid position or adjust level that is most comfortable for you. 2) Setting the Channel GR-2000 has 15 main channels. To select the channel - Turn the radio on. - Press up[ ] or down[ ] button to choose the channel.
- Page 4 GR-2000 Basic Operation 01-12-20 To active the DW mode - Press the Function[F] button until the [ oF or 1 up to 15] and DW icon blink on the LCD. - Press the up[ ] button or down [ ] button to choose the channel.
- Page 5 GR-2000 Basic Operation 01-12-20 7) Beep tone To activate or disable the beep tone - Press the Function[F] button until [bP on or oF] and the BELL[ icon blink on the LCD. - Press the up[ ] button or down [ ] button.
- Page 6 GR-2000 Basic Operation 01-12-20 - If there are no more receiving signal for 5 seconds, the unit will go into power save mode and then the “TX” LED will blink with a green color. 12) Receiving The coding feature reduces the possibility of interference and provides enhanced communication.
- Page 7 GR-2000 Basic Operation 01-12-20 To disable the Monitor feature - Press and hold the Monitor[M] button for over two seconds. (The monitor[ ] icon will disappear on the LCD.) 16) Backlight Backlight is used to improve the display visibility in dark condition.
-
Page 8: Fcc Information
GR-2000 Basic Operation 01-12-20 20) External Speaker - Mic Use the approved accessories only to have the optimum performance. - Ear/Mic unit FCC Information THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS :...
