Raytec VARIO 2 PoE Quick Installation Manual

Quick InstallInstallation Guide

Safety Information:

Box Contents:

VARIO2 POE Illuminator , 60° beam angle ILS, User Guide
(ILS: Interchangeable Lens System)
Optional Accessories: Remote Controller for additional programming;
80˚ beam and 120˚ beam angle ILS; Bracketry

Factory Default Set-Up:

35˚ Beam Angle ; Max 100% Power
Photocell sensitivity – MID; Telemetry Input Closed (Premium variants only)
Status LEDs – ON ; No PIN Set
Programming function will auto-disable after 7 Days (if no manual buttons used)
VARIO2 Specifications Table:
See Page 26 and 27 in Full Instruction Guide

PoE Detection:

There is a switch on the VAR2-PoE-w8-1, i8-1 and i8-1-C illuminators which
can be used to change the PoE detection resistance of the illuminator
(24.9KΩ is the factory default setting).
The majority of PSE equipment requires a detection resistance of 24.9KΩ to
establish a PoE link. Some models of PSE equipment require12.5KΩ.
For 24.9 KΩ, slide switch to the LEFT (factory default – as shown). For 12.5 KΩ,
slide switch to the RIGHT.
1
www.rayteccctv.com
POE
White Light and IR Variants (850nm & 940nm)
Caution – Risk Group 2. Avoid Exposure / use protection.
See Safety Information in FULL Instruction Guide for more details.
