Page 1: User Manual
LevelOne User Manual FSW-0511 / FSW-0811 5/8-Port Fast Ethernet Switch V1.0.0-0803... -
Page 2: Package Contents
Package Contents • FSW-0511 or FSW-0811 • Power Adapter • User Manual • Wall-Mounting Kit Installation Please inspect the Power Adapter carefully, and make sure that it is properly connected to a power source. Power on. It will be automatically initialized and the LED indicators should respond as follows: All of the Link/Act LED indicators will flash momentarily, which represent a resetting of the... - Page 3 Features & Specifications 5/8 auto-negotiation 10/100 Mbps Ethernet ports Auto MDI/MDI-X at each port Supports IEEE802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode Data filtering and forwarding at full wire speed Store-and-Forward switching technology Standards IEEE802.3 10Base-T, IEEE802.3u 100Base-TX Data Transfer 10Mbps (Half Duplex), 20Mbps (Full Duplex)
-
Page 4: Led Definition
LED Definition FSW-0511/FSW-0811 Front Panel This indicator will light up when the Switch powers up Link/Act One LED indicator will light green when a device is connected to the corresponding port. It flashes when data is being transmitted or received on the connection. Rear Panel The rear panel of the FSW-0511/FSW-0811 consists of 5/8 10/100Mbps RJ45 Ports.
