Summary of Contents for SportRack CREST DELUXE 2
- Page 1 CREST DELUXE 2 BIKE LOCK-AND-TILTING PLATFORM HITCH RACK EN = North American English 2 bike maximum - 70 lb. total or 35 lb. per tray EN PARTS INCLUDED F x1 C x2 A x1 G x1 B x1 D x2...
- Page 2 EN part EN description EN qty. EN item number EN hook collar top — EN hook collar bottom — EN wheel loop B — EN wheel loop A — EN mast liner 8527888001 EN mast tube — EN arm tube and central bracket assembly —...
- Page 3 IMPORTANT: - Tighten knobs by hand only. - Do not over tighten. - Do not use power or pneumatic tools. 17 mm Tighten Well 506-7094...
- Page 4 506-7094...
- Page 5 C & D - Insert bolt through bracket and slides. - Thread knob on, but do not over tighten. - Slide wheel loop onto bike arms. 506-7094...
- Page 6 EN FOOT INSTALLATION FOR 1 1/4" RECEIVERS - 11/4" receiver installation. - 2" receiver installation. - Insert safety pin through hole. Receiver Installation Receiver Installation Tighten Well EN THE RACK IS NOW READY TO LOAD BIKES. 506-7094...
- Page 7 Tighten Well - Raise the hooks by depressing the grey buttons and sliding the hooks upward on the mast. Bicycle Installation - Place the bike on the bike tray with the wheels in the - Push down hook firmly. wheel trays and push down hook firmly until top tube fits snug against top bend of hook underside.
- Page 8 Tighten Well - Try to position smaller bicycle between support and bumper, combined bicycle weight should not exceed - Attach wheel straps to front and rear wheels as shown. Check security of 70lbs. or 35lbs. per bike. bike. Tighten down hook or wheel straps if needed. - To lock the bikes to the carrier.
