VXI Vesh-P1 User Manual

203426B_VEHS-P1_User_Guide_102913:Layout 1
*This user guide describes the installation steps to connect the VEHS to your phone. For information about your
phone's capabilities or provisioning requirements go to www.vxicorp.com/resources/vehs, visit your phone system
manufacturer's website, or contact your IT administrator.
*Le manuel de l'utilisateur décrit les étapes de branchement du VEHS à votre téléphone.Pour des
renseignements sur les capacités de votre téléphone ou sur les exigences en matière d'approvisionnement, visitez le
www.vxicorp.com/resources/vehs ou le site Web du fabricant de votre téléphone, ou communiquez avec votre
administrateur TI.
*Esta guía de usuario describe los pasos de instalación para conectar el VEHS a su teléfono.Para obtener información
sobre las capacidades de su teléfono o requerimientos de provisiones visite www.vxicorp.com/resources/vehs, visite
el sitio web del fabricante del sistema de su teléfono o comuníquese con su administrador TI.
VXi Corporation | 271 Locust Street, Dover, NH 03820 USA
Toll Free | Sans frais | Número gratuito: (800) 742-8588
Phone | Téléphone | Teléfono: 1 603 742-2888
© 2013 VXi Corporation. All other trademarks are property of their respective owners.
Printed in China | Imprimé en Chine | Impreso en China
10/29/13 1:05 PM Page 1
www.vxicorp.com
APN 203426B

INSTALLATION

1. Remove the panel from the bottom of 3. Insert the color-coded cables from
the base station (refer to the V150 the VEHS-P1 into the corresponding
User Guide for additional information). color-coded jacks of the V150 base
station; the connectors should 'snap'
in place when fully inserted.
2. Attach the VEHS-P1 to the bottom of 4. Connect the longer VEHS-P1 cable
the V150 by carefully inserting the into the AUX port of the phone taking
plastic guide pin into the screw-hole care to align the pins of the cable
socket on the base of the V150, then with the socket of the phone's AUX
press together the rear of the V150 port (the AUX port is generally located
base and VEHS-P1 until it snaps into on the bottom of the phone).
place.

VXi LIMITED WARRANTY

1. VXi warrants that your product will be free from defects in material and workmanship for one year from
the date of purchase. If, during that period from the date of purchase, your product fails to work due to
a defect in material or workmanship, VXi will repair or replace the product, at its election, free of charge.
Without proof of purchase, the warranty period begins on the date of manufacture. Consumable
components (for example, cushion, battery and fuse) are not included in this warranty.
2. The foregoing limited warranty does not cover equipment failure attributable to accident, improper operation,
misuse, abuse, or any cause other than defects in the materials or workmanship of VXi's products.
3. VXi's obligations under this warranty are limited to repair or replacement (at our option) of any defective part
returned to VXi at the customer's expense. Returned products require a Return Authorization that may be
obtained by calling 800-742-8588. Products returned to VXi for repair under this warranty will be return
shipped to the customer at VXi's expense.
4. THIS LIMITED WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Some jurisdictions
do not permit the exclusion of implied warranties and the foregoing exclusions may not apply to you.
5. In no event shall VXi be responsible for any other damages whatsoever, including direct, indirect, special,
incidental, consequential, or other damages for breach of this or any other warranty, express or implied.

Additional V150 Setup

- V150 should be in MODE 2.
- V150 'Compatibility Switch' should be
placed in the 'D' position.
- Connect one end of the base jack cord
(orange tag) into the V150 base jack
(orange dot on base) and the other end
into the headset port of the telephone.
TEL WALL
EHS/LIFTER POWER JACK BASE JACK HANDSET

LED Status Indicator

The LED status indicator indicates the
phone's mode as shown by the table
below.
Phone Mode LED indicator
On-hook
Off-hook
Incoming ring detected
HS
Solid on
Slow flash
Fast flash
