INSTALLATION INSTRUCTIONS
H-BEAM 1.25 / MICRO
Wall Mount
A
1035 22nd Avenue, Unit 1
Oakland, CA 94606
P
510.489.2530
E
TalkToUs@alwusa.com
W
alwusa.com
n

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H-BEAM 1.25 and is the answer not in the manual?

Questions and answers

Summary of Contents for ALW H-BEAM 1.25

  • Page 1 INSTALLATION INSTRUCTIONS H-BEAM 1.25 / MICRO Wall Mount 1035 22nd Avenue, Unit 1 Oakland, CA 94606 510.489.2530 TalkToUs@alwusa.com alwusa.com...
  • Page 2 HB1.25 / MICRO - Safety & Warnings! 1. Read all instructions. 2. Install in accordance with national and local electrical code regulations. 3. This product is intended to be installed and serviced by a qualified, licensed electrician. 4. Do not install in wet locations. For dry and damp use only. 5.
  • Page 3: Table Of Contents

    Table of Contents Luminaire Overview Diagram Included Parts Parts (by others) Tools Required Quick Specs Installation Prepare Wall Connect Wiring Mount Fixture Finishing (single-section fixtures) Joining Straight Sections Finishing (multi-section fixtures) Wiring Diagrams Traditional On/Off 0-10V Dimming DALI Lutron LDE Troubleshooting HB1.25 / MICRO Wall Mount Installation Guide 3 of 11...
  • Page 4: Luminaire Overview

    Luminaire Overview Wall Mount Brackets 6-32 Mounting Screws (x2) 2x4 J-Box To Class 2 Remote Driver (not pictured) Wood Screws (x4) HB Fixture Included Parts 6-32 Mounting Screws HB Fixture Wall Mount Brackets Parts (by others) Tools Required Quick Specs 2”...
  • Page 5: Installation

    Installation: Prepare Wall Plan structure Review submittal drawings for mounting dimensions. ⁄ " 5" ⁄ " ⁄ " ⁄ " ⁄ " Install blocking (Non-Power Entry End) Install Blocking and J-Box Install blocking approximately 4 1/8” from intended Install Blocking 3 1/8” from intended power-entry end of non-power-entry end of fixture.
  • Page 6: Connect Wiring

    Installation: Prepare Wall Installation: Connect Wiring Install Remote Driver J-Box Mount standard wall plate Install remote driver J-Box(es) in an accessible/ Screw standard wall plate into structure using wood serviceable location. Run low voltage CL2 or applicable screws. Ensure standard wall plate is level with J-Box wall wire from Remote Driver J-Box to Canopy J-Box in plate.
  • Page 7: Mount Fixture

    Installation: Mount Fixture Installation: Finishing (single section fixtures) Mount fixture to wall Turn power on Turn power back on at the breaker. Raise fixture to wall brackets. Illuminate fixture Power fixture and check for complete illumination Secure Fixture Secure fixture to wall plates using provided 6-32 screws. Ensure fixture for strength and alignment.
  • Page 8: Joining Straight Sections

    Installation: Joining Straight Sections SHOCK HAZARD! May result in serious injury or death. Turn power OFF at circuit breaker prior to installation or servicing. DO NOT PINCH OR PUT EXCESSIVE TENSION ON WIRES while joining sections or reattaching end caps. Mount fixture to wall Raise fixture to mounting bracket and secure using pro- vided 6-32 screws.
  • Page 9: Finishing (Multi-Section Fixtures)

    Installation: Finishing (multi-section fixtures) Turn power on Turn power back on at the breaker. Illuminate fixture Power fixture and check for complete illumination HB1.25 / MICRO Wall Mount Installation Guide 9 of 11 102-000018 - IG020519-A.0...
  • Page 10: Wiring Diagrams

    Wiring Diagrams Traditional On/Off Brown Driver 1 LED + Black Line Voltage (Hot) Blue Driver 1 LED - Remote LED White Line Voltage (Neutral) Driver J-Box AC 50/60Hz Green Ground Yellow Driver 2 LED + Orange Driver 2 LED - 0-10V Dimming Black Line Voltage (Hot)
  • Page 11: Troubleshooting

    Troubleshooting Only a certified electrician can service and troubleshoot product field issues. Always turn main power off before servicing fixture. Full Fixture does not illuminate • Ensure fixture is wired correctly and power is on. • Check that circuit breaker is on and not off or tripped. •...
