Basisstation2
Bedienungsanleitung
Operating instructions
Istruzioni per l`uso
Instrucciónes de uso
Mode d`emploi
© 2004 by
Bachstraße 59,
5023 Salzburg – Österreich
www.orderman.com
Errors and misprints excepted.
Copyright, all rights reserved.
Duplication, reproduction or distribution,
even in part, is prohibited without the written consent
of think dig high tech solutions gmbh.
P3.56-247 V2.0
think dig übernimmt keine Verantwortung für Schäden oder Verluste, die durch Anwendung dieser Anleitung ent-
stehen.
think dig übernimmt keine Verantwortung für Verluste oder Ansprüche von dritten Personen, die durch die Benüt-
zung der Basisstaion2 entstehen.
Änderungen des Inhalts dieser Anleitung sind vorbehalten, und können ohne Vorankündigung durchgeführt wer-
den.
Diese Bedienungsanleitung kann nicht Bestandteil eines Vertrages sein.
think dig assumes no responsibility for injuries or losses resulting from the utilization of these instructions.
think dig assumes no responsibility for losses or claims by third parties resulting from the use of the base station
2.
The contents of these instructions are subject to changes, which can be carried out without prior notice.
These operating instructions do not constitute part of a contract.
think dig non si assume alcuna responsabilità per danni o perdite eventualmente causati dalle presenti istruzioni
per l'uso.
think dig non si assume alcuna responsabilità per danni o diritti di terzi riconducibili all'uso della stazione base2.
Ci riserviamo di apportare alle presenti istruzioni per l'uso, senza preavviso, qualsiasi modifica al contenuto rite-
nuta necessaria.
Le presenti istruzioni per l'uso non possono essere usate come parte integrante di un contratto.
think dig no se responsabiliza de los daños o pérdidas que puedan ocurrir por el uso de estas instrucciones de
uso.
think dig no se responsabiliza de las pérdidas o exigencias por parte de terceros que puedan ocurrir por el uso
de la antena RF2.
Reservado el derecho de modificaciones del contenido de estas instrucciones. Dichas modificaciones pueden
ocurrir sin previo aviso.
Estas instrucciones de uso no pueden ser parte de un contrato.
think dig décline toute responsabilité pour les dommages ou pertes causés par l'utilisation du présent mode
d'emploi.
think dig décline toute responsabilité pour les pertes ou les revendications de tiers entraînées par l'utilisation de
la station de base2.
Sous réserves de modifications du contenu du présent mode d'emploi. Les modifications peuvent être effectuées
sans avis préalable.
Le présent mode d'emploi ne peut pas constituer de partie intégrante à un contrat.
