Summary of Contents for Priva FS Concentrator
- Page 1 Installation manual FS Concentrator...
- Page 2 This publication has been developed with care. However, the products shown may differ in dimensions and design from the actual products. Priva B.V. will not accept any responsibility for damages caused by any errors or deficiencies in this publication. Priva B.V. may modify its products and the associated manuals without prior notice.
- Page 3 FS Concentrator FS Concentrator – installation manual – 1.2...
-
Page 4: Table Of Contents
Installation - electrical part ................14 Electrical connection ..........................14 Operating software ..................16 Commissioning ....................17 Preparations ............................17 Reset to factory defaults ........................18 Commissioning ............................18 Operation ......................19 Taking out of operation .................. 20 FS Concentrator – installation manual – 1.2... - Page 5 Maintenance and repair ................. 22 Firmware updates ..........................22 Disposal of waste equipment ................ 23 Appendices ....................... 24 Technical specifications ........................24 EC Declaration of Conformity ......................25 FCC Statement ............................26 IC Statement............................26 FS Concentrator – installation manual – 1.2...
-
Page 6: About This Manual
Concentrators. This manual will also allow you to effectively observe and resolve any malfunctions. For the sake of simplicity this manual uses the term "unit", to refer to FS Concentrator. Target groups and required competencies Target group Tasks and responsibilities... -
Page 7: Explanation Of Symbols In This Document
Information Terms and abbreviations The list below states the abbreviations and terms relating to the Priva labour and production registration units of FS Performance. Therefore, abbreviations and terms that do not apply to your specific unit and as a result are not used in this manual may still be found in the list below. -
Page 8: Safety
Keep the product clean and the surroundings tidy. • Report faults or damage to Priva immediately. Inactivate the equipment and do not use it if a deficiency is observed. •... -
Page 9: Installation
• this manual, unforeseen risks may occur. Installation Only Priva approved installers are allowed to install and configure the product. Troubleshooting In case of problems, in most cases a message will be generated. This manual describes the problems you might be able to solve yourself. -
Page 10: Product Description
20 FS Routers per FS Concentrator should be used in one chain. The FS Concentrator can be placed either in the greenhouse or in the packhouse, as long as it can communicate with the first FS Router in the wireless chain. For reasons of optimal speed during heavy data loads, such as updating the firmware in the FS Readers, it is preferred that the FS Concentrator is placed close to the location of the FS Cradles. - Page 11 Data that is received by an FS Router from an FS Reader will be transferred wireless to the next router until delivered at the FS Concentrator. All transaction data is acknowledged by the FS Concentrator. The FS Reader will only flush transaction data from its memory when this acknowledgement has been received.
-
Page 12: Transport And Storage
• • A horizontal cable entry plug (already placed on the PCB inside the FS Concentrator casing). A mounting set containing 4 clips and 4 screws for mounting the FS Concentrator to (for • instance) a cable tray. 3 m CAT.5E UTP Ethernet cable. -
Page 13: Installation - Positioning The Unit
The FS Concentrator must be placed near the FS Cradles, in such a way that FS Readers that are placed in the FS Cradle can communicate with the FS Concentrator (especially for firmware update). -
Page 14: Installation - Electrical Part
Electrical connection The FS Concentrator can be connected to any standard power socket. This is done by connecting any standard power cable according to local regulations. The following steps are to be taken in account to properly install the FS Concentrator: The installer selects the ideal location for the FS Concentrator. - Page 15 Set the switch indicated in the yellow square in Figure 1 to the “ON” position. 10. Close the casing and connect the electrical power. 11. The installer makes sure that the led on the FS Concentrator is functioning, indicating the power and Ethernet connection have both been properly connected.
-
Page 16: Operating Software
Operating software The functionality of the FS Concentrator is in its firmware. The FS Concentrator is delivered with the most recent version of the firmware that was available at the moment of production. The FS Concentrator can be updated with the latest firmware. Please, refer to the “FS Reader Software –... -
Page 17: Commissioning
Preparations The FS Concentrator is delivered with a default IP-address and netmask: 192.168.1.1 / 255.255.255.0. The FS Concentrator must be configured to a static IP-address for the network of the customer. In order to connect to the FS Concentrator, the IP-address 192.168.1.1 must be reachable from the computer that will be used for the configuration. -
Page 18: Reset To Factory Defaults
FS Concentrator. Reset to factory defaults If the FS Concentrator has been set to a wrong or unknown IP-address, it won’t be available on the network. This situation can be resolved by means of a jumper on the Printed Circuit Board (PCB). -
Page 19: Operation
Operation The FS Concentrator works automatically once installed and therefore no further action is needed. The FS Concentrator has a tri-colour status led: Red + Green + Orange, which has the following signalling function: Led shows: Indicates: FS Concentrator is switched OFF... -
Page 20: Taking Out Of Operation
Priva B.V. Taking out of operation If the FS Concentrator must be replaced by another one, first add the new FS Concentrator before removing the old one! (Else all FS Readers must be rebooted to connect to a new network.) -
Page 21: Troubleshooting
Possible cause Solution(s) Led off Power cord is disconnected Reconnect power cord Led off Fuse is broken Replace the fuse No registrations Ethernet cable is disconnected Reconnect Ethernet cable Led red Led orange FS Concentrator – installation manual – 1.2... -
Page 22: Maintenance And Repair
The FS Concentrator does not require regular maintenance in order to keep it working. If the FS Concentrator is in need of repair, the customer will contact Priva B.V. after which the product can be sent back to Priva B.V. for repair or possible replacement. -
Page 23: Disposal Of Waste Equipment
FS Concentrator – installation manual – 1.2... -
Page 24: Appendices
10 .. 95 % Ambient pressure: 70 .. 105 kPa Operating conditions: • Temperature (ambient): 0 .. 50 °C Temperature change: max 30 °C / day Relative humidity: 20 .. 95 % Approvals / certifications: • FS Concentrator – installation manual – 1.2... -
Page 25: Ec Declaration Of Conformity
EN 62311:2008 Assessment of electronic and electrical equipment related to human exposure restrictions for electromagnetic fields (0 Hz-300 GHz) The technical file was compiled by the department Product Development of Priva B.V. The Netherlands, De Lier, January 2016 M. Prins Managing Director FS Concentrator –... -
Page 26: Fcc Statement
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: this device may not cause interference and this device must accept any interference, including interference that may cause undesired operation of the device FS Concentrator – installation manual – 1.2... - Page 27 FS Concentrator – installation manual – 1.2...
- Page 28 Priva B.V. Priva B.V. P.O. Box 18 I www.priva.nl Zijlweg 3 2678 ZG De Lier E contact.priva@priva.nl 2678 LC De Lier Nederland Nederland FS Concentrator – installation manual – 1.2...
