AeroLife Fitness DR-6600 Instruction Manual

DR-6600
AEROLIFE
Home Jumping
Instruction Manual
Names of Each Component
Main Body Names
■Explanation of marks from assembly
during
product inspection
There is a possibility that there are scratch marks on the portions of assembly of your product, but these
would have been caused by product inspections. We apologize and ask for your kind understanding.
ー

Parts Names

F
G
H
I
■
Precautions for usage
●The legs are equipped with a silicone rubber substance to prevent slipping, but if you will be using it
in slippery locations or if you are concerned with the silicone rubber leaving marks, use a non-slip mat.
●
If the spring cover (F) is removed, there is a possibility that the exposed tip of the net hook (I) will cause
injury. Please be sure that the spring covers (F) are firmly secured before use.
1
A
Symbol Part Name Count
B A Net (Jumping Net) 1
B Main Body Cover 1
C End Cap 6
Ｄ
Leg 6
Ｅ
Rubber Cap 6
C
Accessories
D
●User Manual
※This document
E
※Please store with the main
body.
。
Symbol Part Name Count
F Spring Cover 15
G Main Body Frame 1
H Coil Spring 30
I Net Hook 15

Assembly Method

■Assembly Instructions
Rotate right
①Flip over the main body.
②Remove the (6) end caps (C) from the legs of the main body.
③Insert the legs (D) into the screw of the main body perpendicularly.
④As shown in the figure, slowly rotate to the right without breaking.
※If the legs (D) cannot be attached properly, remove the rubber caps (E).
The side from which the rubber caps (E) have been removed also have
screw taps cut into them, so flip over the legs (D) vertically and try
attaching them again.
※The cardboard under the main body cover is only shock-absorbing material.
Remove it before use.

Precautions for Training

■If you are a beginner, do not strain yourself when training
●If you are a beginner or elderly, gradually increase your exercise load and
do not strain yourself.
●Refrain from exercise intensity that results in a lot of pain the following day.
●Elderly people who struggle to maintain balance should refrain from usage.
■Breathing method
●Enjoy exercising at a level where you can breathe normally and
still speak without struggling to breathe.
■Precautions for usage
●Be sure to jump in the center of the net, using the marker in the center as a guide.
●Do not land, hop on, or step on the main body cover.
There is a possibility that this will damage the product or cause injury.
●Only jump as high as you can while still maintaining control of your balance.
This product is not a trampoline for competition. If you jump too high,
there is a possibility that this will lead too damage to the product or injury.
●If any abnormalities are spotted in any of the parts, immediately stop use.
The parts may change in shape due to continued use.
。
2
