Summary of Contents for Special Projects Group SP-500
- Page 1 Panic Device Power Controller Installation Guide Rev. 031510...
- Page 2 Table of Contents: Overview ........................... 3 Specifications ........................3 Installation Instructions ....................3 LED Diagnostics ....................... 4 Maintenance ........................4 Terminal Identification ..................... 4 Wiring Distance Table ...................... 5 Enclosure Dimensions ...................... 7 - 2 - SP-500...
- Page 3 Overview: SP-500 operates one (1) 24VDC panic hardware device. It is designed to handle the high current surge panic hardware locking devices demand. In addition, an auxiliary power output provides power for accessory devices such as card readers, keypads, REX PIRs, electronic timers, relays, etc.
- Page 4 -- OUT + Connect 24VDC Panic Hardware Device, up to 16 amp 300 ms., .5 amp on hold. Normally Open [NO] trigger input controls output. A maintained contact closure GND / NO will extend the unlock period. - 4 - SP-500...
- Page 5 12 amp 12 AWG Stranded 80 ft. 100 ft. 16 amp 14 AWG Stranded 40 ft. 75 ft. 16 amp 12 AWG Stranded 60 ft. 80 ft. 16 amp 10 AWG Stranded 100 ft. 125 ft. SP-500 - 5 -...
- Page 6 U.L. Listed Tamper Switch Reporting Device Fig. 2a AC LED 6.3A 250V UNLOCK GND NO -- BAT + -- Aux + --- OUT GND NO -- BAT + -- Aux + --- OUT Fig. 2b - 6 - SP-500...
- Page 7 Enclosure Dimensions: 8.5”H x 7.5”W x 3.5”D SP-500 - 7 -...
- Page 8 Notes: Special Projects Group is not responsible for any typographical errors. Special Projects Group Inc. 1125 Satellite Blvd., Suite 112, Suwanee, Ga 30024, 678-417-8500, fax: 678-475-8448 web site: www.specialprojectsgroup.com Lifetime Warranty from manufacturer, Made in U.S.A. IISP500 Rev. 031510 G08L...
