- Page 1 Wireless LAN Device Series 802.11n Draft 2.0 Multi-Mode AP ZW-N5310 User’s Manual Version. 1 (2008.05.14)
-
Page 2: Table Of Contents
TABLE OF CONTENTS NOTICE ..............................3 PREFACE ...............................5 CH 1. ZW-5310 INSTALLATION......................6 ............................6 ACKING ....................6 ONNECTORS UTTONS AND ........................7 ARDWARE NSTALLATION CH 2. FIRST TIME CONFIGURATION ....................7 ......................7 EFORE TART TO ONFIGURE ....................8 NOWING THE ETWORK PPLICATION ...........................10 ETUP IZARD ..........................11 ASIC ETTINGS .........................16... - Page 3 PPTP ..............................37 DHCP S ......................38 ONFIGURING ERVER .........................39 TATIC OUTE ETUP ........................40 YNAMIC OUTE ETUP UPNP..............................40 VPN P ..........................40 THROUGH CH5. THE MANAGEMENT.......................41 ..........................41 ISCELLANEOUS ..........................42 PLOAD CRIPT SNMP ..............................42 DDNS ..............................45 ............................45 S / B .......................46 ANDWIDTH SETTING ........................48 YSTEM ETTING ............................48...
-
Page 4: Notice
Notice FCC Warning Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions：... - Page 5 CE Statement ZINWELL, hereby declares that this device is in compliance with the essential requirement and other relevant provisions of the R&TTE Directive 1999/5/EC. This device will be sold in the following EEA countries：Austria, Italy, Belgium,...
-
Page 6: Preface
Preface This guide is for the networking professional who installs and manages the Zinwell ZW-5310 product hereafter referred to as the “device”. To use this guide, you should have experience working with the TCP/IP configuration and be familiar with the concepts and terminology of wireless local area networks. -
Page 7: Ch 1. Zw-5310 Installation
Ch 1. ZW-5310 Installation Packing List Before starting the installation of the device, please make sure the package contains the following items： ● ZW-5310 Multi-Mode AP unit * 1 ● Power Adapter * 1 ● RJ-45 Cable * 1 Connectors, Buttons and LEDs Front Panel From Left to right: Power LED: Red LED lights when power on. -
Page 8: Hardware Installation
From left to right: Antenna port 1/2/3: This SMA Reverse allows the user to connect antenna or RF cable. Please connect all three antennas into it. LAN 4/3/2/1: 4 Ethernet ports for the LAN connection. WAN: Connect the Ethernet port from ISP such as Adsl ITU-R, Cable MODEM. Reset Button: Press Reset button to revert it to factory default. -
Page 9: Knowing The Network Application
192.168.1.254, and the subnet-mask is 255.255.255.0. We Recommend to login with username: root and password: root for the first time configuration. Please note that the DHCP server inside the device is default to up and running. Do not have multiple DHCP servers in your network environment, otherwise it will cause abnormal situation. - Page 10 This mode can let you access the AP of your wireless ISP and share the same public IP address from your ISP to the PCs connecting with both the wired Ethernet ports of the device. When setup as this mode, the wireless radio will be client mode connecting to the AP of your ISP as the WAN connection and then you can configure the WAN IP configuration to meet your WISP requirement.
-
Page 11: Setup Wizard
AP+WDS Hereafter are some topologies of network application for your reference. Internet DEV 1 LAN 192 . 168.2. 254 / 24 WAN PPPoE connection Broadband Modem Wireless Channel : 11 / SSID : DEV 1 MAC Address of WLAN ( BSSID ) 000000042728 DHCP Server enabled ( IP Pool 192 .168 .2.1 ~ 253 ) Router Mode With... -
Page 12: Basic Settings
Router Bridge Wireless ISP 2. Time Zone Setting—input the Internet time setting. This device will update time from NTP server. Time Zone: select your time zone. NTP Update Interval: select the time interval between every update attempt. NTP Server 1: input your favorite NTP server. NTP Server 2: input the backup NTP server. - Page 13 WLAN: Uncheck to disable the wireless interface of device. Default: Checked. Band: Click the dropdown box to select one among 802.11b/g/n Mixed, 802.11b/g Mixed, 802.11a Only, 802.11b Only, 802.11g Only, 802.11n Only, 802.11a/n Mixed modes. Operation: The radio of device supports different modes as following: 1.
- Page 14 devices with WDS function supported can survey and connect to it. Infrastructure: This type requires the presence of 802.11 a/b/g/n Draft 2.0 Access Point. All communication is done via the Access Point. Ethernet AP Client #1 AP Client #2 Ad Hoc: This type of connection provides a peer-to-peer communication between wireless stations.
- Page 15 SSID: The SSID, which is also called ESSID is a unique identifier that wireless networking devices use in order to establish and maintain wireless connectivity. Multiple access point/bridges on a network or sub-network can use the same SSID. SSIDs are case sensitive and can contain up to 32 alphanumeric characters.
- Page 16 choosing 40MHz, the data rate is doubled. HT Extension Channel: below, above This option only appears when you select 40MHz as the HT Channel Bandwidth. Select one to decide whether up or down band to expand the bandwidth. When you setup the below or above option, the available channel may change to fit the RF frequency range.
-
Page 17: Advanced Settings
and the value go back to 300 seconds. When it countdown to zero, this Client/Station will be kicked out from this table. RSSI: It shows the signal strength of this Client/Station in dBm unit. Advanced Settings These settings are only for more technically advanced users who have sufficient knowledge about wireless LAN. - Page 18 DTIM Period The default value of Delivery Traffic Indication Message is 1 beacon. The DTIM which is in the beacon is to inform clients of the next window for listening to broadcast and multicast messages. RTS Threshold The RTS threshold determines the packet size at which the radio issues a request to send (RTS) before sending the packet.
- Page 19 Short Slot Default: enabled. Reduce the waits after the collision time before retransmitting. It will increase the throughput. Tx Burst Default: enabled. Enable it and the device will try this function when the other associated AP/Client is available. Tx Short Preamble Default: enabled.
-
Page 20: Configuring Wireless Security
HT TX Aggregation MSDU Default: enabled. Enable to increase the 11n throughput. Configuring Wireless Security This device provides complete wireless security function include WEP, WPA/WPA2 Personal and Enterprise in different mode (see the Security Support Table). The default security settings of the encryption function are disabled. Choose your preferred security setting depending on what security function you need. - Page 21 Open None, WEP Default Key ID, Key type, Key content Shared/WEP Default Key ID, Key type, Key Auto content WPA/WPA2 TKIP, AES, Pass Phrase (8..32bytes), Hex Personal TKIP/AES (64hex) WPA/WPA2 TKIP, AES, Radius Server Enterprise TKIP/AES Network/Address/Port/Key WEP Encryption Setting Wired Equivalent Privacy (WEP) is implemented in this device to prevent unauthorized access to your wireless network.
- Page 22 encryption method of 40-bit WEP. When input 10 hexadecimal digits (0-9, a-f or A-F) or 5 ACSII chars as the key, it is using 64-bit WEP encryption. 128-bit WEP Encryption ： 128-bit WEP keys are as same as the encryption method 104-bit WEP.
-
Page 23: Mac Acl
depends on whether the RADIUS server location is. Radius Server Address: Input the IP Address of the Radius server. Radius Server Port: Input the port of the Radius server. The default port is 1812. Radius Server Key: Input the Authentication Key. Ethernet RADIUS Server Wireless Station... -
Page 24: Options Explanations
Only applies in AP mode. Options explanations WPS Mode: As Registrar – add other enrollee to this device. The device supports “As Registrar” mode currently. WPS Config Method: PIN – Personal Identification Number: input 8-character code. The PIN code setting must be the same as the enrollee’s setting. PBC –... -
Page 25: Wps Configuration Steps
Note: When the WPS is enabled, the authentication mode is left only Open, WPA Personal and WPA2 Personal for configuration. WPS Configuration Steps Setup the Wireless Security: We recommended you to setup Wireless Security before setting WPS; otherwise it will use no encryption after you setup and start WPS. -
Page 26: Site Survey
communication” and then press “PBC” option on the configuration tool of the WLAN Client (station). The client will get associated in a few seconds. Note: If there isn’t any WPS setting such as Pin code and PBC in your WLAN client tool, perhaps your WLAN client card doesn’t support WPS. - Page 27 Step 2. Check the state of connection in “Status” web page. The alternative way to configure as following: Step 1. In “Wireless Site Survey” page, select one of the SSIDs you want to connect and then press “Connect” button to establish the link.
-
Page 28: Ch 3. Configuring Wds
Step 2. If the linking is established successfully. It will show the message “Connect successfully”. Then press “OK”. Step 3. Then you can check the linking information in “Status” page. Note ： If the available network requires authentication and data encryption, you need to setup the authentication and encryption before step1 and all the settings must be as same as the Access Point or Station. -
Page 29: Wds Network Topology
you want to communicate with in the WDS AP List and then enable the WDS. When you decide to use the WDS to extend your WLAN, please refer the following instructions for configuration. The bridging devices by WDS must use the same radio channel. When the WDS function is enabled, all wireless stations can’t connect the device. - Page 30 LAN 1 WDS #5 WDS #2 LAN 5 WDS #1 LAN 2 WDS #4 WDS #3 LAN 4 LAN3 Spanning Tree Device Entries of WDS AP List Protocol Required WDS1 The MAC Addresses of WDS2, WDS3, WDS4 and WDS5 WDS2 The MAC Address of WDS1 WDS3 The MAC Address of WDS1...
-
Page 31: Wds Application
Mesh topology： LAN 1 WDS #1 LAN 5 LAN 2 WDS #2 WDS #5 WDS #4 WDS #3 LAN 4 LAN3 Device Entries of WDS AP List Spanning Tree Protocol Required WDS1 The MAC Addresses of WDS2, WDS3, WDS4 and WDS5 WDS2 The MAC Addresses of WDS1, WDS3, WDS4 and WDS5 WDS3... - Page 32 Spanning Tree Description Entries of WDS AP List Protocol Required Parent WDS-AP The MAC Address of WDS-AP WDS-AP The MAC Address of Parent WDS-AP Wireless Bridge Wireless Bridge can establish a wireless connection between two or more Wired LANs. When you decide to use the WDS as a Wireless Bridge, please refer the following instructions for configuration.
-
Page 33: Ch 4. Advanced Configurations
Ch 4. Advanced Configurations Configuring LAN to WAN Firewall Filtering function is used to block or permit packets from LAN to WAN. The device supports three kinds of filter Port Filtering, IP Filtering and MAC Filtering. All the entries in current filter table are used to restrict or allow certain types of packets from your local network to through the device. -
Page 34: Ip Filtering
IP Filtering When you enable the IP Filtering function, you can specify local IP Addresses in current filter table. If you select “Accept” for the IP forwarding default policy, once the source IP address of outgoing packets match the IP address definition in the table, the firewall will block those packets form LAN to WAN. -
Page 35: Configuring Port Forwarding (Virtual Server)
Configuring Port Forwarding (Virtual Server) This function allows you to automatically redirect common network services to a specific machine behind the NAT firewall. These settings are only necessary if you wish to host some sort of server like a web server or mail server on the private local network behind the device's NAT firewall. -
Page 36: Configuring Wan Interface
also useful while you run some applications (ex. Internet game) that use uncertain incoming ports. Enable the “Enable DMZ”, and then click “Apply Changes” button to Enable DMZ: save the changes. Input the IP Address of the computer that you want to expose to DMZ LAN IP: Internet. -
Page 37: Dhcp Client (Dynamic Ip)
provided by your ISP or MIS. The address will be your network identifier besides your local network. The number used to identify the IP subnet network, Subnet Mask: indicating whether the IP address can be recognized on the LAN or if it must be reached through a gateway. The IP address of Default Gateway provided by your ISP or Default MIS. -
Page 38: Pppoe
PPPoE When the PPPoE (Point to Point Protocol over Ethernet) WAN Access Type is selected, you must fill the fields of User Name, Password provided by your ISP. The IP configuration will be done when the device successfully authenticates with your ISP. Input the host name for the device. -
Page 39: Configuring Dhcp Server
The number used to identify the IP subnet network, Subnet Mask: indicating whether the IP address can be recognized on the LAN or if it must be reached through a gateway. The IP address of PPTP server. Server IP Address: (Default Gateway) The account provided by your ISP User Name:... -
Page 40: Static Route Setup
Static Route Setup User can set the routing information let the Router knows what routing is correct also it can not learn automatically through other means. For example, if user wants to link the Network 3 and Network 4 separately from Network 1 that Routing Table configuration as below: 1. -
Page 41: Dynamic Route Setup
Dynamic Route Setup The Dynamic Route utilizes RIP1/2 to transmit and receive the route information with other Routers. 1. Enable Dynamic Route and then select RIP 1 、 RIP2 or Both to transmit/receive packets final click Apply Change button. 2. Click Show Route Table button to show Dynamic Route Table. 3. -
Page 42: Ch5. The Management
CH5. The Management Miscellaneous HTTP Port The default http port is 80. For security concern, you can change the device’s http port, to protect this web server from intrusion and attack. 1. Entering the port number you want to change in HTTP PORT field, then click Apply Changes button. -
Page 43: Upload Script
SSH Port Check to enable SSH login. Input the password for SSH login. Upload Script You can upload your private script file or paste your script into the device. SNMP This device is compatible with SNMP v1/v2c and provides standard MIB II. Currently only the “public”... - Page 44 2. Following Table describes the SNMP configuration parameter Label Description SNMP Read Community This string is for SNMP Get-Request for accessing the device. SNMP Write Community This string is for SNMP Set-Request for accessing the device. SNMP Trap Host Setup the Trap host for sending the SNMP event.
- Page 45 1.3.6.1.4.1.99.3 Channel, Channel of the device in WLAN 1.3.6.1.4.1.99.4 Band, 802.11g / 802.11b only 1.3.6.1.4.1.99.5 RSSI, Receive Signal Strength Index (Support AP and Client RSSI) 1.3.6.1.4.1.99.6 Active_Clients, The number of associate clients 1.3.6.1.4.1.99.7 Active_Clients_List, Client’s Information (MAC Address, Data Rate, RSSI…etc) 1.3.6.1.4.1.99.8 Encryption, Encryption type of device in Wireless Network...
-
Page 46: Ddns
1.3.6.1.4.1.99.6 - Active_Clients 1.3.6.1.4.1.99.7 - Active_Clients_List 1.3.6.1.4.1.99.8 - Encryption DDNS If you want to access the device from Internet with the dynamic IP (DHCP, PPPoE) WAN of the device, you can use the DDNS function. First you go to the web site of DDNS to register a DDNS account. Then setup the information in the DDNS page of the device. -
Page 47: Qos / Bandwidth Setting
QoS / Bandwidth setting You can select one between Bandwidth and QoS. Select “Disable” to disable this function. Bandwidth This functionality can control Bandwidth of Up/Downstream. Enable Bandwidth Control and then enter Upload Bandwidth, Latency and Download Bandwidth in the specific field. Parameter Definition Label Description... - Page 48 download bandwidth for every SSID. Download Latency Similar a waiting time the data queuing- time. QoS allows you to specify some rules, to ensure the quality of service in your network. Such as use Bandwidth Priority concept to allocate bandwidth. This function can be helpful in shaping and queuing traffic from LAN (WLAN) to WAN or LAN to WLAN, but not WLAN to WLAN.
-
Page 49: System Log Setting
System Log Setting The device supports the log function. Check the Enable checkbox to setup the details. Options Description System Log Check to enable the log function. Storage Type Choose RAM or Flash to storage the log. Kernel Log Level Click the drop-down box to choose one log level. -
Page 50: Save/Reload Settings
Save/Reload Settings Reset Setting to Factory Default: Besides reset through pressing reset button, this device provides the Web-Browser interface to reset the configuration data. After resetting it, the current configuration data will be lost and restored to factory default value. Saving &... -
Page 51: Password Setup
is the Web-Browser upgrading interface. It will check the firmware checksum and signature, and the wrong firmware won’t be accepted. After upgrading, the device will reboot and please note that depends on the version of firmware, the upgrading may cause the device configuration to be restored to the factory default setting, and the original configuration data will be lost! To upgrade firmware, just assign the file name with full path then click... -
Page 52: The Information
The configurable page for “Admin” level account Main Category Sub page All pages are configurable. All pages are configurable. The configurable page for “Guest” level account Main Category Sub page Management Ping Test Information System Information Wireless Information Routing Table Packet Statics Logout Logout... -
Page 53: System Information
category. System Information Click to view the information about the device. Wireless Information Click to view the wireless information about the device. Routing Table Click to view the Routing Table on the device. -
Page 54: Packet Statics
Packet Statics Click to view the packet statics. System Log Click to view the log on the device. Click the drop down box of “priority” or “category” to filter the log. Click “Refresh” to apply the filter. Logout Logout Click the Logout button to log out the current account. Reboot The “Guest”... - Page 55 ZW-5310 Specification RF SPECIFICATIONS Frequency range 2.4 ~ 2.484 GHz 5.15~5.26, 5.725~5.825 GHz 802.11g TX power 14dBm ± 1dB @ 54Mbps 802.11b TX power 17dBm ± 1dB @ 11Mbps 802.11a TX power 12dBm ± 1dB @ 54Mbps 802.11n(20MHz) -70dBm ± 2dB @ 130Mbps sensitivity 802.11n(40MHz) -66dBm ±...
- Page 56 Hidden SSID Broadcast 64 / 128-bit WEP Encryption WPS Push Button and PIN Code WPA for 802.1x and WPA-PSK WPA2 / IEEE 802.11i WLAN: b/g protection, Block WLAN Relay, Tx Burst, Software Feature Tx Short Preamble, Packet Aggregation, HT Operation mode, HT Guard Interval, HT Tx Aggregate MSDU, MAC ACL, Site Survey.
