Summary of Contents for Holystone HS110
- Page 1 INSTRUCTIONS FOR USE 2.4GHz FPV real-time video and image transmitter drone HS110/200 usa@holystone.com (America) +1(855) 888-6699 ca@holystone.com (Canada) eu@holystone.com (Europe) jp@holystone.com (Japan) www.holystone.com...
-
Page 2: Table Of Contents
CONTENTS 1. Preface ....................1 2. Warnings ................... 1 3. Maintenance ..................2 4. Transmitter Functions ..............3 5. Transmitter Batteries Installation ..........3 6. Drone’s Details ................4 7. Charging The Lithum Battery Of Drone ........6 8. Specification ..................7 9. -
Page 3: Preface
PREFACE: < PREFACE> To make your experience with this drone as straightforward and convenient as possible, please read this instructions before operating and keep it for the future reference and maintenance. Important Statement: 1. This product is not a toy, but it is a high precision drone that integrates various electronic stability and control mechanisms. -
Page 4: Maintenance
4. Neither Holy Stone nor any distributors or agents accepts any responsibility for loss, injury or damage caused by incorrect operation of the drone. 5. This drone is not suitable for children under the age of 14. Younger pilots should always operate the drone under the supervision of an adult. -
Page 5: Transmitter Functions
< TRANSMITTER FUNCTIONS > The transmitter is able to reach its maximum transmission distance at about 400 feet (120 meters) when used in a wide open area with no radio or electronic interference. Short press : Flip Mode Short Press: Take Photo ( Short press,then move right control stick in any direction.) Press 2 Seconds: Record Video... -
Page 6: Drone's Details
< DRONE’S DETAILS > Propeller A Propeller B Front Motor Base Head Propeller A Body Frame Propeller B Landing Gear Propeller Guard Drone Battery Please note that all propellers must be installed in the correct orientation.(Pay attention to the letter “A” or “B” printed on each propeller when installing.) - Page 7 < DRONE’S DETAILS > 04. Propeller Guard 01. Propeller Cap 02. Propeller A 03. Propeller B 05. Motor Shaft Propeller B 06. Motor Base 01. Propeller A 09. Motor Gear(big) 07. Landing Gear 08. HD Camera Qty. Qty. Name Name Propeller Cap Motor Base Propeller A...
-
Page 8: Charging The Lithum Battery Of Drone
< CHARGING THE LITHIUM BATTERY OF DRONE > 1. Balanced charging: Make sure the battery is connected to the drone, insert the USB charging cable into USB adapter( 5V/0.5-1.0A recommended then, connect the USB charging cable to the charging port on the drone. The indicator light on the power switch will turn red when charging and turn off when the battery is fully charged. -
Page 9: Specification
< SPECIFICATION > Drone Model: HS110/HS200 Weight: 146g / 5.13oz Max Flight Time: 9 minutes WIFI Distance: 30 m (Outdoor And Unobstructed) Motor Model: 8616 Hovering: Enabled Operating Temperature Range: 32° to 104°F (0° to 40°C) Dimensions: 320 x 320 x 66 mm... - Page 10 < SPECIFICATION > APP / LIVE VIEW Mobile App: Deerc FPV Live View Working Frequency: 2.4 GHz ISM Live View Quality: 720P @ 20fps Latency: Low Latency Video (depend on conditions and mobile device) Required Operating Systems: iOS 8.0 or above / Android 4.1.2 or above Recommended Devices: 4.7″to 6.0″...
-
Page 11: Flight
< FLIGHT > Rotating propellers can be dangerous. Do not start the motors ● when there are people nearby. Always keep your hands on the transmitter so long as the ● motor is still spinning. Only stop motors mid-flight in emergency situations when doing ●... - Page 12 One Key Return ⑤ Long press the One Key Return Function button to calibrate the gyro. Press ONE KEY TAKE OFF, the drone will fly up and hover about ⑥ 1.5 meters above the ground. When you want to make drone land, press ONE KEY LANDING, the drone will land slowly by itself until it touch the ground.
- Page 13 NOTICE：The default flight control is known as Mode 2. The left stick controls the drone’s altitude and heading, while the right stick controls its forward, backward, left and right movements. ⑧ Push the left joystick (slowly) up/down/left/right, the drone will ascend/ descend,or rotate to left/right.
-
Page 14: Emergency Stop
F/B Sideward Fly Trim : When the drone drifts to foward or backward, slide the trim button to the opposite direction to re-balance the drone. Emergency Stop: Long press or double click the Emergency Stop button, the motors will stop immediately. Only stop motors mid-flight in emergency situations when doing so can reduce the risk of damage or injury. -
Page 15: Headless Mode
< HEADLESS MODE > Do not use the Headless Mode until you totally comprehend the instructions for use. Flying in Headless Mode without sufficient experience might result in loss or damage of the device. 2.4GHz TAKE OFF & LAND RE-SYNC Headless Mode Headless... - Page 16 < HEADLESS MODE > 2. Push the left joystick up then down to pair the transmitter to the drone. 3. Press the Headless Mode button on the transmitter to enter Headless Mode. The direction of control when paired Don’t turn your direction Don’t turn your direction Under Headless Mode, the forward direction is the direction the pilot faces when the pilot pairs the drone with the transmitter.
- Page 17 < ONE KEY RETURN > The Model is designed with a One Key Return function. The function makes the drone fly itself back towards the pilot automatically by simply pressing the One Key Return button. It will continue to fly in this direction until One Key Return mode is canceled or the pilot moves one of the control sticks to resume control of the drone.
-
Page 18: Wifi Camera Function
<WIFI CAMERA FUNCTION > This drone is equipped with FPV real-time camera function as well as gravity sensor control function. Please download the “Deerc FPV ”App to use these functions. QR code of “ Deerc FPV” App for QR code of “ Deerc FPV ” App for Apple iSOS system (Please sacn this Android system (Please sacn this QR QR code to download the APP). -
Page 19: First Person View Function
< FIRST PERSON VIEW FUNCTION > Power on your drone, then go into your phone settings, select Wi-Fi, and then connect to “HolyStoneFPV***”, which is the camera connection. Once you have successfully connected, exit the settings menu on your phone and open the“Deerc FPV”App to see real-time images from camera. <... -
Page 20: Spare Parts
The drone becomes out of control Gyro sensor lose it’s balance after seconds, and recalibrate the gyro. after crashing. crashing. Please do not hesitate to contact us if you need further support. eu@holystone.com (EU) usa@holystone.com (USA) jp@holystone.com (JP) ca@holystone.com (CA) +1(855) 888-6699... -
Page 21: General Information
GENERAL INFORMATION FCC Notice: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. - Page 22 IC Notice: This device complies with Canada Industry licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference; and (2) this device must accept any interference. Including interference that may cause undesired operation of the device. CAN ICES-3 (B) Avis d’Industrie Canada Le présent appareil est conforme aux CNR d'industrie Canada applicables...
- Page 23 We invite you to contact your retailer or inquire at your local town hall to find out where and how the drone can be recycled. BATTERY WARNING: 1.Failure to follow all the instructions may result in serious injury, irreparable damage to the battery and may cause a fire, smoke or explosion.
- Page 24 Directive 2009/48/EC have been fully fulfilled on our product with indication below: Product Name: Remote control four axis series Model : HS110/HS200 The Statement of compliance is available at the following address: http://www.holystone.com/Download/CE/HS110_HS200_EU_DOC.pdf This product can be used across EU member states.
