Page 1: User Manual
User Manual 5 Port HDMI Switcher Model NO:HDSW0016M1... - Page 2 Introduction Dear customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Our series of converters, switchers, extenders, matrixes and splitters are designed to make your A/V device use more convenient, more comfortable, more productive and more cost-efficient.
- Page 3 Accessories Content: 1、Manual 2、Remote 3、IR Extender Cable 4、USB Cable Physical Connect Port: Picture 1.0 Front Panel Showing A： Standby and Start Button B： Standby Status LED, when light goes bright, the device goes to Standby State. C： HDMI Input Channel Switch Button D：...
- Page 4 Picture 1.1 Rear Panel Showing A: HDMI Output Port B：HDMI Input Two, Three, Four, Five Port Picture 1.2 flank Panel Showing A：HDMI Input One Port B：DC 5V Input port...
- Page 5 Remote Button Function Showing “OFF” ：Standby Button, when device is working normally, it will go to Standby status if you press the button and also the Standby Led Status Light will go bright; “ON” ：Start Button, when device is Standby status, it will go to working normally if you press the button and also the Standby Led Status Light will go off;...
- Page 6 put channel is not switched auto while the Auto fuction is turned on,you need to check if yo ur HD Signal source have been started.) * Pls take out the film at the rear of the remote before you use. Pls insert the film to remote rear if you do not use the remote for long time.
- Page 7 Spec: HDSW0016M1 HDMI Resolution……24/50/60fs/1080P/1080i/720p/576p/576i/480P/480i,24/30/2160P Deep Color …………24/30/36bit/1080P/1080i/720p/576p/576i/480P/480i,24bit//2160P HDMI In/Out Supported Audio Format………………………………………………………… DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD HDMI Channel Max Bandwidth………………………………………………………225MHz Input / Output DDC signal…………………………………………………….… 5Vp-p(TTL) HDMI Input Cable Length……………….…………..…≤6m AWG26 HDMI standard cable HDMI Output Cable Length……………………..….….≤6m AWG26 HDMI standard cable Max Working Current…………………………………..……………………..…………400mA Working Temperature Range……………………………………..……………(-0 to +40℃)
- Page 8 Notes: Pls use the machine as the instruction listed to keep the long use lifetime of the machine. 1. The machine should be placed at the spot far from the Damp, High-Temperature, Dusty, Erosive, and oxidative environment. 2. All parts will be free from the strong shake, hit, fall. 3.
- Page 9 3、Check the system connection quality. 4、Check if the line is all good quality. 5、Check the cable quality. 1、To try again to connect the cable to be free from the Obscure Picture unsuccessful connection. 2、HDMI Cable Quality 1、Please confirm the setting position of audio mode No sound switch 1、Pls check if the film that stops the current has been...
