Mutant – The New Species Harmony Speakers Features Installation Wiring Diagram Speaker Dimensions Tweeter & Crossover Dimensions Grille Dimensions Trouble Shooting Thiele Parameters Warranty For more information about car audio visit our website at is a brand name of Armour Automotive Ltd. - Page 3 Mutant’s new Harmony speakers have been designed to provide stunning audio reproduction and drop dead gorgeous looks at an affordable price. Stunning Gloss black cones with Rose Gold accents mean that you can at last be proud to show off your speakers without having to break the bank.
- Page 4 new Harmony speakers have been designed to provide stunning audio reproduction and drop dead gorgeous looks at an affordable price. Stunning Gloss black cones with Rose Gold accents mean that you can at last be proud to show off your speakers without having to break the bank. With High Gloss PU surround to compliment the rose gold tweeter housing and detailing and give superior cone control and linear travel for improved clarity.
- Page 5 Before starting the installation, you should decide the location for all components of the speaker system. This can be the door of the vehicle, the dashboard or rear parcel shelf. You may also choose to make custom mounts for the speakers as the best results can often be obtained by using MDF baffle rings.
- Page 6 Next you will need to cut a 45mm hole for the tweeter body to fit through the panel. Once the hole is cut you can insert the tweeter into the hole and use the supplied bracket to secure it from the rear. If you are to use the surface mount option you should remove the front bezel from the tweeter by unscrewing it anti clockwise.
- Page 7 When you come to wire up your new Harmony component speakers please ensure that the speaker’s wires do not get pinched behind any panels and that they are not going to get nipped by and panel securing screws. Also please make sure that wherever the wires pass through metal that they are protected by a grommet (door jambs).
- Page 8 50.5 51.5 62.5 52.5 60.5 136.2 155.5 203.7 For more information about car audio visit our website at is a brand name of Armour Automotive Ltd.
- Page 9 37.4mm 52.6mm 23.5mm 18mm 45.2mm 30.5mm 18mm 94mm 46.5mm 66mm INPUT WOOFER TWEETER 85mm 105mm For more information about car audio visit our website at is a brand name of Armour Automotive Ltd.
- Page 10 179.6 10.5 11.5 136.2 155.5 203.7 For more information about car audio visit our website at is a brand name of Armour Automotive Ltd.
- Page 11 • Check connections on speaker are good and connections at source are good. • Make sure gain or volume is turned up. Check that none of the speaker wires are shorted or pinched behind a panel or trim. Check all connections at crossover especially the tweeter level input connections.
- Page 12 Max Power (Watts) RMS Power (Watts) Impedance (Ohms) 4 ohm 4 ohm Frequency Response 50Hz - 20KHz 50Hz - 20KHz (Hz) Magnet Size (oz) 10oz Voice coil diameter 1” Kapton 1” Kapton (inches) Sensitivity (dB) dB (1W/1M) 86.500 87.000 Resonant Frequency 99.540 58.086 (Hz)
- Page 13 140W 4 ohm 4 ohm 4 ohm 4 ohm 60Hz - 20KHz 50Hz - 20KHz 50Hz - 20KHz 40Hz - 20KHz 7.6oz 10oz 12.5oz 20oz 1.2” Kapton 1.2” Kapton 1.2” Kapton 1.2” Kapton 84.000 86.500 88.000 87.000 106.734 86.575 81.210 61.077 5.561 5.376...
- Page 14 If you need to make a warranty claim or require service to your Mutant product, please return to your original dealer with the product and your original bill of sale.
- Page 15 Why not attach your receipt here so you can find it should you need it!!! Model Number: ___________ Date of Purchase: ____________ DEALER:__________________________________________________ (Enter your dealer telephone number here for future reference) *Calls cost 60p per minute. Opening hours: 9:00am - 5:30pm Mon-Thu, 9:00am - 1:30pm Fri. *Call costs correct at date of creation For more information about car audio visit our website at...
- Page 16 For more information about car audio visit our website at: is a brand name of Armour Automotive Ltd. Woolmer Way, Bordon, Hampshire, GU35 9QE T: +44 (0)1420 476767 F: +44 (0)1420 477137 www.armourautomotive.uk.com...
