Summary of Contents for AMIMON AMN32225 Grizzly
- Page 1 AMN32225 (Grizzly) User/Installer Manual An AMIMON Inc. Document Copyright 2014 Version 1.1...
-
Page 2: Important Notice
AMIMON does not warrant or represent that any license, either express or implied, is granted under any AMIMON patent right, copyright, mask work right, or other AMIMON intellectual property right relating to any combination, machine, or process in which AMIMON products or services are used. -
Page 3: Revision History
Revision History Version Date Description Sep 15, 2014 Initial Release Oct. 21, 2014 Add notification about Power Supply on pages 9, 11. Replace the Module picture... -
Page 4: Table Of Contents
Table of Contents ............Important Notice ............Revision History ............Table of Contents ............Safety Instructions ............... Introduction Front view .................... Back view ..................... LED behaviors ..................FCC Caution .............. -
Page 5: Safety Instructions
Do not open unit. Do not block the air ventilation openings. Use only accessories specified or recommended by Amimon. When devices are switched on keep away at least 20 cm from your body. Do not expose to moisture or excessive heat. -
Page 6: Introduction
A/V receiver board, which works at the 5GHz unlicensed band. RIZZLY It is are based on AMIMON's WHDI Professional chipset that consist of the AMN2220 baseband receiver and the MAXIM 2851 ICs, presents the ultimate solution for HDMI receiver of the WHDI system. -
Page 7: Front View
PRODUCT DESCRIPTION Front view Figure 1 –Rx Grizzly top-side Back view Figure 2 – Rx Grizzly bottom side... -
Page 8: Led Behaviors
LED behaviors Network LED BLINKING MODE DESCRIPTION Solid When a connection to Tx is established*/Link quality is good Slow Device is in listen mode/Link quality is reasonably good Normal During link setup mode/during registration Fast System Error (Video LED flashing as well)/Link quality is poor *In Aerial mode even when Tx is out of range. - Page 9 PRODUCT INSTALLATION The AMN352225 is referred as the main platform that comprises a wireless Video Display Unit (VDU). It provides HDMI video signal Interface connector output. The source of the video and audio is a compatible remote wireless Video Source Device (VSU). At common application, the VSU is connected to a video source, and transmits the video over wireless to the VDU, which is connected to the video monitor.
- Page 10 Position both transmitter and receiver in an upwards position, for enhanced antennas performance. Mount the Amimon - AMN352225 module with proper air ventilation. Bring the transmitter and receiver closer together while trying to maintain at least 1 meter...
-
Page 11: Fcc Caution
FCC Caution Any changes or modifications not expressly approved by the responsible party could void the user's authority to operate this equipment. Notice: This module in its final integration requires the end-product to continue to comply with DFS requirements. A class II permissive change may be required for operation not already described in the FCC Grant filing. A regulated power supply will need to be used with this module and may be subject to further FCC testing.
