- Page 1 70ZX416241E-11 1/14 Eddysonic Flowmeter Operation Manual Surpass Industry Co., Ltd. 2015/2...
-
Page 2: Read Before Use
Surpass Industry about errors, Use the product only as intended, and only omissions, or any other points of doubt. as directed in this manual. -
Page 3: Product Description
70ZX416241E-11 3/14 Product Description Eddysonic Flowmeter, that has the part in contact with liquid made of PFA and provides connection with no use of seal-tapes resulting in potentially leakage, is the ideal flowmeter used to measure the flow rates of chemical liquids. - Page 4 70ZX416241E-11 4/14 <Circuit Block Diagram> Waveform Shaping Phase Filter/Amplifier Comparator Comparator Analog Output Oscillator Pulse Output Circuit Block Diagram...
-
Page 5: Specifications
70ZX416241E-11 5/14 Specifications Model ESL-6-2.5 ESL-10 ESL-10-7 ESL-15 Applicable Fluid Fluids not corrosive or permeable against fluorocarbon resin Flow Meter Range 0.4 ~ 2.5 L/min 0.5 ~ 3.5 L/min 0.5 ~7 L/min 1 ~ 16 L/min (at water)(※ (at 1x10... - Page 6 ※ Instructions on range of flow rate Kinetic viscosity of liquids Maximum flow [x 10 rate [L/min] ESL-6-2.5 Minimum flow rate of liquids [L/min] ESL-10 Minimum flow rate of liquids [L/min] ESL-10-7 Minimum flow rate of liquids [L/min] ESL-15 Minimum flow rate 16.0...
-
Page 7: Outer Dimensions
70ZX416241E-11 7/14 Outer Dimensions ＥＤＤＹＳＯＮＩＣ ＦＬＯＷＭＥＴＥＲ ＥＳＬ－１０ ＳＵＲＰＡＳＳ ＩＮＤＵＳＴＲＹ ＣＯ．，ＬＴＤ． ＭＡＤＥ ＩＮ ＪＡＰＡＮ ｗｗｗ．ｓｕｒｐａｓｓｉｎｄｕｓｔｒｙ．ｃｏ．ｊｐ Base Flow direction indicator Cable... - Page 8 70ZX416241E-11 8/14 Mounting and Connecting the Connector Parts If you wish to anchor your Flowmeter, always use the mounting holes in the base. In order to install connector parts correctly, always refer to the relevant catalog or operation manual issued by the connector manufacturer.
-
Page 9: Pressure Loss
Pd : Pressure values at the downstream side [kPa ] ⊿P: Pressure loss values [kPa] : Vapor pressure values of liquids [kPa abs] < > Pressure Loss ESL-6-2.5 ESL-10 ESL-15 Flow Rate [L/min] ※ Cavitations Phenomenon that the liquid evaporates, generating air bubbles, when the liquid pressure drops to the... - Page 10 70ZX416241E-11 10/14 Points to Observe When Installing To prevent erroneous operation or premature wear, do not install in: Areas where corrosive Areas of excessive Areas of high or explosive gases are vibration temperature being ejected Areas that may be Areas that may be Areas of excessive Outdoor submerged in water or...
- Page 11 70ZX416241E-11 11/14 Wiring Observe these precautions to connect the leads correctly. CAUTION Never do wiring work when power supply is on. Doing so may cause electrical shock. Refrain from excessive pulling or bending of the cables. Doing so may cause disconnections which may cause electrical shock and fire hazards.
-
Page 12: Maintenance And Inspection
<Relationship of Flow and Analog Output> The analog output increases proportional to flow in the range of (1) L/min. (The Flow Range depends on the flowmeter model) <Flow Range> ESL-6-2.5 0.4 ~ 2.5 L/min ESL-10 0.5 ~ 3.5 L/min ESL-10-7 0.5 ~7... -
Page 13: In Case Of Breakdown
70ZX416241E-11 13/14 In Case of Breakdown Symptom Cause Countermeasure No output value displayed Incorrect wiring. Check the wiring diagram and correct the with a flow. wiring. Incompatible power, voltage. Check the power supply and voltage. The tubing system is not filled Fill the liquid inside the tubing system. - Page 14 70ZX416241E-11 14/14 Notes on Warranty The warranty runs for one year after the day when Surpass Industry products are delivered from Surpass factory in Japan. In case Surpass Industry should agree in writing that the defects in performance or material were caused by faulty design or workmanship of Surpass Industry, replacement products will be supplied free of charge.
