INSTALLATION MANUAL
MANUFACTURERS SPECIFICATION
FORM050D1/3
ROLL IN REFRIGERATED
B I O R O L L
1x1C, 2x1C and 3x1C Stainless & White
1x2C, 2x2C and 3x2C Stainless & White
1x3C, 2x3C and 3x3C Stainless & White
CABINETS
BONNET GRANDE CUISINE
Rue des Frères Lumière - Z.I. Mitry Compans
77292 MITRY MORY cedex
Tél. 01 60 93 70 00 - Fax. 01 60 93 70 43
n° 6BE648285NI-0606
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Bonnet S200B11
Summary of Contents for Bonnet S200B11
- Page 1 1x2C, 2x2C and 3x2C Stainless & White 1x3C, 2x3C and 3x3C Stainless & White INSTALLATION MANUAL MANUFACTURERS SPECIFICATION BONNET GRANDE CUISINE Rue des Frères Lumière - Z.I. Mitry Compans 77292 MITRY MORY cedex Tél. 01 60 93 70 00 - Fax. 01 60 93 70 43 n°...
- Page 2 IMPORTANT RECOMMENDATIONS ∗ The installation should be entrusted to approved contractors and comply with all current regulations. ∗ Before locating the unit ensure that the air circulation and volume are sufficient to allow normal cooling of the condenser and compressor. ∗...
-
Page 3: Table Of Contents
3.5 Connections 4. Commissioning 4.1 General requirements 4.2 Thermostat configuration BONNET GRANDE CUISINE Rue des Frères Lumière - Z.I. Mitry Compans 77292 MITRY MORY cedex Tél. 01 60 93 70 00 - Fax. 01 60 93 70 43 n° 6BE648285NI-0606 – Page 1... -
Page 4: Technical Characteristics
1. TECHNICAL CHARACTERISTICS LOCATION 1.1 Model 1x1C The cabinet must be installed on a flat, smooth and S200B11 : Model 1x1C Stainless perfectly horizontal surface. A bead of silicone mastic is S210B11 : Model 1x1C White required around the perimeter. -
Page 5: Model 2X1C
1.2 Model 2x1C LOCATION The cabinet must be installed on a flat, smooth and S200B21 : Model 2x1C Stainless 1D to RHS perfectly horizontal surface. A bead of silicone mastic is S201B21 : Model 2x1C Stainless 1D to LHS required around the perimeter. S210B21 : Model 2x1C White 1D to RHS CONSTRUCTION S211B21 : Model 2x1C White 1D to LHS... -
Page 6: Model 3X1C
1.3 Model 3x1C LOCATION The cabinet must be installed on a flat, smooth and S200B31 : Model 3x1C Stainless 1D to RHS perfectly horizontal surface. A bead of silicone mastic is S201B31 : Model 3x1C Stainless 1D to LHS required around the perimeter. S202B31 : Model 3x1C Stainless 1D central S210B31 : Model 3x1C White 1D to RHS CONSTRUCTION... -
Page 7: Model 1X2C
1.4 Model 1x2C LOCATION The cabinet must be installed on a flat, smooth and S200B12 : Model 1x2C Stainless perfectly horizontal surface. A bead of silicone mastic is S210B12 : Model 1x2C White required around the perimeter. CONSTRUCTION - Internal and external panels in austenitic stainless or white plastic coated steel (except the external roof in corrosion proof galvanised sheet). -
Page 8: Model 2X2C
1.5 Model 2x2C LOCATION The cabinet must be installed on a flat, smooth and S200B22 : Model 2x2C Stainless 1D to RHS perfectly horizontal surface. A bead of silicone mastic is S201B22 : Model 2x2C Stainless 1D to LHS required around the perimeter. S210B22 : Model 2x2C White 1D to RHS S211B22 : Model 2x2C White 1D to LHS CONSTRUCTION... -
Page 9: Model 3X2C
1.6 Model 3x2C LOCATION The cabinet must be installed on a flat, smooth and S200B32 : Model 3x2C Stainless 1D to RHS perfectly horizontal surface. A bead of silicone mastic is S201B32 : Model 3x2C Stainless 1D to LHS required around the perimeter. S202B32 : Model 3x2C Stainless 1D central S210B32 : Model 3x2C White 1D to RHS CONSTRUCTION... -
Page 10: Model 1X3C
1.7 Model 1x3C LOCATION The cabinet must be installed on a flat, smooth and S200B13 : Model 1x3C Stainless perfectly horizontal surface. A bead of silicone mastic is S210B13 : Model 1x3C White required around the perimeter. CONSTRUCTION - Internal and external panels in austenitic stainless or white plastic coated steel (except the external roof in corrosion proof galvanised sheet). -
Page 11: Model 2X3C
1.8 Model 2x3C LOCATION The cabinet must be installed on a flat, smooth and S200B23 : Model 2x3C Stainless 1D to RHS perfectly horizontal surface. A bead of silicone mastic is S201B23 : Model 2x3C Stainless 1D to LHS required around the perimeter. S210B23 : Model 2x3C White 1D to RHS S211B23 : Model 2x3C White 1D to LHS CONSTRUCTION... -
Page 12: Model 3X3C
1.9 Model 3x3C LOCATION The cabinet must be installed on a flat, smooth and S200B33 : Model 3x3C Stainless 1D to RHS perfectly horizontal surface. A bead of silicone mastic is S201B33 : Model 3x3C Stainless 1D to LHS required around the perimeter. S202B33 : Model 3x3C Stainless 1D central S210B33 : Model 3x3C White 1D to RHS CONSTRUCTION... -
Page 13: Data Plate
2. DATA PLATE The data plate is to be found fixed to the refrigeration platform. Voir plaque pour cellules et Arm chaudes For all correspondence relating to your equipment remember : - The unit code (Type) - The serial number (N° SERIE) - The date (Date) The principal characteristics are repeated on a label fixed to: - The left hand internal panel... -
Page 14: Installation
3. INSTALLATION 3.1 GENERAL REQUIREMENTS The installation, any repairs or alterations to this equipment should be undertaken by qualified specialists. 3.2 HANDLING The appliance should be moved with specialist lifting gear. If the unit must be transported it should be on its original pallet and should under no circumstances be stacked. -
Page 15: Assembly Instructions
3.4 ASSEMBLY INSTRUCTIONS 3.4.1 ASSEMBLY PRINCIPLES Compressor cover assembly (GI model only) Refrigeration platform Control panel Right rear Left rear End panel Left hand door & frame Right hand door & End panel frame Floor fixing channel Door frame fixing bracket Model shown: 2x1C GI cabinet with 2 doors to the front. - Page 16 3.4.2 FLOOR FIXING CHANNEL IMPORTANT : The floor fixing channels should be fixed to a perfectly flat and horizontal floor. With the stainless base option the channels are replaced by a radiused stainless sheet. In this case, to avoid water infiltration the base should be sealed to the floor with mastic particularly in the doorways.
- Page 17 3.4.3 INSTALLING THE PANELS Assemble the panels so that the 8mm locating pegs fit into the locking boxes . Locking is accomplished using a special key provided with the unit, simply turn until it engages. The holes are plugged by 10mm covers that are supplied. 1) Start by assembling the back and corner panels Hole plug ∅10 Locating pegs ∅8...
- Page 18 3.4.4 FITTING THE CONTROL PANEL 1) Start by outlining the location and drilling 2) Open the facia and fit the back of the the 3mm holes. control panel with 4 self tapping screws Facia control panel 4 self tapping screws 3.4.5 FITTING THE COMPRESSOR COVER (for GI models) Fix the different pieces of the front cover on to the top of the side panels (where the...
- Page 19 3.4.6 FITTING THE FLOOR FINISHING KITS (optional) After cutting them to length, the PVC finishing strips are fixed to the cabinet using the FB n°4.19 self tapping screws provided. Seal in place with silicone mastic. Internal finishing strips are not compatible with the stainless floor base option. 3.4.7 REVERSING THE DOOR HANDING On site this operation requires that a set of lexan labels be ordered.
-
Page 20: Connections
3.5 CONNECTIONS ( See § 1 "Technical characteristics") 3.5.1 REFRIGERATION Cabinets that are not fully equipped (without compressor) are supplied with an external suction tube and a thermostatic expansion valve on top of the unit. 3.5.2 ELECTRICS The unit is fitted with a supply cable which should not be removed. Earth continuity must be maintained (see §... -
Page 21: Commissioning
4. COMMISSIONING 4.1 GENERAL REQUIREMENTS There are no particular requirements except to ensure that nothing obstructs the air flow to the condenser and evaporator. 4.2 THERMOSTAT CONFIGURATION To adjust the thermostat see the OPERATING MANUAL Due to the inertia of the thermostat bulb the correct temperature will not be displayed until after the initialisation is complete. - Page 22 4.2.2 TABLE OF PARAMETERS Code Parameter Factory Password To be set to –19 –55 PROBE Probe type 1=PTC ; 3=NTC Unit of temperature 0=°F ; 1=°C TEMPERATURE REGULATOR Differential °C Minimum set point –55 °C –2 Maximum set point –55 °C COMPRESSOR PROTECTION Delay at power up...
