Simplicity 555M Parts Manual page 11

Engine, Pulleys, & Frame Group - 5HP Tecumseh
REF NO PART NO.
45 7092031SM
46 2824819SM
47 1674325SM
48 7090201SM
49 1720313SM
50 7010061SM
51 7015861SM
52 1930645SM
53 7028090SM
54 7091075SM
55 7034169SM
56 7034254SM
57 7034251SM
58 7034239SM
Footnotes
Note*See your local Tecumseh distributor for engine service parts.
The above parts group applies to the following Mfg. Nos.:
1694587 - 555M
1694595 - 555M
Briggs and Stratton Yard Power Products Group
Copyright © 2008 by Briggs and Stratton Corporation
Milwaukee, WI, USA. All rights reserved
QTY. DESCRIPTION
1 JAM NUT, 5/16-24 Hex
1 KEY - Hi Pro .125 x .625 HP 504 SAE1035
1 PULLEY, V Groove
2 SET SCREW, 5/16-18 x 5/16" Hex Recess, Cup Point
1 PULLEY, 2.75 OD
1 KEY, 3/16 Square x 1"
1 HARNESS CLIP
1 NUT, 3/8-16 Hex Flange Lock Two Way
1 MUFFLER GUARD, Domestic (Tecumseh)
1 SCREW, #10-24 x 5/8" Hex Washer Self-Tap
1 MUFFLER GUARD, Tecumseh Engine (CE/Export), not shown; Tecumseh p/n 127-18
2 SCREW. Tecumseh Muffler, not shown; Tecumseh p/n 42-671
2 LOCK WASHER, Tecumseh Muffler, not shown; Tecumseh p/n 36-351
2 WASHER, Tecumseh Muffler, not shown; Tecumseh p/n 36-195-1
11
TP 400-4148-01-IW-S
