Version 1.1

Smart Necklace

Manual

V1.1

Table of Contents

Need help?

Do you have a question about the Miragii-N-A and is the answer not in the manual?

Questions and answers

Summary of Contents for Miragii Miragii-N-A

Page 1 Version 1.1 Smart Necklace Manual V1.1...
Page 2: Technical Specification
Please Read This User’s Manual Please take the time to follow the instructions in this user’s manual carefully. It will help you set up and operate your Miragii product properly and enjoy its advanced features. Please save this guide for future reference.
Page 3: First Time Use
Version 1.1 2 Product Graphic Definition Earphone Pendant The pendant has a concealed earphone on the back. 3 Product Function Definition Scene 1 Scene 2 First Time Use Charge the pendent and the earphone first after you received the package. Please see section 4, for cable connections.
Page 4 Set “Bluetooth” to “ON” c) Tap the earphone inside the pendent to wake it up d) In Devices list, select Miragii product ID to connect. e) Click the arrow next to “Connected” or “Not Connected”. f) Set “Show Notifications” to “ON”...
Page 5: Incoming Call
The Bluetooth® ID is printed on the surface of the earphone. 3) In the smart phone Bluetooth® synchronizing list, select the Miragii product ID and begin pairing. 4) During paring, the LED light alternates between green and blue.
Page 6 Version 1.1 has been paired with the smart phone. 2) In Scene 2, an incoming text message will trigger the vibrator inside the pendent; it will vibrate 3 times as the notification. 3) User puts one hand within 3 cm in front of the pendent., After the sensor detects the hand, move that hand to about 10~30 cm in front of the pendent, the incoming message sender name will be projected on the hand for 6 seconds.
Page 7 Version 1.1...
Page 8 Version 1.1 Procedure to take out Earphone Step 1 Step 2 Step 3 1) In step 1, disconnect the earphone with the pendent connector by carefully pulling the earphone head in the direction as the arrow shows. 2) In step 2, continue sliding the earphone toward the edge of the pendent as the arrow shows.
Page 9: Outgoing Call
Version 1.1 Decline Call/SMS Put the hand in front of the pendent very close, within 3 cm for about 1~3 second, and then move the hand away completely. Scroll down message Move the hand toward the pendent to about 5~10cm spacing, and then move the hand in front of the pendent until about 20cm away.
Page 10 Version 1.1 2) Take Earphone out from Pendant. 3) Use the charging cable included to connect to both the earphone and the pendent as shown on the following drawing. 4) Connect the USB port of the charging cable to power USB port. 5) Earphone LED will appear green, while the pendent will vibrate once to indicate charging started to Earphone...
Page 11: Trouble Shooting
Version 1.1 Use the specialized pin to push the reset button in the hole for 1 second. 6 Package 1) Pendant (Battery in) 2) Earphone (Battery in) 3) Cord 4) Charging cable 5) User manual 7 Trouble shooting item description Possible reasons/solutions No or low sound from earphone...
Page 12: Firmware Upgrade
Further setup instructions will be available once APP is released. 10 Limited Warranty Miragii, LLC, including its affiliates (“Miragii”) warranty information can be found online at http://www.miragii.com/legalnotice.html. 11 Compatibility You acknowledge that you have verified the compatibility of the product with other required equipment (e.g., ensuring that your mobile device and/or...
Page 13: Limitation Of Liability
Any and all intellectual property rights involved in, embedded or related to the product and/or any of its parts that is a property of Miragii shall remain the exclusive property of Miragii. YOU ASSUME ALL RISK AND...
Page 14 Version 1.1 services). Miragii product is not designed or intended to be used for such communication. YOU UNDERSTAND THAT 911 SERVICE IS NOT PROVIDED OR AVAILABLE THROUGH THE USE OF THE PRODUCT. IF YOU USE THE PRODUCT OR APPS IN CONNECTION WITH OR ASSOCIATED WITH...
Page 15: Safety And Handling Information
• Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by Miragii could void the user’s authority to operate this equipment. La operació n de este equipo está sujeta a las siguientes dos condiciones: (1)
Page 16  Do not leave your Miragii product in direct sunlight for an extended period of time.  Do not leave your Miragii product near open flames.  Do not dispose of your Miragii product in a fire. The battery could explode.  Do not attempt to disassemble your Miragii product.
Page 17 All users should pay attention to road conditions, closures, traffic, and all other factors that may impact safe driving or walking. Always obey posted road signs. You should not use the Miragii product while driving.
Page 18 RF energy and compatible with the Miragii product. Your physician may also be able to assist you in obtaining this information. Many manufacturers of medical devices recommend that...
Page 19: Built-In Battery Precautions
15 Built-in Battery Precautions  Do not attempt to replace your Miragii product’s battery. It is built-in and not changeable.  Charge the battery in accordance with the instructions supplied with this guide.
Page 20: Disposal And Recycling Information
 Do not attempt to force open the built-in battery. 16 Disposal and Recycling Information You must dispose of Miragii product properly according to local laws and regulations. Because Miragii product contains electronic components and a battery, Miragii product must be disposed of separately from household waste.
Page 21 Version 1.1...
