Left View; Right View - Acer Swift 5 Quick Manual

Left view

# Icon Item
1 Noble lock slot
2 Headset/speaker jack
Power indicator
3
Battery indicator

Right view

# Icon Item
1 USB Type-C port
USB port with power-
2
off charging
3 USB port
4 HDMI port
5 DC-in jack
1 2 3
Description
Connects to a Noble-compatible security lock.
Connects to audio devices (e.g., speakers,
headphones) or a headset with microphone.
Indicates the computer's power status.
Indicates the computer's battery status.
Charging: The light shows amber when the
battery is charging.
Fully charged: The light shows blue when in AC
mode.
Description
Connects to USB devices with a USB Type-C
connector.
Supports DisplayPort™ over USB-C™.
Connects to USB devices.
Connects to USB devices.
Supports high-definition digital video connections.
Connects to an AC adapter.
1 2 3 4 5
7
