Foream X1 User Manual

User Manual

Maintenance

Thanks for Purchasing the
Foream X1 wearable sport camera
Customer Service & Support:
• Please visit our website for the latest software, user support, product
information and shared videos.
• If you have any issue or suggestion, please send an e-mail to our customer
support team: support@foream.com
To enjoy our warranty services, please register your product on our website
www.foream.com

Start Using

Camera
Please charge the camera before the first use of it.
Charge the Camera
• Take out the camera and the Micro-USB cable.
• Connect the USB cable to computer to start charging the camera;
• During charging, if the battery is not fully charged, the battery indicator lamp blinks green
twice successively; but if the battery is fully charged, the indicator lamp keeps green lighted
on.
Install Micro SD Card
• Open the USB lid on Micro SD card slot;
• Insert a Micro SD/SDHC card with Class 6 or higher (max memory of 32 GB) in the
direction of sign on the camera and push the lid until it is closed.
• Put on the USB slot protection cover.
• Do not apply or remove the Micro SD card during the camera is switched on.
Use the Camera
• Be sure the battery is fully charged and Micro SD card is inserted before using the
camera.
• Press and hold the power/mode button for a while to turn on the camera.
• When the camera is on, press the power/mode button once to convert its shooting mode.
• The shooting modes include Video, Photo, and Timelapse shooting mode;
• After choosing the video shooting mode, press the shooting button to start recording or
shooting. Press it again to stop.
• When the Photo mode is chosen, press the shooting button once to take photo.
Use WIFI
When the camera starts up but doesn't start recording or shooting, press WIFI button once
to turn on or off WIFI.
Version: X1-CHI-EN-v1001

Camera Specification

Resolution Ratio: 1080P/30FPS 720P/30FPS
Video Format: .MP4 (H.264 Codec)
Sensor: CMOS
Dept of Field: 0.8 Meter - Infinite
Angle of Lens (Opposite Angle): 87°
Pixel: 8 Megapixel
Microphone: Built-in Microphone
USB: Micro-USB
External Memory: Micro SD, SDHC MAX Memory 32 GB
Compatibility: Windows 7 or above/MAC OSX10.5 or above
Size: 176.5X174.8X27mm (Belt not include)
Weight: 97g
Power Supply: Built-in Lithium Battery, 1160 mAh
Shooting Time: Continuous 180 Minutes of HD Video Shooting after Full-charged

Package Include

Camera
Magic Stripe
User Manual Camera Bag

Wearing Method

Positioning
Magic Stripe
Magic Stripe Position
Lens in Middle, Correct
USB Facing Bottom, Correct
Micro USB Cable
Camera
Not Balance, Wrong USB Facing Up, Wrong
