Caswell CAR-5050 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

CAR-5050
User Manual
Revision: 0.1
CAR-5050 Series User`s Manual
http://www.cas-well.com
Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com
Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CAR-5050 and is the answer not in the manual?

Questions and answers

Related Manuals for Caswell CAR-5050

Summary of Contents for Caswell CAR-5050

  • Page 1 CAR-5050 User Manual Revision: 0.1 CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
  • Page 2 E) Reliable Ear thing Reliable ear thing of rack-mounted equipment should be maintained. Particular attention should be given to supply connections other than direct connections to the branch circuit (e.g. use of power strips). CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com...

  • Page 3: Table Of Contents

    REMOVE LOM MODULE ........................... 33 3.13 REMOVE POWER SUPPLY ..........................34 3.14 REMOVE MAIN BOARD ............................ 35 CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
  • Page 4 BOOT ................................44 SAVE & EXIT ..............................44 BIOS STATUS ABD BEEP CODE .......................... 45 CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.

  • Page 5: Chapter 1 Preview

    Chapter 1 Preview 1.1 About This Manual This manual contains all necessary information for configuration and testing of CAR-5050. The CAR-5050 is based on the Intel® Skylake-SP series processors. If there is any information not included, please contact your sales person at CASwell.

  • Page 6: Chapter 2 Introduction

    Based on CASwell NIC Module or Standard add-on card Expansion Up to 5 PCIe Gen3 x 16 for CASwell NIC Module Up to 1 PCIe Gen3 x 8 for CASwell NIC Module Up to 1 PCIe Gen3 x 8 for Standard NIC Module Storage Device 2x 3.5”or2.5”...
  • Page 7 Intel® Xeon® SP Silver 4114/4114T 10C/20T 2.2GHz 13.75MB Intel® Xeon® SP Silver 4110 8C/16T 2.1GHz 11MB CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.

  • Page 8: Jumper Setting

    8C/8T 1.7GHz 11MB 2.2.2 System Block Diagram 2.3 Jumper Setting CAPB-5050 ˙Components Map TOP Layer CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
  • Page 9 CPU SOCKET CPU0 CPU1 DIMM SOCKET CPU0 CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
  • Page 10 SATA Port 1 (6Gb/s) or SATA DOM SATA Port 0 (6Gb/s) TPM Header SATA Port 2 (6Gb/s) M.2 PCIex4 Connector CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
  • Page 11 SATA Port 3 (6Gb/s) J54/J57/J58 NIP Module Fan J55/J56 Upper Layer NIP Connector USB3.0 Header PCI-E Slot C x16 (CASwell NIP)-CPU0 PCI-E Slot E x16 (CASwell NIP)-CPU1 PCI-E Slot G x16 (CASwell NIP)-CPU1 J65/J76 Manager Board Slot BT module Header...
  • Page 12 2 4 6 8 10 1 3 5 7 9 Pin No. Signal Description Pin No. Signal Description DDC_CLOCK CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
  • Page 13 J54/J57/J58：NIP Module Fan 1 2 3 Pin No. Signal Description  J7/J8/J5/J6：Smart Fan 1 2 3 CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
  • Page 14 1 3 5 7 9 Pin No. Signal Description Pin No. Signal Description GP67 GP60 GP66 GP61 GP65 GP62 CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
  • Page 15 ˙Components Map TOP Layer Jumper & Connector List Connector Function Remark Power connector PCI-E Slot B x16 (CASwell NIP)-CPU0 PCI-E Slot D x16 (CASwell NIP)-CPU0 PCI-E Slot F x16 (CASwell NIP)-CPU0 J10/J11 Board to Board Connector ABM-5050-0 CAR-5050 Series User`s Manual http://www.cas-well.com...
  • Page 16 ˙Components Map TOP Layer BOT Layer CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
  • Page 17 USB 3.0 Connector Management Port 01 RJ45 Management Port 02 RJ45 IPMI connector ( RJ45 Interface ) CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.

  • Page 18: The Chassis

    The system is integrated in a customized 2U chassis . on the front panel you will find , two LAN port , two types of console port(default baud rate 115200), two USB ports, one IPMI port, one NIC module, and six LAN module slot. CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com...
  • Page 19 CAR-5050 Front view of the chassis CAR-5050 Rear view of the chassis CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.

  • Page 20: Open The Chassis

    1. Loosen the 12 screws of the chassis. Take off screws 2. The top lead can be removed from the base stand CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.

  • Page 21: Remove Processor

    Step 3:Remove processor from processor clip. Step 4:You can change the processor. CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.

  • Page 22: Install Processor

    Step1: Processor triangle mark & processor clip trangle should be the same direction . Step 2:Put processor clip on heatsink and press down. Step 3: Processor clip trangle & heatsink NO.2 should be the same direction. CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com...
  • Page 23 ※ Need use star screwdriver. T=30 Step4:Install 1,2->3,4 CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.

  • Page 24: Remove And Install Dimm

    3. Firmly insert the DIMM into the socket until the retaining clips snap back in place and the DIMM is properly seated CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
  • Page 25 Follow these steps to remove a DIMM: 1. Simultaneously press the retaining clips outward to unlock the DIMM CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.

  • Page 26: Remove And Install Compact Flash Card

    2. The completed installation of Compact Flash Card is shown as Completion of Compact Flash Card connection CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.

  • Page 27: Remove And Install Battery

    3.7 Remove And Install Battery Eject the battery Restore the battery CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.

  • Page 28: Remove And Install Add-On Card

    3.8 Remove and Install And-on Card The system is equipped with one of CASwell LAN module bays. Note: Please be sure to un-plug the power cord before fix or exchange the CASwell NIP Module. Step 1. Remove the tray from the bay of hand spin Step 2.

  • Page 29: Ear Mount Kit Installation

    3.9 Ear Mount Kit Installation The CAR-5050 series shipped with 2 ear mount kits. The following is the installation instruction of these ear mounts: Step 1. Step2. Step3.Finish CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com...

  • Page 30: Remove Ezio

    3.10 Remove EZIO Step 1. Loosen this screw. Step 2. Step 3. Finish CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
  • Page 31 3.11 Remove HDD Step 2.Pull out the HDD. Step 1. Step 3. Finish CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.

  • Page 32: Remove Hdd Tray

    Step 2: Loosen 4 screws on left side. Step 3. Loosen this screw & remove sata cables. Step 4 Finish CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.

  • Page 33: Remove Lom Module

    3.13 Remove LOM Module Step 1.Loosen 2 screws Step 2: CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.

  • Page 34: Remove Power Supply

    Step 4 Remove power on board cables. Step 5.Loosen 4 screws. Step 6.Loosen 2 screws on chassis bottom. CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
  • Page 35 Step 7.Finish CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.

  • Page 36: Remove Main Board

    Step 1. Remove EZIO guide groove bracket screws. Step 2. Remove the screws. Step 3. Finish CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
  • Page 37 Step 5. Finish Step 6. Remove Fan module. Step 7. Remove all of the screws & Copper pillar from main board. CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
  • Page 38 Step 8. Finish CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
  • Page 39 CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.

  • Page 40: Chapter 4 Bios Settings

    Restore previous BIOS item setting value <F3> Restore optimized default value <F4> Execute Save and Reset <ESC> Execute Exit CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.

  • Page 41: Main

    Display system date and allow you change the system date. System Time Display system time and allow you change the system time. CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.

  • Page 42: Advanced

    Configure the Network Stack settings. CSM Configure Configure the Option ROM execution settings. NVMe Configure Configure NVMe Device. CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
  • Page 43 Enables or Disables system ability to Hibernate. Lock Legacy Resources Enables or Disables Lock of Legacy Resources. CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
  • Page 44 Enable or Disable Serial Port (COM). Change Settings Select an optimal setting for Super IO Device. CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
  • Page 45 Fan Speed Control Mode Configure Fan Speed Control Mode. ˙4.3.5 Serial Port Console Redirection Console Redirection CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
  • Page 46 If system has SR-IOV capable PCIe Devices, this option Enables or Disables Single Root IO Virtualization Support. ˙4.3.7 Network Stack Network Stack Enable/Disable UEFI Network Stack. CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
  • Page 47 Control the execution of UEFI and Legacy Storage OpROM. Video Control the execution of UEFI and Legacy Video OpROM. Other PCI devices CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
  • Page 48 ˙4.3.9 NVMe Configruation Display NVMe device info if system have plug the device ˙4.3.10 USB Configuration CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
  • Page 49 Maximum time the device will take before it properly reports itself to the Host Controller. 'Auto' uses default value: for a Root port it is 100ms, for a Hub port the delay is taken from Hub descriptor. CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com...
  • Page 50 ˙4.4.1 PCH Configuration AC Power Loss Determines the state of the system after the return of power from an AC power loss. CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
  • Page 51 PCI Express Root Port PCIE root port Enable/Disable. PCIE ASPM PCIE root port ASPM setting. L1 Substates CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
  • Page 52 SATA RSTe Boot Info Enable setting provides full int13h support for SATA controller attached devices. CSM storage OPROM policy should be set to legacy to make this selection effective. CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com...
  • Page 53 Enable/Disable all USB 3.0 pins or on a per pin basis. USB 3.0 pin #X Enable/Disable this US3.0 pin. ˙4.4.2 Server ME Configuration CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
  • Page 54 Displays and provides option to change the UPI Settings. Memory Configuration Displays and provides option to change the Memory Settings. CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
  • Page 55 Advanced Power Management Configuration Displays and provides option to change the Power Management Settings. ˙4.5.1 Processor Configuration CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
  • Page 56 LLC Prefetcher LLC (hardware cache) prefetching on all threads will be supported. Extended APIC CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
  • Page 57 Isochronous support to meet QoS (Quality of Service) requirements. Numa Enable or Disable Non uniform Memory Access (NUMA). ˙4.5.3 UPI Configuration CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
  • Page 58 IODC (I/O Directory Cache) to generate snoops instead of generating memory lockups for remote IIO (InvIToM) and/or WCiLF (Cores). ˙4.5.4 Memory Configuration Memory Frequency CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
  • Page 59 PCIE Max Read Request Size Selection Pcie Relaxed Ordering Enable/Duisable PCIE Relaxed Ordering 4.5.5.1 Socket0/1 Configuration CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
  • Page 60 Socket 0/1 PcieBrxD0xFx – Port x Settings related to PCI Express Ports (0/1A/1B/1C/1D/2A/2B/2C/2D/3A/3B/3C/3D) 4.5.5.1.1 Socket 0/1 PcieBrxD0xFx – Port x CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
  • Page 61 Select No in this item for TLP Processing Hint support, which will allow a "TPL request" to provide "hints" to help optimize the processing of each transaction occurred in the target memory space. CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com...
  • Page 62 Coherency Support (Non-Isoch) Enable/Disable Non-Isoch VT_D Engine Coherency support. CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
  • Page 63 If this feature is set to Native Mode, hardware will choose a P-state setting based on OS guidance. If this feature is set to Native Mode with No Legacy Support, hardware will choose a P-state setting independently without OS guidance. CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com...
  • Page 64 Enhanced Halt State (C1E) Enable "Enhanced Halt State" support, which will significantly reduce the CPU's power consumption by minimizing CPU's clock cycles and reduce voltage during a "Halt State. CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com...
  • Page 65 Enable/Disable interfaces to communicate with BMC. IPMI BMC Reset to def System BIOS will set IPMI BMC to default seting value on next boot CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
  • Page 66 4.7 Security Administrator Password Set Administrator Password. CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.

  • Page 67: Boot

    Enables or disables Quiet Boot option. Boot mode select Select the type of devices to be used for system boot. CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.

  • Page 68: Save & Exit

    Restore/Load Default values for all the setup options. 4.10 BIOS status codes ˙BIOS status codes PEI Phase Code Description 0x10 PEI_CORE_STARTED CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
  • Page 69 PEI_MEMORY_NOT_DETECTED 0x53 PEI_MEMORY_NONE_USEFUL 0x54 PEI_MEMORY_ERROR 0x55 PEI_MEMORY_NOT_INSTALLED 0x56 PEI_CPU_INVALID_TYPE 0x56 PEI_CPU_INVALID_SPEED 0x57 PEI_CPU_MISMATCH 0x58 PEI_CPU_SELF_TEST_FAILED CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
  • Page 70 DXE_PCI_BUS_HPC_INIT 0x94 DXE_PCI_BUS_ENUM 0x95 DXE_PCI_BUS_REQUEST_RESOURCES 0x96 DXE_PCI_BUS_ASSIGN_RESOURCES 0x97 DXE_CON_OUT_CONNECT 0x98 DXE_CON_IN_CONNECT 0x99 DXE_SIO_INIT 0x9A DXE_USB_BEGIN CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
  • Page 71 DXE_SB_ERROR 0xD3 DXE_ARCH_PROTOCOL_NOT_AVAILABLE 0xD4 DXE_PCI_BUS_OUT_OF_RESOURCES 0xD5 DXE_LEGACY_OPROM_NO_SPACE 0xD6 DXE_NO_CON_OUT 0xD7 DXE_NO_CON_IN 0xD8 DXE_INVALID_PASSWORD 0xD9 DXE_BOOT_OPTION_LOAD_ERROR CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
  • Page 72 Indicate that MRC is complete 0x2A No memory found 0xE8 No memory to map 0xEB Memory Test Failed CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
  • Page 73 Invalid DIMM SPD contents 0xEE Un-support DIMM detect 0xEF~0xFA Memory initial failed End of File CAR-5050 Series User`s Manual http://www.cas-well.com Tel: 02-7705-8888 Fax: 02-7731-9988 E-mail: info@ cas-well.com Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
