Summary of Contents for Liquid Controls SP711-3
- Page 1 INSTALLATION & OPERATION MANUAL SP711-3 REV. A 3-Wire Analog Transmitter DOC#: MN-711-3-A.doc...
-
Page 2: Specifications
The sensitivity adjustment permits the SP711-3 to discriminate between a signal input or noise by increasing (CCW) or decreasing (CW) the input signal amplitude necessary to be processed as a valid signal. This in conjunction with direct meter mounting allows the SP711-3 to operate effectively in noisy environments. - Page 3 SP711-3 3-Wire Analog Transmitter pg 3 Sponsler, Inc. DOC#: MN-711-3-A BENCH TEST CALIBRATION PROCEDURE Required Equipment: Power Supply 12-28VDC, Digital Multimeter (DMM), Frequency Generator, & Frequency Counter Refer to Figure Test Procedure: Connect DMM positive & negative leads to J1-3,4 respectively & set DMM function to DC Volts Connect power supply positive &...
- Page 4 SP711-3 3-Wire Analog Transmitter pg 4 Sponsler, Inc. DOC#: MN-711-3-A DATE REVISION RECORD AUTH F/S FREQUENCY RANGE SELECT JU1: 1875-10,000 Hz JU2: 350-1950 Hz JU3: 75-375 Hz TERMINAL LOCATION ANALOG 3.00 DIA. SIGNAL IN + OUTPUT SIGNAL IN – SELECT ANALOG OUT + ANALOG OUT –...
