Denon Professional DN-X1500 Service Manual

Hide thumbs

Table of Contents

Quick Links

MODEL

DN-X1500

DN-X1500S

●

For purposes of improvement, specifications and

design are subject to change without notice.

Please use this service manual with referring to the

●

operating instructions without fail.

Some illustrations using in this service manual are

●

slightly different from the actual set.

SERVICE MANUAL

DJ MIXER

サービスをおこなう前に、このサービスマニュアルを

必ずお読みください。本機は、火災、感電、けがなど

に対する安全性を確保するために、さまざまな配慮を

おこなっており、また法的には「電気用品安全法」に

もとづき、所定の許可を得て製造されております。

従ってサービスをおこなう際は、これらの安全性が維

持されるよう、このサービスマニュアルに記載されて

いる注意事項を必ずお守りください。

PROFESSIONAL BUSINESS COMPANY

TOKYO, JAPAN

注意

本機の仕様は性能改良のため、予告なく変更すること

●

があります。

補修用性能部品の保有期間は、製造打切後 8 年です。

●

修理の際は、必ず取扱説明書を参照の上、作業を行っ

●

てください。

本文中に使用しているイラストは、説明の都合上現物

●

と多少異なる場合があります。

Ver. 3

Please refer to the

MODIFICATION NOTICE.

E2A E1C EUT

X0196V.03 DE/CDM 0711

Table of Contents

Need help?

Do you have a question about the DN-X1500 and is the answer not in the manual?

Questions and answers

Summary of Contents for Denon Professional DN-X1500

Page 1 Ver. 3 Please refer to the MODIFICATION NOTICE. SERVICE MANUAL MODEL E2A E1C EUT DN-X1500 DN-X1500S DJ MIXER 注意サービスをおこなう前に、このサービスマニュアルを必ずお読みください。本機は、火災、感電、けがなどに対する安全性を確保するために、さまざまな配慮をおこなっており、また法的には「電気用品安全法」にもとづき、所定の許可を得て製造されております。従ってサービスをおこなう際は、これらの安全性が維持されるよう、このサービスマニュアルに記載されている注意事項を必ずお守りください。 ● For purposes of improvement, specifications and 本機の仕様は性能改良のため、予告なく変更すること ● design are subject to change without notice.
Page 2: Safety Precautions
DN-X1500/DN-X1500S SAFETY PRECAUTIONS The following check should be performed for the continued protection of the customer and service technician. LEAKAGE CURRENT CHECK Before returning the unit to the customer, make sure you make either (1) a leakage current check or (2) a line to chassis resistance check.
Page 3 DN-X1500/DN-X1500S DISASSEMBLY 各部のはずしかた (Follow the procedure below in reverse order when reassem- （組み立てるときは、逆の順序で行ってください。） bling.) 1. Top Panel Unit 1. Top Panel Unit (1) Remove 9 side screws and pull up the Top Panel Unit. (1) 側面側からネジを 9 本はずし、Top Panel Unit を引き出...
Page 4 DN-X1500/DN-X1500S 3. CH Fader Unit 3. CH Fader Unit (1) Remove 4 knobs. (1) ノブ 4 個をはずします。 (2) Remove 4 screws and pull up CH Fader Panel. (2) ネジ 4 本をはずし、CH Fader Panel を引き出します。 (3) Remove 2 screws for each CH.
Page 5: Cross Fader
DN-X1500/DN-X1500S ADJUSTING THE MOVEMENT OF THE CROSS FADER つまみの動き調整 CROSS FADER CONTROL (1) Move the Cross Fader control all the way to the end in the (1) Cross Fader つまみを矢印の方向一杯に移動します。 direction of the arrow. (2) Turn Cross Fader screw A gently using the adjustment (2) Cross Fader のネジ...
Page 6 DN-X1500/DN-X1500S SERVICE MODE SPECIFICATION サービスモード仕様 * How the product performs when the operation buttons for μcom control are pressed (including control input) is described in the * 以下にマイコンを制御する操作ボタンが押された（外部制御入力も含む）時の本体の動作について記載します。 table below. 1. POWER ON 1. POWER ON 機能詳細表示備考...
Page 7 DN-X1500/DN-X1500S 5. SAMPLER ASSIGN switch 5. SAMPLER ASSIGN switch Function Description Display Remarks 機能詳細表示備考 When CROSSFADER ASSIGN switch is set to ①Refer to CROSSFAER ASSGIN. FADER VR CROSS FADEASSIGN スイッチが POST 側に設定 ① CROSSFAER ASSGIN を参照 FADER VR POST, you can check the fader VR and LED.
Page 8 DN-X1500/DN-X1500S SEMICONDUCTORS Only major semiconductors are shown, general semiconductors etc. are omitted to list. 主な半導体を記載しています。汎用の半導体は記載を省略しています。 IC's ● MN102H74D (IC101) MN102H74D Terminal Function Pin Name Symbol I/O DET Ext Res Ini Function P50,WAIT _WAIT HI R/W timing wait signal P51,_RE Read signal...
Page 9 DN-X1500/DN-X1500S Pin Name Symbol I/O DET Ext Res Ini Function 39 P40,A16 Hi-z Address bus 40 P41,A17 Hi-z Address bus 41 P42,A18 Hi-z Address bus Address bus 42 P43,(TM2IO),A19 Need pull up to extension for DSP boot control 43 Vss...
Page 10: Top View
DN-X1500/DN-X1500S TMP86CM47U (IC301) TOP VIEW TMP86CM47U Terminal Function Pin No. Pin Name Symbol I/O DET Ext Res Ini Function GND (0V) Oscillation input 16MHz XOUT XOUT Oscillation output TEST TEST Fixed to GND Power (+5.0V) ADR1 Address decode signal 1...
Page 11 DN-X1500/DN-X1500S ADSST-MEL100 (DSP:IC101) TOP VIEW BOTTOM VIEW ADSST-MEL100 Terminal Function Pin Name Pin Name Pin Name Pin Name Pin Name 1 NC 1 TRST_ 1 TMS 1 TD0 1 FLAG10 2 BMSTR 2 TDI 2 EMU_ 2 TCK 2 RESET_...
Page 12: Block Diagram
DN-X1500/DN-X1500S 128M-SDRAM (DSP:IC102) DQ15 DQ14 DQ13 DQ12 DQ11 DQ10 DQM0 DQM1 CAS# RAS# DQM2 DQM3 DQ16 DQ31 DQ17 DQ30 DQ18 DQ29 DQ19 DQ28 DQ20 DQ27 DQ21 DQ26 DQ22 DQ25 DQ23 DQ24 Note: The # symbol indicates signal is active LOW.
Page 13 DN-X1500/DN-X1500S 128M-SDRAM Terminal Function Pin NO. Symbol Type Description Clock Clock Enable Chip Select 17, 18, 19 WE#, CAS#, RAS# Command Inputs 16, 71, 28, 59 DQM0-DQM3 Input/Outout Mask 22, 23 BA0, BA1 Bank Address Input(s) 21, 24-27, 60-66 A0-A11...
Page 14: Functional Block Diagram
DN-X1500/DN-X1500S AD1838A (IC401,501) DVDD DVDD DBCLK CLATCH DLRCLK DAUXDATA AGND OUTLN1 AGND AD1838A TOP VIEW OUTLP1 (Not to Scale OUTRN1 OUTRP1 AGND AGND AVDD AVDD OUTLN2 OUTRP3 OUTLP2 OUTRN3 PIN FUNCTION DESCRIPTIONS Input/ Pin No. Mnemonic Output Description 1, 39 DVDD Digital Power Supply.
Page 17 DN-X1500/DN-X1500S PCM1804 (IC301,305,309,313) OSR0 SCKI CLK Control OSR1 AGNDL AGNDR OSR2 Delta-sigma Decimation Modulator (L) Filter (L) FMT0 FMT1 AGNDL LRCK/ FMT0 AGND DSDBCK Serial TOP VIEW BCK/DSDL FMT1 Output DATA/DSDR Interface OVFL AGNDR OSR0 OVFR OVFL OSR1 Decimation Delta-sigma...
Page 20 DN-X1500/DN-X1500S M66005AFP (IC201) D I G D I G D I G D I G D I G D I G D i s p l a y C o d e R e g i s t e r...
Page 24: Printed Wiring Board
PRINTED WIRING BOARD DN-X1500/DN-X1500S GU-3591 MAIN / POWER P.W.B. UNIT ASS’Y COMPONENT SIDE...
Page 25 DN-X1500/DN-X1500S GU-3591 MAIN / POWER P.W.B. UNIT ASS’Y FOIL SIDE...
Page 26 DN-X1500/DN-X1500S GU-3592 P.uCOM / INPUT P.W.B. UNIT ASS’Y COMPONENT SIDE...
Page 27 DN-X1500/DN-X1500S GU-3592 P.uCOM / INPUT P.W.B. UNIT ASS’Y FOIL SIDE...
Page 28 DN-X1500/DN-X1500S GU-3593 P.VR P.W.B. UNIT ASS’Y COMPONENT SIDE...
Page 29 DN-X1500/DN-X1500S GU-3593 P.VR P.W.B. UNIT ASS’Y FOIL SIDE...
Page 30 DN-X1500/DN-X1500S GU-3594 DSP P.W.B. UNIT ASS’Y COMPONENT SIDE GU-3594 DSP P.W.B. UNIT ASS’Y FOIL SIDE...
Page 31: Note For Parts List
DN-X1500/DN-X1500S NOTE FOR PARTS LIST 部品表について • Part indicated with the mark "nsp" are not always in stock and possibly to １．nsp 印の部品は常時在庫していませんので供給に長時間を要すること take a long period of time for supplying, or in some case supplying of part があります。 may be refused.
Page 32 DN-X1500/DN-X1500S PARTS LIST OF P.W.B. UNIT ASS'Y Note: The symbols in the column ”Remarks” indicate the following destinations. E3 : U.S.A., & Canada model GU-3591 MAIN / POWER P.W.B. UNIT ASS’Y E2 : Europe model JP : Japan model Ref. No.
Page 33 DN-X1500/DN-X1500S Ref. No. Part No. Part Name Remarks RESISTORS GROUP R713,714 00D 241 2377 918 RD14B2E750JNBST R731,732 00D 241 2377 918 RD14B2E750JNBST R805,806 00D 244 2052 973 RS14B3A561JNBST(S) R813,814 00D 244 2051 961 RS14B3A101JNBST(S) R835 00D 244 2052 973 RS14B3A561JNBST(S)
Page 34 DN-X1500/DN-X1500S Ref. No. Part No. Part Name Remarks C355-358 00D 257 0506 951 CC73CH1H101JT C359,360 00D 257 0509 929 CK73B1H102KT C365,366 00D 257 0511 904 CK73F1H103ZT C367,368 00D 254 4538 900 CE04W1C100MT SMG/RE3 C369,370 00D 257 0512 903 CK73F1E104ZT C371,372...
Page 35 DN-X1500/DN-X1500S Ref. No. Part No. Part Name Remarks C481 00D 254 4538 900 CE04W1C100MT SMG/RE3 C482 00D 257 0509 929 CK73B1H102KT C483 00D 254 4538 900 CE04W1C100MT SMG/RE3 C484 00D 254 4538 913 CE04W1C220MT SMG/RE3 C485,486 00D 257 0512 903...
Page 36 DN-X1500/DN-X1500S Ref. No. Part No. Part Name Remarks C703,704 00D 257 0511 904 CK73F1H103ZT C705,706 00D 257 0504 982 CC73CH1H470JT C707,708 00D 254 4522 958 CE04W1V101MT SMG/RE3 C709,710 00D 257 0509 929 CK73B1H102KT C711,712 00D 254 4541 939 CE04W1E470MT SMG/RE3...
Page 37 DN-X1500/DN-X1500S Ref. No. Part No. Part Name Remarks C951-958 00D 257 0509 929 CK73B1H102KT OTHER PARTS GROUP AS106 00D 417 0532 006 RADIATOR AS901,902 00D 417 0476 036 RADIATOR CX041 00D 205 0343 045 4P CONN.BASE(KR-PH) CX081 00D 205 1296 007 8P FFC CON.BASE...
Page 38 DN-X1500/DN-X1500S GU-3592 P.uCOM / INPUT P.W.B. UNIT ASS’Y Ref. No. Part No. Part Name Remarks SEMICONDUCTORS GROUP IC201 00D 262 3228 908 M66005AFP IC301 00D 262 3359 000 TMP86CM47U-5FH5 IC302,303 00D 262 1708 909 TC74HC138AF(TP1) IC305 00D 262 3335 901...
Page 39 DN-X1500/DN-X1500S Ref. No. Part No. Part Name Remarks C330 00D 257 0512 903 CK73F1E104ZT C331 00D 254 4302 958 CE04W1A470MT(SRE) C332 00D 257 0512 903 CK73F1E104ZT C333 00D 254 4302 958 CE04W1A470MT(SRE) C334 00D 257 0511 904 CK73F1H103ZT C335,336 00D 257 0512 903...
Page 40 DN-X1500/DN-X1500S Ref. No. Part No. Part Name Remarks C539,540 00D 257 0502 971 CC73CH1H5R0CT C541,542 00D 257 0512 903 CK73F1E104ZT C545,546 00D 257 0512 903 CK73F1E104ZT C547,548 00D 254 4524 985 CE04W1H100MT SMG/RE3 C549,550 00D 254 4524 998 CE04W1H220MT SMG/RE3...
Page 41 DN-X1500/DN-X1500S Ref. No. Part No. Part Name Remarks FB301,302 00D 235 0130 903 CHIP EMIFIL(11A121) FB601,602 00D 235 0130 903 CHIP EMIFIL(11A121) FL201 00D 393 8074 008 FL TUBE (16-ST-73GN) FL201 00D 393 8074 105 FL TUBE (16-ST-73GN) for DN-X1500S E2 only...
Page 42 DN-X1500/DN-X1500S GU-3593 P.VR P.W.B. UNIT ASS’Y Ref. No. Part No. Part Name Remarks SEMICONDUCTORS GROUP IC401-404 00D 269 0220 007 GP1S094HCZ(JP) IC701-704 00D 262 3335 901 BU2152FS IC705-708 00D 262 3336 900 TC4051BF D701-715 00D 276 0560 901 DAN202KT146 LD701...
Page 43 DN-X1500/DN-X1500S Ref. No. Part No. Part Name Remarks CAPACITORS GROUP C401-404 00D 257 0512 903 CK73F1E104ZT C701 00D 257 0512 903 CK73F1E104ZT C702 00D 254 4302 958 CE04W1A470MT(SRE) C703 00D 257 0512 903 CK73F1E104ZT C704 00D 254 4302 958 CE04W1A470MT(SRE)
Page 44 DN-X1500/DN-X1500S GU-3594 DSP P.W.B. UNIT ASS’Y Ref. No. Part No. Part Name Remarks SEMICONDUCTORS GROUP IC101 00D 262 3245 004 ADSST-MEL100-DVD IC102 00D 262 3307 007 128M SDRAM(32B TSOP) IC103-105 00D 262 2640 901 SN74LV245APW-EL2 IC106 00D 262 2959 906...
Page 45: Exploded View
EXPLODED VIEW DN-X1500/DN-X1500S WARNING: Parts marked with this symbol ! have critical characteristics. Use ONLY replacement parts recommended by the manufacturer. ! 印の部分は安全を維持するために重要な部品です。従って、交換時は必ず指定の部品を使用してください。...
Page 46: Parts List Of Exploded View
FOOT SHEET 00D 449 0077 050 CARD SPACER (H=10) 00D 412 5075 000 RADIATOR 00D GEN 6583 F.CAUTION LABEL DN-X1500 for E3 ★ 00D 105 1448 005 BACK PANEL DN-X1500 for E3 00D 105 1448 018 BACK PANEL DN-X1500 for E2...
Page 47 00D 112 0925 006 SENSOR LEVER 00D 112 0928 100 BLIND SHEET 00D 144 2870 004 CH FADER PANEL for DN-X1500 00D 144 2989 102 CH FADER PLATE DN-X1500S for Silver color model 00D 144 2989 115 CH FADER PLATE...
Page 48: Packing View
WARRANTY (COM.) for E3 00D 515 0919 208 GUARANTEE(S) SUB ASS’Y for JP 00D 511 4143 007 INST.MANUAL DN-X1500 for E2, E3 00D 511 4516 003 INST.MANUAL DN-X1500S for E2, E3 00D 511 4517 002 INST.MANUAL DN-X1500S for JP 00D 515 0923 207 S.S.LIST COM.(EX)
Page 49 BLOCK DIAGRAM AUDIO PART DN-X1500/DN-X1500S MASTER OUT MUTE (BAL) MUTE MASTER OUT MUTE (UNBAL) SIG. SELECTOR TC9273N-004 E.VOL MUTE BOOTH OUT RIAA TC94A32F A/D CONV. PHONO 1/ D/A CONV. PCM1804 PCM1791ADBR LINE 1 REC OUT MUTE LINE 2 CODEC (MASTER) SIG.
Page 50 BLOCK DIAGRAM SYSTEM PART DN-X1500/DN-X1500S D/A CONV. MASTER OUT (XLR) PCM1791ADB SIG.SELECTOR PHONO1/ E.VOL A/D CONV. CODEC TC9273N LINE1 TC94A32F PCM1804 (MASTER) MASTER OUT -004 RESET IC (RCA) AD1838AAS SN74LV02APW PST600C LINE2 SIG.SELECTOR PHONO2/ E.VOL A/D CONV. SN74LV08APW BOOTH OUT...
Page 51: Level Diagram
LEVEL DIAGRAM DN-X1500/DN-X1500S...
Page 52: Wiring Diagram
WIRING DIAGRAM DN-X1500/DN-X1500S GU-3593-1 P.VR UNIT GU-3592-2 INPUT UNIT CY221 CY222 CX351 CX221 CX222 CY351 CY301 1 30P SMT SOCKET 1 GND 2 +3.3V_DSP 3 A1 4 A2 5 A3 6 A4 7 A5 8 A6 9 A7 10 A8...
Page 53 DN-X1500/DN-X1500S DOCUMENTS FOR WEEE (Europe model) Details of Recycle parts (DN-X1500/DN-X1500S) ＊ You have to remove the parts that marked “WEEE Mark ◆ “ when the recycling processing. WEEE Ref. No. Part Name Material Q'ty Mark MAIN UNIT Complex ◆...
Page 54 DN-X1500/DN-X1500S WEEE Ref. No. Part Name Material Q'ty Mark KNOB (MARU) ASSIGN KNOB (MARU) CH FADER KNOB CROSSFADER KNOB 35P FFC Complex ◆ 3P VH-VH CON.CORD Complex ◆ 8P FFC (1.25) Complex ◆ 11P KR-KR RIBBON 150 Complex ◆ EMI GASKET Complex ◆...
Page 55 Exploded view of DN-X1500/DN-X1500S unit (Europe model) DN-X1500/DN-X1500S You have to remove the parts that marked “WEEE Mark ◆ ” when the recycling processing. (Europe model only)
Page 56 DN-X1500/DN-X1500S Details of Recycle parts for Power Transformer (Ref. No. 17) Ref. No. Material Ref. No. Material 12 Polybuthylene Terephtalate 13 Polyestar Tape (Spiral Form) 14 Thermal fuse Polyurethane Covered Wire / Polyestel Enameled Wire 15 Polyester combination Tape 16 Polyester Film/ Polyester Non-woven Insulating Tape...
Page 57: Note For Schematic Diagram
DN-X1500/DN-X1500S NOTE FOR SCHEMATIC DIAGRAM 配線図について 1. WARNING: 印の部品は安全を維持するために重要な部品です。 Parts marked with this symbol have critical character- 従って交換時は必ず指定の部品を使用してください。 istics. Use ONLY replacement parts recommended by the manu- facturer. 注） 2. CAUTION: 1. 指定なき抵抗値は Ω、ｋはｋΩ、M は MΩ を示す。...
Page 58 DN-X1500/DN-X1500S SCHEMATIC DIAGRAMS (1/8) SCHEMATIC DIAGRAMS (1/8) GU-3591-1 MAIN UNIT (1/3)
Page 59 DN-X1500/DN-X1500S SCHEMATIC DIAGRAMS (2/8) SCHEMATIC DIAGRAMS (2/8) GU-3591-1 MAIN UNIT (2/3)
Page 60 DN-X1500/DN-X1500S SCHEMATIC DIAGRAMS (3/8) SCHEMATIC DIAGRAMS (3/8) GU-3591-1 MAIN UNIT (3/3)
Page 61 DN-X1500/DN-X1500S SCHEMATIC DIAGRAMS (4/8) SCHEMATIC DIAGRAMS (4/8) GU-3591-2 POWER UNIT GU-3591-3 TRANS UNIT...
Page 62 DN-X1500/DN-X1500S SCHEMATIC DIAGRAMS (5/8) SCHEMATIC DIAGRAMS (5/8) GU-3592-1 P. uCOM UNIT GU-3592-3 P. SW UNIT GU-3592-4 P. uCOM UNIT...
Page 63 DN-X1500/DN-X1500S SCHEMATIC DIAGRAMS (6/8) SCHEMATIC DIAGRAMS (6/8) GU-3592-2 INPUT UNIT...
Page 64 DN-X1500/DN-X1500S SCHEMATIC DIAGRAMS (7/8) SCHEMATIC DIAGRAMS (7/8) GU-3593-1 P. VR UNIT GU-3593-2 CH FADER UNIT 1 GU-3593-3 CH FADER UNIT 2 GU-3593-4 CH FADER UNIT 3 GU-3593-5 CH FADER UNIT 4...
Page 65 DN-X1500/DN-X1500S SCHEMATIC DIAGRAMS (8/8) SCHEMATIC DIAGRAMS (8/8) GU-3594 DSP UNIT...
