- Page 1 CodeLock Installation Manual Version 1.0...
-
Page 2: Table Of Contents
Connect the cable to the Remote Node / db Sentry Controller – Step 4 ............7 Connect the lock to 3 -party Access Panel ..................8 Connect the SENSE OUT to monitor the lock position (open/closed) ............9 db CodeLock Version 1.3 Digitus Biometrics, Inc. 2017 Page 2 of 10... -
Page 3: Determining Which Lock Pawl To Use
1000-13 1000-U32 1000-28 1000-U33 1000-26 1000-U34 1000-12 1000-U35 1000-11 1000-U36 1000-51 1000-U37 1000-52 1000-U38 1000-25 1000-U39 1000-53 1000-U40 1000-54 1000-U41 1000-10 1000-U42 1000-55 1000-U43 1000-56 1000-U44 Table 1 db CodeLock Version 1.3 Digitus Biometrics, Inc. 2017 Page 3 of 10... -
Page 4: Overview
Pay particular attention to the rotation limiter. This is installed as shown depending on whether you have a right on left hand opening door. Pawl Rotation Limiter Figure 1 db CodeLock Version 1.3 Digitus Biometrics, Inc. 2017 Page 4 of 10... -
Page 5: Mount The Tie-Down Pads To The Door And Cabinet - Step 2
Ensure that the door surface is clean and free from any debris. (Using neat alcohol to clean the surface is highly recommended. Allow drying time before proceeding.) Figure 2 Remove the protective cover from each tie-down pad and situate as shown in Figure 2. db CodeLock Version 1.3 Digitus Biometrics, Inc. 2017 Page 5 of 10... -
Page 6: Route The Cable Between The Lock And The Remote Node / Db Sentry Controller Or Acm Panel - Step 3
Sentry, if using Digitus a controller. If connecting to a third party access control panel, connect a network cable to RJ- 45 coupler and run back to panel. Figure 3 db CodeLock Version 1.3 Digitus Biometrics, Inc. 2017 Page 6 of 10... -
Page 7: Connect The Cable To The Remote Node / Db Sentry Controller - Step 4
Side View of db Sentry It is recommended that for a cabinet with 2 doors, the front door is connected to Dev 1 and the back door is connected to Dev 2. db CodeLock Version 1.3 Digitus Biometrics, Inc. 2017 Page 7 of 10... -
Page 8: Connect The Lock To 3 Rd -Party Access Panel
-party Access Panel Orange/White – GND, Ground Orange – LOCK CTRL. Requires a 12V (24V if a 24V version of the db CodeLock was purchased) control line to unlock the handle Green/White – RED LED. Connect to the Red LED output on the 3 -party panel Blue –... -
Page 9: Connect The Sense Out To Monitor The Lock Position (Open/Closed)
Connect the SENSE OUT to monitor the lock position (open/closed) If the 3 -party Access Panel requires a 2-wire input to monitor the door positions, an external relay is required. Connect as follows: db CodeLock Version 1.3 Digitus Biometrics, Inc. 2017 Page 9 of 10... - Page 10 Digitus Biometrics, Inc. 2 East Bryan Street, Suite 502 Savannah, GA 31401 USA Phone: 912-231-8175 Fax: 912.629.9478 www.digitus-biometrics.com support@digitus-biometrics.com Specifications subject to change without notice. db CodeLock Version 1.3 Digitus Biometrics, Inc. 2017 Page 10 of 10...
