Summary of Contents for MRKT-IT RTA-888

  • Page 2: Table Of Contents

    Directory FUNCTIONAL CHARACTERISTIC ............- 1 - ................. - 1 - 1.1 P RODUCT VERVIEW ................- 2 - 1.2 P RODUCT FEATURES ..............- 3 - 1.3 T ECHNICAL PARAMETERS PRODUCT DIAGRAM ..............- 4 - III. ICON IDENTIFICATION ..............- 6 - OPERATING INSTRUCTIONS ............
  • Page 3 5.2.6 Naming Rules for the files ............- 33 - ....................- 34 - PHOTO ................- 37 - 5.4 A UDIO AND VIDEO ....................- 43 - 5.5 A UDIO ) ......- 44 - 5.6 T ELEPHONE ONLY SUPPORTED BY VERSION .
  • Page 4 Introduction This equipment is applicable to workplaces such as railway, oil field, power, machinery, petrochemical, gas overhaul, military use, fire, police, urban management, industrial and mining enterprises, etc. It is efficient, practical and intelligent equipment integrating the functions of lighting, video, photography, positioning, and Netcom 4G networking for patrol records, maintenance, security, and patrol.

  • Page 5: Functional Characteristic

    I. Functional characteristic 1.1 Product Overview ● Operating system of Android 6.0 ● 64-bit 8-core processor, CORTEX-A53 architecture design, and 1.5GHz basic frequency ●Netcom support: 4G： TD-LTE B38/B39/B40/B41； FDD-LTE B3/B7； 3G： WCDMA B1/2/5；TD-SCDMA B34/39；2G：GSM 850/900/1800/1900 (supported by 4G only) ●WIFI network supports IEEE 802.11 n/b/g ●Standard V4.0 blue tooth ●Multi-point touch screen of industrial capacitive type, which can be operated with gloves on.

  • Page 6: Product Features

    1.2 Product features ● Highly support 128GB T-Flash Card (file format of FAT32) ●Built-in 20 million HD CMOS camera ●1.54 inch IPs HD display, shooting files can be played back at any time ●Photos can be superimposed with date, time watermark, GPS (latitude and longitude), Car No.

  • Page 7: Technical Parameters

    1.3 Technical parameters Image sensor: 1/3 CMOS Effective pixels: 20 million LENS: 3.6mm Effective angle: 120 degree Encoding: H.264 Video resolution: 1920*1080/30fps 1280*720/30fps 720*480/30fps Photo Resolution: 20M:5184*3888 13M:4096*3072 8M:3264*2448 5M:2560*1920 Video file format: MP4 Photo format: JPG Recording format: WAV Supply Battery: RTA29785A/5000mAh, RTA29140F/10000mAh Working duration of LED Flashlight along: about 24 hours Working duration of LED flashlight and video at the same time: about 8 hours...

  • Page 8: Product Diagram

    II. Product diagram - 4 -...
  • Page 9 - 5 -...

  • Page 10: Icon Identification

    III. Icon identification Photo preview mode Video preview mode Videoing Automatic flash Flash off Flash on Play file Pause GPS on WIFI Signal Strength 4G network currently (supported by 4G version) 4G network and 4G mobile data currently (supported by 4G version) 3G network currently (supported by 4G version) 3G network and 3G mobile data currently (supported by 4G version) 2G network currently (supported by 4G version)

  • Page 11: Operating Instructions

    IV. Operating Instructions 4.1 Lighting Short click the key of "(6) strong lighting"; then turn on the strong lighting mode, as shown in the following figure: Click again and switch the bright lighting to the dim light mode, as shown in the following figure: Click again, the strong light will be turned off 4.2 Signal Light...

  • Page 12: Boot

    signal is turned on. Note: operation method of the keys: If not specifically stated, the keys shall be operated as follows；select the directions (up/down/left/right) through "(3) direction key (left/top)" and "(9) direction key (right/bottom), then click "(4) Confirm key" to confirm, or click " (8) Return key "...
  • Page 13 (II). After the boot, carry out the following operation on the screen: Setting → power-on application settings → camera, wherein the boot mode is set to the camera mode, as shown in the following figure: After the boot up, the device will directly enter into the camera interface, as shown in the following figure: (III).

  • Page 14: Touch Screen

    After the boot up, the device will directly enter into the camera interface, as shown in the following figure: 4.4 Touch Screen (5) 1.54-inch IPS display is a multi-touch capacitive screen of industrial level, which can be normally operated by finger with gloves on. Please avoid letting the touch screen contact with other electronic equipment;...
  • Page 15 (I) Click To open the application, select the menu options, click the button on the screen or use the input function on the keyboard appeared on the screen; it only takes a simple click to operate, as shown in the following figure: (II) Double-click Double-click the image to enlarge it, and double-click again to go back, as shown in the following figure:...

  • Page 16: Lock Up The Screen

    (IV) Opening and closure Separating two fingers on the image can enlarge a part of the image, and closing up two fingers can shrink the image, as shown in the following figure: 4.5 Lock up the screen Click "(2) power button" to close the screen and to lock it up. In addition, if the device is not going to be used for a specified period of time, the screen will close and lock itself automatically.

  • Page 17: Mobile Network (Supported Only By 4G Edition)

    4.7 Mobile network (supported only by 4G edition) After the boot up, carry out the following operation on the screen: Setting → mobile network →click "OK" →turn on or turn off cellular data; only under the state where the mobile’s cellular data is on, the device will start to search the signal of mobile data, as shown in the following figure: 4.8 WIFI After powering up, carry out the following operation on the screen: Setting→...

  • Page 18: Bluetooth

    Select the currently available WIFI, and click the "OK" key, then the device will automatically connect the selected WIFI; after the connection is successful, "Connected" will be shown and the WIFI signal icon “ ” will appear above the screen, as shown in the following figure: 4.9 Bluetooth After the boot, carry out the following operation on the screen: Setting →...
  • Page 19 When the Bluetooth is turned on, long click "M" key and the "Nearby Bluetooth list" will be displayed, as shown in the following figure: Select the menu bar of "Nearby bluetooth list", and click "OK" key, then it will display the list of the current nearby Bluetooth; select the current visible Bluetooth device, click "OK", and the device will automatically connect the selected Bluetooth;...

  • Page 20: Gps

    4.10 GPS After the boot, carry out the following operation on the screen: Setting the →GPS Function→ click the "OK" key→ turn on or turn off the GPS Function; only in the state where GPS Function is on, the device will begin to search GPS signal, as shown in the following figure: The symbol appearing in the middle of the screen indicates that the GPS...

  • Page 21: Nfc

    The green section of the figure represents the satellite data that has been spotted, and the values on the green vertical bars indicate the signal strength of the current satellite. Note: when mobile networks, WIFI and GPS services are turned on, the battery consumption will be increased.

  • Page 22: Storage

    4.12 Storage This device is equipped with internal storage and it supports inserted T-flash card as an external storage device; you can set it up as follows： Setting → Set storage location; as shown in the following figure: This device chooses internal storage as memory by default, as shown in the following figure: If external storage device is needed, please insert a T-flash card of FAT32 format;...
  • Page 23 When the device identifies the inserted T-flash card, the prompt of “preparing SD card" will disappear; the device will automatically set the defaulted storage as "external memory only", as shown in the following figure: If the T-Flash card inserted into this device is removed or not recognized by this device, the device will automatically set the default memory to "internal storage only"...

  • Page 24: Turn Off The Device

    If you need to remove the T-Flash card, please turn off the device before removing it. Otherwise, the T-Flash card may be damaged or not recognized by the device. 4.13 Turn off the device Under any state in which the device is turned on, long click the "Power button" for two seconds, the screen will pop up the "Power off"...

  • Page 25: Device Update

    internal storage is the built-in memory of the device. The actual usable capacity of the built-in storage is less than the specified capacity, which is due to that the operating system and the default application have used up part of the memory. The available capacity may be changed when the device is updated.

  • Page 26: Take Pictures

    Note: The open-up applications of this device can be can selected by finger clicks; after selecting the intended application, click the "OK" key to start up the corresponding application. 5.1 Take pictures Start the "Camera" APP, as shown in the following figure After starting, enter the shooting preview interface, click the "OK"...
  • Page 27 Click the "M" key to return to the main screen after the picture is taken. In the upper left corner of the screen, “Estimated capacity 929 pics” is the approximate number of photographs that can be stored by this unit, based on the current memory and the current photo resolution.
  • Page 28 In a dark environment, if a strong light is turned on, the device will forcibly turn off the strong light for a few seconds while taking a picture. After the picture is taken, the device will automatically resume the bright light. (II) Focusing In the camera preview interface, you can lock the focus of the selected area.
  • Page 29 Click the "left" and "right" keys to select the photo size, click the "OK" to pop up the submenus showing 20M pixels, 13M pixels, 8M pixels and 5M pixels. Click the "left" and "right" keys to select the desired option. Click "OK" again to confirm the selection, as shown in the following figure Click "Left"...
  • Page 30 5.1.1 File watermarking The photo that have been successfully taken by this device will be marked with the watermark information such as the date, time, GPS latitude and longitude, Car No., and device number in the lower right corner, as shown in the following figure Among them: 2017-08-18 represents August 18, 2017 CRH380BL-2541 indicates that the current registration number is CRH380BL-2541...

  • Page 31: Camera

    N22°40'37.1" E114°3’48.2” indicates north latitude: 22°40’37.1” and longitude 114°3’48.2” 5.2 Camera Start up the "camera" program, as shown in the following figure After starting, enter the camera preview interface, as shown in the following figure In the camera preview interface, click the "OK" once, so as to start the video recording.
  • Page 32 "00:18:08" is displayed in the upper left corner of the screen, indicating that the record has been lasting 0 hour, 18 minutes, and 08 seconds. "1080P" is displayed in the lower right corner of the screen, indicating that the current camera resolution is "1920*1080". The device supports several options, i.e. 1080P (1920*1080), 720P (1280*720), and 480P (720*480).
  • Page 33 the screen indicates the status of the fill light. The fill light setting can be changed by tapping the icon with a finger; and the setting of the fill light includes “on” and “off”. Note: Fill light cannot be operated when battery power is below 15%; The recording program will not be operated when the battery power is below 3%.
  • Page 34 Click “left” and “right” keys to select the resolution. Click “OK” to pop up the submenus with the options of 1080P, 720P and 480P. Click “left” and “right” to select the desired option. Click again. "OK" to confirm the selection, as shown in the following figure Click "left"...

  • Page 35: Tagged Important Files

    5.2.1 Tagged important files During the video recording process, if the currently recorded video needs to be tagged, you can long click “OK” after the camera is started. The device will make an important mark on the file, as shown in the following figure If an important file is marked and the currently recorded file has been marked as an important file, the prompt "Set current file as important”...

  • Page 36: Auto Focus And Fixed Focus

    After the important file is marked, the storage name of the file will be added with IMP to distinguish it from ordinary files. 5.2.2 Auto focus and fixed focus Before starting the video recording or during the video recording, click the “AF” in the lower left corner of the figure to select the auto focus and fixed focus, as shown in the following figure Icon "...

  • Page 37: Capture

    The icon “ ” represents recording sound simultaneously; the icon “ ” is not to record sound while recording. 5.2.4 Capture During the video recording, if a frame of image in the current shooting needs to be captured, short click the “M” to capture the current frame of image and to store it. 5.2.5 File storage location Photo files captured by this device and pictures captured during video recording will be stored in the PHOTO folder of the built-in memory or external memory.

  • Page 38: Photo

    Naming of the tagged files: CRH380A-2541_RTA888_20170818_225805_0003_IMP.mp4 Naming of the audio files: CRH380A-2596_RTA888_20170818_225806_0002.wav CRH380BL-2541: indicates the Car No. RTA888: indicates the device number 20170818: indicates that the current date is August 18, 2017 225628: indicates that the current time is 22:56:28 0001: indicates the current file sort jpg: indicates the image files of jpg format mp4: indicates the video files of mp4 format...
  • Page 39 To view the next picture, swipe your finger to the right side or click the “right” key; to view the previous picture, swipe your finger to the left or click the “left” key; to go back to the home page, click the “M” key to exit the photo viewing program. (I) View photo menu In the photo preview interface, long click the “M”...
  • Page 40 The “18%" in the lower right corner of the screen indicates that 18% of the files have been uploaded. According to the type and speed of the current accessed network, the upload speed will be different. After the upload is completed, "Uploaded" will be displayed in the lower right corner of the screen, indicating that the current photo has been successfully uploaded to the server, as shown in the following figure;...

  • Page 41: Audio And Video

    Note: Please choose the options of “Delete” and “Delete all” carefully; once you delete the file, it will not be restored. 5.4 Audio and video Start up the "Audio and video" APP, as shown in the following figure: After starting, the device will enter into the audio and video preview interface. If the most recent file is a normal video file, the following picture is displayed: - 37 -...
  • Page 42 If the most recent file is a tagged video file, the following picture is displayed: The symbol " " in the lower right corner of the figure indicates that this file is a tagged video file; note that the file names of all the important video files are added with IMP.
  • Page 43 the “OK” button. When the “ ” changes to “ ”, the playing will be paused, as shown in the following figure: Long click the “right” key to fast-forward the playback; and long click the “left” key to quickly rewind during the playback. Or directly drag the progress bar with your finger to fast forward or rewind the playing.
  • Page 44 In the audio file preview interface, click on the " " symbol in the middle of the screen or click the "OK" button to start playing the current audio, as shown in the following figure: During the playback, click the “ ”...
  • Page 45 your finger to the left or click the “left” key; to go back to the home page, click the “M” key to exit the audio viewing program. (II) The menu of audio and video In the preview interface of Audio and video, long click the "M" key to pop up the menu, as shown in the following figure: Click “left”...
  • Page 46 Click "left" and "right" keys to select "Video", and click "OK" to switch to the "Video" APP. Select "Camera" and click "OK” to switch to "Camera" APP; Select "Audio” and click "OK" to switch to "Audio” APP; Select “Photo” and click “OK” to switch to “Photo” APP (view audio and video files);...

  • Page 47: Audio

    5.5 Audio Start the "Audio" APP, as shown in the following figure: After starting, enter the audio recording interface, as shown in the following figure: In the audio recording interface, click the “OK” button to start recording. During the recording process, repress the “OK” button to stop recording, as shown in the following figure: - 43 -...

  • Page 48: Telephone (Only Supported By 4G Version)

    00:00:10 displayed in the figure indicates that the audio recording has been lasting 0 hour, 10 minutes and 10 seconds. (I)Audio recording menu In the audio recording interface, long click the "M" key to pop up the menu, as shown in the following figure: Click "left"...
  • Page 49 After starting, enter into the phone dialing interface, as shown in the following figure: Click "left” and "right" keys to select the telephone number needs to be dialed, and click "OK" to make the phone call, as shown in the following figure: Note: This device can only dial the pre-set phone numbers.

  • Page 50: Car No

    5.7 Car No. Start up the "Car No.” APP, as shown in the following figure: After starting, enter into the setting interface of the Car No APP, as shown in the following figure: According to the Car No. that needs to be input, click on the corresponding figures to input the number, or click the “left”...

  • Page 51: Upload Files

    Note: The mobile network, WI-FI status, GPS service, storage location setting, and startup application setting are all described in details above. More options can be set by clicking the "Right” key to select downwards or swiping up to select the menu, as shown in the following figure: 5.8.1 Upload files Select “Upload files”, and click "OK"...
  • Page 52 The current upload mode is: manual upload, that is, you can manually upload the recorded or photographed files. If there are a considerable amount of files to be uploaded, long click the "M" key to pop up the switch menu, thereby changing the "Manual upload" to "Batch upload", as shown in the following figure: The function of batch upload can upload the recorded or photographed files in one go.
  • Page 53 After the upload is complete, the bar of the current status will show that the file has been uploaded, as shown in the following figure: Basic information: you can view the currently uploaded FTP address information. After changing the upload mode to batch upload, long click the “M” key to pop up the setup menu, as shown in the following figure;...

  • Page 54: Language Setting

    Upload videos: Upload batches of recorded or photographed videos in one go; Upload audios: upload the recorded audio files in go; Cancel the upload: The batch upload can be cancelled during the uploading process; Single manual upload: Bulk upload mode can be changed to the mode of manual upload;...

  • Page 55: Setting Date And Time

    5.8.3 Setting date and time Use the "left" and "right” keys to select the setting date and time, as shown in the following figure: Click "OK" button to enter the setting interface of date and time, as shown in the following figure: - 51 -...

  • Page 56: Displaying Local Imei

    In the figure, "2017" indicates the year, "9" indicates the month, "6" indicates the date, "10" indicates the hour, and "53" indicates the minute. Click “OK” key to select the option to be adjusted. Click “Left” and “Right” keys to set the value. After the setting is complete, short click “M” to pop up the menu, and select OK or Cancel, as shown in the following figure: Click OK or Cancel to go back to the interface of setup menu.

  • Page 57: Displaying The Local Ip Address

    the following figure: 5.8.5 Displaying the Local IP Address Click “Left” or “Right” keys to display the local IP, as shown in the following figure: 5.8.6 About Devices Click “Left” or “Right” keys to select “About devices, as shown in the following figure: - 53 -...

  • Page 58: Visual Positioning Platform (Requires Devices Supporting Visual Positioning Platform )

    Click the "OK" button to enter the interface of device information, as shown in the following figure: The interface of device information can display the device's name, software version number, running memory capacity, internal memory’s capacity, and Android version. 5.9 Visual Positioning Platform (Requires Devices Supporting Visual Positioning Platform) The equipment supports visual positioning platform, which can connect to the network via WIFI or 4G mobile data after starting up, thereby realizing the real-time...

  • Page 59: Operation Instructions Of Pc Setting Software

    VI. Operation instructions of PC setting software Find Smart_Devices_PC_Setup V1.0.0.0.exe in the root directory of the device's built-in memory and double-click to run the installation; after the installation is complete, enter into the PC settings interface, as shown in the following figure: Note: This setting software does not support Windows XP system, and Framework4.5 upgrade package is required to be installed.
  • Page 60 Enter the WIFI SSID that can be used normally in the input box of WIFI Name. Enter the WIFI password in the input box of WIFI password and click OK to save the input. If multiple WIFI information needs to be input, repeat the above steps. For telephone number input, please click "Add", as shown in the following figure: Please enter the phone number you want to add in the phone number input box,...

  • Page 61: Reference Table Of File Occupancy Memory

    Then modify the required information and click on "Save" Software update address: If the manufacturer releases an updated version of the software for this device, please consult the manufacturer to fill in the updated address. After the device is connected to the network, it will automatically download and update the software.

  • Page 62: Battery And Charge

    VIII. Battery and charge 8.1 Battery This device adopts special lithium battery, with rated voltage of 3.7V, capacity of 5000mAh (18.5Wh) or 10000mAh (37Wh), and charging limit voltage: 4.2V. 8.2 charge This device is designed to use lithium batteries. When being purchased, the battery power may be insufficient.

  • Page 63: Attention

    ● The battery is at risk of fire, explosion and burn. Do not disassemble it, heat it up above 60° C, or burn it. ● Do not use the battery in reverse direction or short-circuit the battery ● After the battery is fully discharged, the charging time should be extended to reach the saturation power ●...

  • Page 64: Environmental Protection

    magnetic field, as this may cause internal circuit failures in the device. Do not use this equipment during thunderstorms, so as to avoid lightning or other injuries. Turn off the device in a place where the use of wireless devices is expressly prohibited.

  • Page 65: Storage

    electrolyte, so as to generate a large amount of gas, and the resin adhesive in the electrode sheet also deteriorates, thereby causing the entire battery to gradually deteriorate, even to lose efficacy in a short period of time. Under normal circumstances, charging temperature shall be at 0 ° C ~ 45 ° C. And the discharge temperature is generally -20 °...

  • Page 66: Troubleshooting

    X. Troubleshooting (I) The device cannot be turned on The device will not be turned on when the battery is fully discharged. Before you turn on the device, please fully charge the battery. (II) The touch screen respond slowly or incorrectly If the finger is not clean when you touch the screen, or if you touch the screen with a sharp object or fingertip, the touch screen may appear malfunction.
  • Page 67 The device must have enough available storage space and battery power to support camera applications. If you receive an error message when you start your camera, try the following steps: Charge the battery. Transfer files to your computer or remove files from your device to free up storage space.
  • Page 68 the device. (XIV) Small gaps in the periphery of the device shell This gap is necessary for the manufacturing process; certain parts may appear slight chatter or vibration. The friction between the parts may lead the gap to expand slightly over time. - 64 -...
  • Page 69 Warranty Card Name or unit name： Address and post code： Contact number： Product serial number： Date After-Sale Service Records Service Personnel...
