Simplicity CONQUEST Conquest / 2700 Parts Manual page 11

Frame Group - Power Steering
REF NO PART NO.
44 1733851SM
45 1960355SM
46 1732939SM
47 1721682SM
48 1919394SM
49 2832577SM
50 1734202SM
Footnotes
The above parts group applies to the following Mfg. Nos.:
1695152 - Conquest
1695154 - 1723H
1695155 - 2723H
2690600 - Conquest
2690603 - 1723H
2690605 - 2723H
© Copyright 2008 Simplicity Manufacturing, Inc. All Rights Reserved.
QTY. DESCRIPTION
1 AXLE, Front Casting
1 NUT, Hex Lock ESNA Heavy 1/2-13
1 SPINDLE & ARM ASSEMBLY, R.H.
6 BUSHING, Axle
1 WASHER, 1
2 RING, Retaining, Extension
1 SPINDLE & ARM ASSEMBLY, L.H.
11
TP 400-4593-A-CQ-SMA
