Summary of Contents for e-JOE Bicycle Gadis
- Page 1 GADIS USER MANUAL Please read before operating your new bicycle.
- Page 2 INTRODUCTION Congratulations on the purchase of your new e-bike! We want to make you happy and believe your new e-bike will bring you lots of fun. We ask that you please read this manual thoroughly, paying special attention to the safety warnings before you start riding your bicycle.
-
Page 3: Warranty
LIMITED 30 DAYS FULL REPLACEMENT WARRANTY If an e-JOE bicycle is not working properly because of a major defect within the first 30 days, e-JOE Bike, Inc. will repair or replace any defective e-JOE Bicycle at its sole option and expense upon determining whether the damage, failure, or loss is due to a major defect. - Page 4 ● Front and rear LED lights ● Pedals (2) ● Battery charger - in a separate box ● Mini tool kit for assembly and/or repairs ● Keys (2) Please contact your dealer or e-JOE Bicycle if any of these parts are missing.
- Page 5 STRUCTURE OF YOUR E-BIKE...
- Page 6 MAIN SPECIFICATIONS: GADIS BIKE Weight 52 lbs. Max Capacity 300 lbs. Dimension 66 x 26 x 40 Max Speed 20 mph Full Charge Distance 30 miles Climbing Grade ≤ 10% MOTOR Description Rear drive brushless hub motor Max Riding Noise...
- Page 7 ASSEMBLY Step 1: Handlebars Stand the main body of the electric bike on the kickstand. Insert the stem of the handlebar subassembly into the steering column that is at the front of the main body frame. Make sure that the fork that will hold the front wheel is pointing forward, and orient the handlebar accordingly. Insert the stem all the way and tighten from the top using a big hex wrench.
- Page 8 ● Do not use any other charger other than the one that came with your electric bike. If you need another charger, contact your local dealer or e-JOE Bicycle. ● Do not attempt to open or repair your charger, the electronics contain high pressure circuits, so do not dismantle by yourself without a professional.
- Page 9 GENERAL OPERATING INSTRUCTIONS Before You Ride for the First Time: ● Check that the handlebar and handlebar stem are properly tightened. ● Check all other nuts and bolts and fixings are properly tightened, paying particular attention to the motor fixings, kickstand, yoke, and steering head bearings.
- Page 10 LCD OPERATING INSTRUCTIONS Default Settings: Default Settings fall into two categories: general, and advanced. General settings can be directly set by users. Advanced settings should NOT be altered once entered, as they affect the system as a whole. Please DO NOT make changes to the advanced settings. Settings Contain the Following: ●...
- Page 11 ○ Time/Quit from General Settings ■ Press [up] and [down] to change the hour ■ Press [mode] to enter minute settings, use [up] and [down] buttons to change the minute ■ Press [mode] to save and quit from general settings ●...
-
Page 12: Maintenance
MAINTENANCE ● IMPORTANT! DO not attempt to open the casings of the battery, motor, or controller; it could be dangerous and will void any warranties by doing so. If you experience and problem, please contact our service department or your retailer. ●... -
Page 13: Simple Troubleshooting
SIMPLE TROUBLESHOOTING PROBLEM SOLUTIONS A. Top speed too slow 1. Fully recharge battery B. Power on but motor not working 1. Reinstall battery/ Replace fuse C. Driving shorter distance per recharge 1. Check tire pressures 2. Recharge completely or have charger re-inspected 3.
