Summary of Contents for Dogu FourSeason KKS 062 - 046
- Page 1 AIR HANDLING UNIT INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS is a registered trademark of Dogu Iklimlendirme A.S...
- Page 2 (DIN,EN). Dogu puts the devices on the market with ‘’Four Season’’ brand. Dogu HVAC Systems which is in business within 45.000m² open area with 2 factory, has 120 different types of products. It brings new products to the sector producing Make-up Kitchen Hoods, Laminar Flow Ceiling, One Piece Square Ceiling Diffuser.
- Page 3 Air Handling Unit Installation, Operation And Maintenance Instructions is a registered trademark of Dogu Iklimlendirme A.S - Protect your unit against damage, shock and distortions. - Do not attemp to install and run the unit before reading the instructions in this booklet - Your unit’...
-
Page 4: Table Of Contents
Air Handling Unit Installation, Operation And Maintenance Instructions CONTENTS Pages - INTRODUCTION ............................3 - ABOUT AIR HANDLING UNITS ........................3 - TRANSPORTATION AND STORAGE ......................4 - INSTALLATION ............................4 4.1 CONNECTION OF SECTIONS ......................5 - CONNECTIONS ............................6 5.1- DUCTING CONNECTIONS ........................ -
Page 5: Introduction
2- About Air Handling Units WARNING: DOGU IKLIMLENDIRME A.S. air handling unit are only used for heating, ventilating and air conditioning purposes. Any other use is considered not in conformity with general provisions. The manufacturer is not responsible for damages resulting;... -
Page 6: Transportation And Storage
33 - 34 for information only. It is not permitted to operate fans and motors at higher speeds other than design speed, without written permission of DOGU IKLIMLENDIRME A.S., since operating at higher speeds may overload and damage the motor and fan. -
Page 7: Connection Of Sections
Air Handling Unit Installation, Operation And Maintenance Instructions WARNING: Air handling units should be installed on a rigid and level surface. Correct alignment of the sections is essential to maintain a satisfactory airtight enclosure and to avoid distortion to the casing and components. -
Page 8: Connections
Air Handling Unit Installation, Operation And Maintenance Instructions WARNING: Do not use excessive forces to align the sections, because it may deform the aluminum framework and casing. Sections are locked together by special connection parts, bolts, and nuts. Section connection parts are mounted on the unit sections, bolts and nuts are fitted on the connection pieces. - Page 9 Air Handling Unit Installation, Operation And Maintenance Instructions 5.1.2- Ducted Outlet Conditions With the outlet connected to the discharge duct by a flexible connector, which is desirable for noise and vibration isolation, it is important that the connector is correctly fitted. The fan outlet and the duct should not be misaligned (Fig.6) nor should the flexible connector be allowed to concertina.
- Page 10 Air Handling Unit Installation, Operation And Maintenance Instructions Extremely high losses occur when attempts are made to change the direction of the airflow close to the fan discharge. If this is necessary the installation should be carried out as in (Fig.12) and ever as in (Fig.13) A better solution is to have a parallel section of ducting prior to changing direction and it should be as long as can be accommodated.
-
Page 11: Piping Connections
Air Handling Unit Installation, Operation And Maintenance Instructions 5.2- Piping Connections Coils should be piped in counter flow arrangement to achieve required capacity. This arrangement requires that the entering heating or cooling fluid contacts the air leaving the coil. Water heating and cooling coils should be arranged with inlet connection at the lowest level on one side of the coil near downstream and water outlet connection on the same side but at high level near the upstream. - Page 12 Air Handling Unit Installation, Operation And Maintenance Instructions www.doguhvac.com...
-
Page 13: Condensate Drain Lines
Air Handling Unit Installation, Operation And Maintenance Instructions 5.3- Condensate Drain Lines Moisture condensed out of the airstreams on cooling / dehumidifying coils should be drained out of the unit, to prevent water damage in the air handling unit and ductwork system. Following precautions should be observed in piping of condensate drain lines. - Page 14 Air Handling Unit Installation, Operation And Maintenance Instructions Starter for centrifugal fans in the air handling units for single speed motors driving through V-belts are normally of the direct-on-line type. However the customer or Electric Supply Authority may require motors above 3kW to be operated by a star-delta starter, to reduce starting current.
- Page 15 - If the operating point of the fan will exceed the design operating point of the fan, there is a risk of motor to overload and overheat. Please consult to DOGU IKLIMLENDIRME A.S., if the design operating point of the fan will be exceeded.
- Page 16 Air Handling Unit Installation, Operation And Maintenance Instructions Starter for centrifugal fans in the air handling units for single speed motors driving through V-belts are normally of the direct-on-line type. However the customer or Electric Supply Authority may require motors above 3kW to be operated by a star-delta starter, to reduce starting current.
- Page 17 Air Handling Unit Installation, Operation And Maintenance Instructions www.doguhvac.com...
- Page 18 Air Handling Unit Installation, Operation And Maintenance Instructions www.doguhvac.com...
- Page 19 Air Handling Unit Installation, Operation And Maintenance Instructions www.doguhvac.com...
-
Page 20: 6- Setting Up Of Components
Air Handling Unit Installation, Operation And Maintenance Instructions 6- Setting Up Of Components 6.1- Dampers Manually operated dampers can be adjusted to obtain the required air flow, by turning the control lever. After setting the desired location on locking quadrant, control lever must be tightened. Dampers can be equipped with the motor. -
Page 21: Humidifiers
Air Handling Unit Installation, Operation And Maintenance Instructions It Is Recommended That The Water Flow Is Shut Off When The Fan Is Switched Off. To Avoid The Overheating Of The Heating Coil, The Hot Water Pump And Water / Steam Valves Should Only Be Opened During The Operation Of Fan. -
Page 22: Supply And Return Fans
DOGU IKLIMLENDIRME A.S. air handling units can be considered as safe machinery. By means of the compliance statement of the EEC and of the symbol “CE” on the unit, it is guaranteed that DOGU IKLIMLENDIRME A.S. air handling units fulfill the provisions for the safety and health, on the ground of Machinery Directive 98/37/EC and the European standards. -
Page 23: Use Of The Unit
Air Handling Unit Installation, Operation And Maintenance Instructions 7.1- Use Of The Unit In order to use the unit according to general provisions, proper instructions of transport, installation and use must be observed. Installation and start up of the unit must conform to the national standards having legal course in the country of the user. -
Page 24: Prevent Of Common Dangers And Risks
Air Handling Unit Installation, Operation And Maintenance Instructions 7.4- Prevent Of Common Dangers And Risks Air handling units are supplied with locked access doors as an option. So, unauthorized persons are not permitted to enter the sections which represent a danger. The most important potential dangers for life and health are described below. -
Page 25: The Hidden Danger
Air Handling Unit Installation, Operation And Maintenance Instructions The available optional guarding devices are: 1) Fan inlet and outlet guards: Centrifugal fans in air handling units are usually connected directly to duct- work which will prevent the contact with the internal moving parts. In case there is an exposed inlet or outlet which could represent a danger, suitable guards can be installed. -
Page 26: Start Up
Air Handling Unit Installation, Operation And Maintenance Instructions 7.7- Start Up Before operating air handling unit for the first time (or after an annual maintenance) the manufacturer’s instructions must be followed. In addition, the following check list must be completed: - Ensure that all the sections of the unit are thoroughly cleaned. -
Page 27: Maintenance
Air Handling Unit Installation, Operation And Maintenance Instructions - Adjust damper position to obtain required air volume. Ensure that the air volume is within specified limits. - Check the motor current and ensure that it is in accordance with the motor rated data (on motor name- plate) - Check inlet-outlet temperatures across coils and adjust water/steam flows accordingly. - Page 28 Air Handling Unit Installation, Operation And Maintenance Instructions WARNING: During maintenance and repair works that will be done with an operator inside the unit a prominent ‘MAINTENANCE, DO NOT CLOSE THE DOOR’ sign must be placed on the service door. Especially at the hygienic air handling units, filters, coils, (by disconnecting the flange connections), droplet eliminator and sound attenuators can be taken out from the service doors.
- Page 29 Air Handling Unit Installation, Operation And Maintenance Instructions - Check motor and fan bearing lubrication - Check the operation of dampers - Check the condition of access door for easily opening and proper locking - Check the condition of valves and fittings on the piping system - Check all wiring, control and isolating devices, terminal connections, etc.
- Page 30 Air Handling Unit Installation, Operation And Maintenance Instructions CAUTION: Keep coils from freezing. When water inside coils is allowed to freeze, serious damage will be caused to the tubes. So, if there is a danger of freezing, anti-freeze chemicals should be added to the circulating water or if the coil will not be operated for a short time, some water circulation should be provided inside the tubes.
-
Page 31: Belt Tension And Alignment Control
Air Handling Unit Installation, Operation And Maintenance Instructions D) Humidifier sections Humidifier should be cleaned regularly. The period changes according to the operating conditions, air specifications and water quality. During periodic maintenance of humidifier, checks mentioned in its own manual should be performed. Piping system and hoses should be checked for leakage and damage. E) Sound Attenuators Sound attenuators can be taken out from the service door by unscrewing the components from the top and bottom panels. - Page 32 Air Handling Unit Installation, Operation And Maintenance Instructions Belt section Small pulley diameter, 11,7 Tensioning 11,7 15,3 force, DEFLECTION SMALL PULLEY CENTER DISTANCE If the belt is not tight enough, and if not corrected, could result in slippage causing loss of fan speed and belt failure through wear.
-
Page 33: Change Of Pulleys
Air Handling Unit Installation, Operation And Maintenance Instructions 10- Change Of Pulleys 10.1- Mounting Of Pulleys - Clean and degrease smooth surfaces of bushing, pulley and shaft - Assemble bushing and pulley by aligning semi-threaded holes. Insert the screws loosely. - Insert the key on shaft, then slide pulley to desired position with screw heads to the outside. -
Page 34: 11- Lubrication Of Bearings
Air Handling Unit Installation, Operation And Maintenance Instructions CAUTION: Don’t use hammer or puller to remove the pulley. Don’t change pulleys without written consent of DOGU IKLIMLENDIRME A.S.; otherwise we take no responsibility for the consequences. 11- Lubrication Of Bearings Bearings have to be controlled and cleaned regularly;... -
Page 35: 12- Troubleshooting
Air Handling Unit Installation, Operation And Maintenance Instructions CAUTION: For lubrication of bearings refer to the recommendations of fan and motor manufacturers. 12- Troubleshooting Before checking the fan system, it will be necessary to shut down the fan. During inspection, the unit must be isolated electrically and all disconnect switches and other controls must be locked in the “off”... -
Page 36: Troubleshooting Chart
Air Handling Unit Installation, Operation And Maintenance Instructions 12.1- Troubleshooting Chart PROBLEM SYMPTOMS POSSIBLE CAUSE OTHER CAUSES OR ACTION Impeller hits inlet Damaged impeller Correct or change impeller ring Damaged inlet ring Correct or change inlet ring Impeller not centered on shaft Center the impeller Shaft loose in bearing Tighten shaft... - Page 37 Air Handling Unit Installation, Operation And Maintenance Instructions PROBLEM SYMPTOMS POSSIBLE CAUSE OTHER CAUSES OR ACTION NO AIR FLOW Current is not Electric power failure Locate fault and restore power Motor is not reaching motor Starter overload tripped Faulty wiring motor. Loose terminals. running Control panel fault Locate and correct fault.
- Page 38 Air Handling Unit Installation, Operation And Maintenance Instructions PROBLEM SYMPTOMS POSSIBLE CAUSE OTHER CAUSES OR ACTION AIR WASHER Low water flow Blockage in system. Valves are closed. Leakage in piping Low water level in water pan Float valve is off. Supply water is off. humidifying Water distribution system is clogged Clean the system.
-
Page 39: 13- Operating Limits Of Fans
13- Operating Limits Of Fans WARNING: It is not permitted to operate fans at higher speeds other than design speed, without written permission of DOGU IKLIMLENDIRME A.S., since operating at higher speeds may overload and damage the motor and fan. - Page 40 Air Handling Unit Installation, Operation And Maintenance Instructions MAXIMUM MAXIMUM FAN TYPE INSTALLED SPEED POWER 180L, 180R 6800 200L, 200R 6000 200K 6800 225L, 225R 5800 225K 6000 250L, 250R 4600 250K 5400 280L, 280R 4000 280K 4700 315L, 315R 3500 315K 4100...
- Page 41 Air Handling Unit Installation, Operation And Maintenance Instructions MAXIMUM MAXIMUM FAN TYPE INSTALLED SPEED POWER TLZ 160 4250 TLZ 180 4000 TLZ 200 3800 TLZ 225 3400 TLZ 250 3000 TLZ 280 2730 TLZ 315 2200 TLZ 355 1900 TLZ 400 1700 TLZ 450 1500...
- Page 42 Air Handling Unit Installation, Operation And Maintenance Instructions MAXIMUM MAXIMUM MAXIMUM INSTALLED SPEED SPEED POWER 3000 TZAF 355B TZAF 355T1 3650 TZAF 355T2 4000 TZAF 400B 2700 TZAF 400T1 3200 TZAF 400T2 3700 TZAF 450B 2400 TZAF 450T1 2850 TZAF 450T2 18.5 3300 TZAF 500B...
-
Page 43: 14- Motor Technical Information
Air Handling Unit Installation, Operation And Maintenance Instructions 14- Motor Technical Information Siemens Low-voltage Three Phase Squirrel-cage Motors 3000 rpm (2 pole) 400V, 3ph, 50 Hz, degree of protection IP55, class F insulation, 40 °C OUTPUT POWER SPEED CURRENT EFFICIENCY POWER FACTOR TYPE CosØ... - Page 44 Air Handling Unit Installation, Operation And Maintenance Instructions 1500 rpm (4 pole) 50 Hz 400V, 3ph, 50 Hz, degree of protection IP55, class F insulation, 40 °C OUTPUT POWER SPEED CURRENT EFFICIENCY POWER FACTOR TYPE CosØ 1LA7 060-4AB60 0.12 1350 0.42 0.75 1LA7 063-4AB60...
- Page 45 Air Handling Unit Installation, Operation And Maintenance Instructions 1000 rpm (6 poles) 50 Hz 400V, 3ph, 50 Hz, degree of protection IP55, class F insulation, 40 °C OUTPUT POWER SPEED CURRENT EFFICIENCY POWER FACTOR TYPE CosØ 1LA7 063-6AB60 0.09 0.44 0.66 1LA7 070-6AB60 0.18...
-
Page 46: Appendix-1 Starter Selection Table
Air Handling Unit Installation, Operation And Maintenance Instructions www.doguhvac.com... -
Page 47: 15- Producing Company
Air Handling Unit Installation, Operation And Maintenance Instructions 15- Producing Company DOĞU İKLİMLENDİRME SAN. VE TİC. A.Ş I.T.O.B. O.S.B 10010 Sok. No:4 35473 Tekeli Menderes IZMIR TURKEY Tel:+90 232 799 02 40 Fax:+90 232 799 02 44 AUTHORIZED SERVICES ANKARA GÜVEN TEKNİK BEKİR YERLİKAYA 0.542.527.7878... -
Page 48: 16- Warranty
Air Handling Unit Installation, Operation And Maintenance Instructions Warranty Certificate Midyat Hospital Air Handling Units And Celled Aspirators The FOUR SEASON brand air handling units and celled aspirators we manufacture which list is given below are under our guarantee against defects in material and workmanship for two years from date of consignment for given conditions below;... -
Page 49: 17- Delivery Report
Air Handling Unit Installation, Operation And Maintenance Instructions DELIVERY REPORT Service / Delivery / Maintenance Form SERVICE SUPPLIED DATE HOUR FIRM NOTIFICATION DATE ../../201..: ..FACILITY NAME DEPARTURE TO SERVICE DATE ../../201..: ..PHONE SOLUTION DATE ../../201... -
Page 50: 18- Decleration Of Conformity
Air Handling Unit Installation, Operation And Maintenance Instructions 17- Decleration Of Conformity DECLARATION OF CONFORMITY We, DOĞU İKLİMLENDİRME SAN. VE TİC. A.Ş.. headquartered at 10010 Sk. No:4 İTOB Organize Sanayi Bölgesi Tekeli Menderes - İZMİR – TURKEY hereby declares that the products KKS – S and KKS – H series AIR HANDLING UNITS manufactured at 10010 Sk. - Page 51 Air Handling Unit Installation, Operation And Maintenance Instructions NOTES www.doguhvac.com...
- Page 54 Factory ITOB Organize Sanayi Bölgesi 10010 Sok. No: 4 35477 Tekeli / Menderes / Izmir / TURKEY Tel: +90 (232) 799 02 40 Faks: +90 (232) 799 92 04 Istanbul Area Barbaros Mah. Çigdem Sok. No:1 Agaoglu My Office Kat: 4/18 Atasehir/Istanbul / TURKEY Tel: +90 (216) 250 55 45 Faks: +90 (216) 250 55 46 Ankara Area Çetin Emeç...
