Congratulations on your purchase
of a Ripmax Rock Racer, please read
these instructions carefully and fully before
use and we hope you enjoy your car.
Specifications
•
Car Scale: 1:24
•
Car Battery: 6.4V 320mAh LiFe (Inc.)
•
Car Dimensions: 201 x 110 x 74mm
•
Driving Max Speed: 25km/h (Approx)
•
Driving Time: 15min (Approx)
•
Car Charging Time: 60min (Approx)
Parts and Functions
Power
Switch
Battery
Hatch
Battery Installation Guide
As shown in diagram 1, open the remote control battery cover. Install three 'AA' batteries
taking care to note the polarity matched the diagram in each battery slot. Re-install the cover to
secure. Check the transmitter power switch is OFF and that the steering trim is centred vertically
(diagram 2) before proceeding.
As shown in diagram 3, open the car battery bay by unscrewing the retaining screw and
releasing the clip. Insert the battery (checking polarity) and tuck the wire in beside the battery.
Re-install the battery cover and secure with screw.
•
•
•
•
•
•
Power LED
Power
Switch
Battery Cover
Charger Input: 100-240V 50/60Hz
Charger Output: 6.4V 350mAh
Tx Max Control Range: 30-40M
Tx Frequency: 2.4GHz
Tx Battery: 3 x 'AA' 1.5V (Req.)
Tx Dimensions: 118 x 72 x 179mm
Steering Trim
Steering Wheel
Trigger
Battery
Charger
6.4v Lithium
Battery
Advertisement
Related Manuals for Ripmax Rock Race
Summary of Contents for Ripmax Rock Race
- Page 1 Congratulations on your purchase of a Ripmax Rock Racer, please read these instructions carefully and fully before use and we hope you enjoy your car. Specifications • Car Scale: 1:24 • Charger Input: 100-240V 50/60Hz • Car Battery: 6.4V 320mAh LiFe (Inc.) •...
- Page 2 Diagram 1 Diagram 2 Diagram 3 Black Black Battery Charging Instructions Plug the battery charger into a mains socket and the LED indicator should illuminate green. Connect the lithium battery to the red charger output connector and the charger LED indicator should change colour to red.
- Page 3 Operating Instructions Note: Always ensure the transmitter is on when the car is on. To do this switch on the transmitter first before use and turn it off last. The steering is controlled by the steering wheel, turn it anti-clockwise to turn left and clockwise to go right when driving forward.
- Page 4 Ripmax are only liable to pay compensation, regardless of the legal reason, an amount limited to the invoice value of product affected directly in the event of any damage occurred.
