- Page 1 Instruction Manual ELTROTEC Panoramascope...
- Page 2 Panoramascope for machines, equipment and cavity walls MICRO-EPSILON Eltrotec GmbH Heinkelstrasse 2 73066 Uhingen / Germany Phone +49 (0) 7161 / 98872-300 Fax +49 (0) 7161 / 98872-303 e-mail eltrotec@micro-epsilon.de www.micro-epsilon.com Certified according to DIN EN ISO 9001: 2008...
-
Page 3: Table Of Contents
Exchanging the Panorama Lens ........................18 Troubleshooting ........................19 6.2.1 Poor Image Quality ........................19 6.2.2 Scratches and Damages ......................19 6.2.3 Strong Reflections ........................19 6.2.4 Image Won’t Focus ........................19 6.2.5 Image is Hazy and no Longer Circular ..................19 ELTROTEC Panoramascope... - Page 4 Maintenance ..............................20 Warranty ..........................21 Service, Repair ........................21 Decommissioning, Disposal ....................21 Appendix Accessories ..........................22 A 1.1 Light Sources ..............................22 A 1.2 Fiber-Optic Cables ............................22 A 1.3 Cameras ................................. 22 A 1.4 Lenses ................................24 ELTROTEC Panoramascope...
-
Page 5: Safety
> Danger of injury, blinding, damage to the eyes Never bend or crush the endoscope. NOTICE > Damage to or destruction of the endoscope Always place the endoscope down carefully; do not let it fall. > Damage to or destruction of the endoscope ELTROTEC Panoramascope Page 5... -
Page 6: Proper Use
- The system may only be operated within the limits specified in the technical data, see Chap. 2.2. - The ELTROTEC panoramascope must be used in such a way that no persons are endangered or ma- chines are damaged in the case of malfunctions or total failure. -
Page 7: Proper Environment
+70 °C (-4 °F to +158 °F) (6 mm) and -20 °C to +100 °C (-4 °F to +212 °F) (11 mm) as the adhesives used in the interior of the endoscope would evaporate. > Destruction of the endoscope The panoramascope is not watertight as the panorama lens is exchangeable. ELTROTEC Panoramascope Page 7... -
Page 8: Functional Principle, Technical Data
1, is a high-quality optical instrument. It is ideal for the inspection of cylindrical cavities in industrial sectors. Fig. 1 Rigid endoscope, model ELTROTEC panoramascope The panoramascope is designed for time-saving inspection of hollow bodies due to 360° all-round view in one workflow and therefore ideally suitable for automatic image processing. - Page 9 A complex lens system guides the lens-generated image through the endoscope cladding tube to the eye- piece. Light Field of view approx. 90°, Direction of view 90° 360° all-round view Panorama lens Fig. 2 Direction of view Panorama lens Focussing ring Fiber optic connector Fig. 3 Panoramascope structure ELTROTEC Panoramascope Page 9...
-
Page 10: Technical Data
Fiber optic connector Lemo 2 Lens mount/eyepiece mount M12x1 Eye cup Ø 32 mm screw-in type Temperature stability -20°C to +70 °C (-4 °F to +158 °F) -20 °C to +100 °C (-4 °F to +212 °F) ELTROTEC Panoramascope Page 10... -
Page 11: Delivery
Delivery Delivery Unpacking / Included in Delivery ELTROTEC Panoramascope Lemo 2 adapter Cleaning set Suitable light sources, optical fibers and cameras are listed in Optional Accessories, see Chap. Check the delivery for completeness and shipping damage immediately after unpacking. In case of damage or missing parts, please contact the manufacturer or supplier immediately. -
Page 12: Mounting
Mounting Dimensional Drawing for Panoramascope 107 ±1 Length (4.21 ±.039) Fig. 4 Dimensional drawing for ELTROTEC panoramascope in mm, not to scale Ø7.2 (.28 dia.) Ø11 (.43 dia.) Fig. 5 Dimensional drawing for panorama lens in mm, not to scale... -
Page 13: Assembling The Screw-Threaded Lens
Eye piece Fig. 7 Individual components for assembling the camera / Fig. 8 Final assembly of the camera / quick- lens / panoramascope release lens and panoramascope The quick-release fastener does not work without the eye cup. ELTROTEC Panoramascope Page 13... -
Page 14: Connecting The Usb Camera With The Usb Cable
Tighten the screws to ensure that the cable doesn’t become loose and the connection won’t be inter- rupted. Plug the USB connector into your laptop. Load the software and instruction manual from the supplied CD and start the program. ELTROTEC Panoramascope Page 14... -
Page 15: Connecting The Analog Camera
The settings will be retained. BNC cable Power supply OSD socket with Remote control unit cable for remote control Fig. 11 Connecting the analog camera Fig. 12 Final assembly of the endoscope, incl. analog camera, laptop and light source ELTROTEC Panoramascope Page 15... -
Page 16: Light Source
(spin lock) which is kept in place in the ring lock recess to prevent the connected plug from rotating. Optical fiber Fiber optic connection Fig. 13 Connecting the optical fiber with the light Fig. 14 Connected optical fiber source ELTROTEC Panoramascope Page 16... -
Page 17: Operation
Turn the knurled ring on the eyepiece to adjust the sharpness of the image (focus) for the endoscope. The depth of field (focus) ranges from 3 mm to infinite. Place the endoscope down carefully after use. Depending on the version (see catalog), the endoscope probe can be rotated. ELTROTEC Panoramascope Page 17... -
Page 18: Exchanging The Panorama Lens
Please make sure that no dust or dirt gets into the panoramascope. NOTICE > Damage to or destruction of the panoramascope Screw the new panorama lens clockwise onto the endoscope until you can feel a slight resistance Panoramascope Panorama lens Fig. 15 Exchanging the panorama lens ELTROTEC Panoramascope Page 18... -
Page 19: Troubleshooting
Keep a larger distance to the inspected object. the inspected object. 6.2.5 Image is Hazy and no Longer Circular Possible cause Troubleshooting One or more lenses are broken. The endoscope must be sent in for repair. ELTROTEC Panoramascope Page 19... -
Page 20: Instructions For Operation
Instructions for Operation Instructions for Operation Cleaning Clean the ELTROTEC panoramascope or the panorama lens with a soft, clean cloth, low-pressure com- pressed air or a cloth moistened with alcohol. Or use the supplied cleaning set. Use low-pressure com- Use a cotton swab moistened with isopropyl alcohol (cleaning pressed air to clean the set) to clean the endoscope. -
Page 21: Warranty
The warranty period lasts 12 months following the day of shipment. Defective parts, except wear parts, will be repaired or replaced free of charge within this period if you return the device free of cost to MICRO-EPSILON Eltrotec. This warranty does not apply to damage resulting from improper handling or violent action or repairs or modifications by third parties. -
Page 22: Appendix A 1 Accessories
Description Item number Photo Eltrotec Endolight High performance LED light 20912110 FOT LED source A 1.2 Fiber-Optic Cables A 1.3 Cameras Description Description Item number Photo Analog color CCD One-cable connection; 20962182 camera CA1/3 white balancing ELTROTEC Panoramascope Page 22... - Page 23 Analog color CCD 20962287 camera Endo CA1/2 USB 2.0 color camera Includes software for image 20961601 Endo CU1/3 display and storage. Power supplied via USB inter- face; different resolutions available ELTROTEC Panoramascope Page 23...
-
Page 24: Lenses
Ab Ø 4,0 mm Ab Ø 5,8 mm 1/2" chip 1/3" chip Fig. 17 Lens selection criteria Small CCD chip - small focal length larger endoscope diameter - shorter focal length 1) Endoscope diameter 2) Lens focal length ELTROTEC Panoramascope Page 24... - Page 25 Focal length f: 47 mm, M14x1 20961055 for rigid endoscopes SKF-D up to a ø of 4.0 mm Focal length f: 32 mm, M12x1 20960088 for endoscopes MTFS and ME Focal length f: 47 mm, M12x1 20960099 for PKF endoscopes ELTROTEC Panoramascope Page 25...
- Page 26 MICRO-EPSILON Eltrotec GmbH X9751373-A011037HDR Heinkelstr. 2 ·73066 Uhingen / Germany Phone +49 (0) 7161 / 98872-300 · Fax +49 (0) 7161 / 98872-303 *X9751373-A01* eltrotec@micro-epsilon.de · www.micro-epsilon.com...
