Summary of Contents for Aztech Technologies Pte Ltd. Kyla AM68
- Page 1 User Guide...
- Page 2 Smart Curtain Motion Thanks for using Aztech Kyla product If you need support or help, please visit www.kyla.aztech.com...
- Page 3 Features · Bi-Voltage Power Supply: AC100~240V, available for global countries · Multiple Connection: Use RJ12 port for several motors online control, and external switch operate each motor · Stop On Block: Motor stop automatically to protect the whole system when meeting resistance ·...
-
Page 4: Load Parameters
Parameter Model Rated Torque Work Speed Size Rated Voltage Power IP Rating AM68 1N.m 16cm/s 310x68x50mm AC100~240V, 50/60Hz IP20 Load Parameters track length track length single retract track length single retract track length single retract track length single retract 90kg 75kg 67.5kg 60kg... -
Page 5: Structure And Accessories
Structure and Accessories Sub box Belt Master box Track Lock Hook Hook Lock Curtain motor Pulley Hanger Master box Sub box Pulley Ceiling bracket Belt Track Hanger Lock Splice Connector Single track bracket Double track bracket... -
Page 6: Installation And Wiring
Installation and Wiring Distance between Duel tracks two brackets ≤500mm Ceiling bracket Single track Double track(two curtains) (fabric+silk curtain) ≥10mm ≥10mm ≥36mm ≥56mm ≥36mm ≥56mm ≥36mm ≥56mm ≥60mm ≥10mm... -
Page 7: Install Motor
Install Motor Lock bar Please check and keep the Insert the motor to main box Slide the lock bar and make sure Check and Locked lock bar at te left side as the image it is in the limit hole on the right... -
Page 8: Remove Motor
Remove Motor Caution Please follow the installation drawing above Make sure the lock bar in the correct position as image Ceiling must be stong enough to hold the track, motor and curtain Pull the lock bar and make Slide to the left Removing motor it slide out of the limit hole... - Page 9 Wiring Available for more motors Caution LED Indicator External manual switch is dry contact mode, function keep the same. Power Cable LED Indicator (Motor) AC 100V~240V LED Indicator WiFi Antenna (WiFi) 433 MHZ Antenna Program Button Motor A Motor B...
-
Page 10: Led Light Status
Smart Wireless Control Operation Instruction 1. Download the Aztech Kyla App Aztech Kyla App Download the free Aztech Kyla App from the App Store / Google Play to get the app on your smartphone or tablet. 2. LED Light Status Working: OFF Reset Network: Flashes in red &... -
Page 11: Operation
3. Operation APP control: Control the curtain motor via Aztech Kyla APP. Scene control: You could preset the motor and our other devices into one scene and control them at the same time. Automation control: You could control the motor automatically when the sensor was triggered. Such as close the curtain motor when someone open the door. - Page 12 Warranty Range and Duration One year warranty applies to most Aztech Kyla product unless other wise speci ed at the time of purchase. Accessories included with the main device and batteries have a warranty of six months when buying used in Aztech Kyla products, the product warranty remains measured from the time it was bought by the original owner.
- Page 13 Product damage caused by accident, human abuse/misuse, such as output short circuit, high-voltage input, overload work, high temperature, water in ow, mechanical damage, broken serious oxidation or rusty and etc. Damage caused by transportation loading and unloading on the way of return for repair. Product failure or damages caused by force majeure such as earthquake, re, ood lightning and so on.
- Page 14 ©2018 Aztech Technologies Pte Ltd. All rights reserved.
