- Page 1 UNIPHOS-250(PM) FumiSense Pro INSTRUCTION MANUAL Uniphos Envirotronic Pvt. Ltd. Readymoney Terrace, 167, Dr. Annie Besant Road, Worli, Mumbai – 400018, India. Tel: (91-22) 2493 0681, Fax: 2493 8826 Email: gasdetection@uniphos.com...
- Page 2 Please do not attempt to use any other accessories and other components other than UNIPHOS. Also do not attempt to open the instrument at site, as it would lead to termination of warranty for your instrument. If you have any queries regarding the...
-
Page 3: Table Of Contents
Table of content Sr. No Content Page INTRODUCTION WORKING PRINCIPLE INSTRUMENT DESCRIPTION FRONT PANEL LEFT HAND SIDE PANEL BOTTOM PANEL(fig 3) INSTRUMENT OPERATION INITIALIZATION OPERATION IN VARIOUS MODES PARAMETER SETTING MODE 4.1.1 SELECT SAMPLING TYPE & SAMPLING TIME 4.1.2 SET SERIAL NUMBER 4.1.3 DATE TIME SETTING CALIBRATION MODE... -
Page 4: Introduction
For this application, UNIPHOS-250(PM) FumiSense Pro is suitable. This manual gives the full description of the UNIPHOS-250(PM) FumiSense Pro, its operation, calibration, maintenance and the other relevant information. -
Page 5: Instrument Description
2. Instrument Description UNIPHOS-250(PM) FumiSense Pro is a microprocessor based instrument for the measurement of Phosphine. Fig. 1 shows the front panel, Fig. 2 shows the right hand side panel and Fig. 3 bottom panel of the instrument. The instrument has following important parts namely sensor, signal conditioning electronics, alphanumeric OLED Display, a sample draw pump and a battery pack. - Page 6 2. SAMPLING LED: The sampling LED glows, when the instrument is in measurement mode. 3. UP KEY: a) Menu page: Press this key to enter into the Sampling/Purging mode (either Batch or continuous). b) Parameter Set Mode: In this mode, the key is used to increase the value of the digit below which the cursor is placed.
-
Page 7: Left Hand Side Panel
Left hand side panel INLET (1) OUTLET (2) USB (3) Fig. 2: Left hand side panel The left hand side of the instrument contains a charging socket, a USB socket and two ports, namely, Gas inlet nozzle & Gas outlet nozzle for sampling. These are marked on the instrument for the identification. -
Page 8: Bottom Panel(Fig 3)
2.3 Bottom panel BATTERY CHARGER SOCKET: This socket is provided for charging the instrument. Plug the charger to 110V/230VAC, 50- 60Hz power outlet and the other end to the instrument and turn it ON. Charge the battery for 3 - 4 hours. The Battery charge status can be viewed on the LCD/ OLED display in the download page. -
Page 9: Instrument Operation
Once instrument is turned ON, it goes into the initialization and following prompts will appear in the sequence on the display. INSTRUMENT STARTS 3 .. 2 .. 1 .. 0 (Instrument Turn ON) UNIPHOS-250 FUMISENSE PRO SERIAL NUMBER A-XXXX(PM) (Instrument Model and Serial number) SOFTWARE VERSION: X.XX.XXX... -
Page 10: Operation In Various Modes
At the end of the initialization, instrument moves to the menu page. The menu page gives information on the operating mode selection for the specific key activation as follows: “UP” key ▲ Monitoring mode i.e. Start sampling (continuous/batch sampling). 2. “DN” key ▼... -
Page 11: Set Serial Number
4.1.2 Set Serial Number: Serial Number A – XXXX (PM) In this screen the display will show the current serial number of the instrument. 2. The cursor will be blinking at the first digit of the “Serial Number”, make desire changes and press ENT key to confirm. -
Page 12: Sampling Mode
3. In case of ZERO CAL FAIL, exit from the calibration mode by pressing SET key. Again re-enter into calibration mode and immediately after “APPLY ZERO GAS” prompt, manually set zero count in between 50 to 999, ideally 500 by adjusting ZERO POT as shown in the image below (within 30 seconds of zero calibration time). - Page 13 1. Press UP key in the menu page to enter the sampling mode and following prompt will appear on the screen. Remove Tubes Select: Sampling/Purging 2. Select Sampling or Purging as per the requirement using Up/Dn key. If the sampling is selected, instrument will display following prompt.
-
Page 14: Data Downlaoding Mode
7. In batch sampling mode, once sampling is over, monitor prompts for data logging mode as shown below. PH3: XXXX PPM Press UP Key to log data 8. Press the UP key and after asking for confirmation, enter site and location value and press ENTER key to log the data in to the instruments memory or press SET key to move to the Purging page without logging / storing the data. -
Page 15: To Download Summary Report
Enter Report No From: 0000 To : XXXX 2. Press Enter key to print the range of data to be printed. Note: XXXX indicates the maximum no. of data that is present in the memory. 4.4.2 To Download Summary report: In data downloading mode, to print summary report, select Summary using UP/DN in the data download page. -
Page 16: How To Monitor Battery Charge Level
Click the OK Button. A blinking cursor will now appear on the New Connection (say ABC) Window. Now the data in the memory of the equipment can be downloaded to the PC by pressing UP key. The records will appear on the new connection window. Press the DOWN key if the data from the instrument memory is to be erased. -
Page 17: Instrument Specifications
Instrument Specifications Sr. No. Feature Description Gas sampling Sample draw type Display 20 X 4 Alphanumeric LCD/ OLED Display Flow rate: 500 - 1000 ml/min Inbuilt pump Power: 4.5 V DC, 35 mAH Power supply Inbuilt 7.4 V Li-Ion rechargeable battery Weight 0.57 Kg (1.256 lb) Construction material... -
Page 18: Sensor Specifications
Warranted for one year. NOTE: PH sensors are warranted for ONE year. Annexure 1 Response Gas Name Model Range Resolution time(T 0 – 1000 PPM 1 PPM 60 Secs UNIPHOS-250(PM) Phosphine FumiSense Pro 0 – 2000 PPM 1 PPM 60 Secs... -
Page 19: Maintenance
8. Maintenance DO a regular battery checkup and recharge it fully before use whenever the battery is low. Perform the calibration check once in a month. Calibration check every month will ensure the accuracy of readings throughout the life of the instrument. NEVER allow the unit to be used in direct sunlight. -
Page 20: Troubleshooting
9. Troubleshooting Problem Possible cause Solution to the problem The instrument does not turn ON Low Battery Recharge battery There may be blockage in Pump making abnormal noise the gas sampling tube or Clear blockage in the nozzles... -
Page 21: Calibration Schedule
10. Calibration Schedule Instrument No. : Calibration Gas: Date Standard Gas Instrument Remarks Next Conc. reading Calibration Due Date Note: Calibration of the instrument is recommended on quarterly basis. -
Page 22: Conclusion/Remarks
11. CONCLUSION/REMARKS... -
Page 23: Notes
12. NOTES Inappropriate use, maintenance or servicing may affect the function of the device and thereby seriously compromise the user's life. The device must be used only in compliance with the applicable regulations, otherwise the safe operation of the instrument is not guaranteed. After completion of life cycle of this instrument, dispose it in accordance with federal, state and local environmental control regulations. -
Page 24: Limitation Of Warranty & Liablity
13. Limitation of Warranty and Liability The seller warrants that this product, under normal use and service as described in the operator’s manual shall be free from defects in workmanship and material for a period of twelve (12) months, or the length of time specified in the operator’s manual, from the date of shipment to the customer. - Page 25 (Due to continuing development we reserve the right to Change specifications without prior notice) Marketing Office Manufactured At Uniphos Envirotronic Pvt. Ltd. Uniphos Envirotronic Pvt. Ltd. Readymoney Terrace P. O. Nahuli, Tal. Umbergaon, 167, Dr. Annie Besant Road Dist. Valsad - 396 108, India Worli, Mumbai 400 018, INDIA Tel.: +91-9909994042...
