Abtus PWR-DA06C User's Operation Manual

SPECIFICATIONS
Technical Model: PWR-DA06C
Input 1 x AC-in
Output 2 x AC OUT
6 x DC OUT
Control 1 x 485
1 x RS-232
Output Power DC Output : 6 X 12V DC 5A max
AC Output : Base on AC input supply
Mechanical
Housing Metal enclosure
Product
Dimensions (L x W x H) 200 X 115 X 45 mm
** For detail, updated Command Code and Application Software, please visit and download from www.abtussingapore.com
Connector Type
D-shape male
D-shape female
3.8mm terminal bock
3.8mm 3pin terminal bock
3.8mm 3pin terminal bock
* Specifications are subject to changes without notice.
** For detail and updated RS-232
Command protocol for programming,
please visit and download from
www.abtussingapore.com
Typical Applications
Any professional presentation system
requiring quick and easy disconnect
and reconnection control unit on
mobile.
• Schools (Media Classroom)
• Churches
• Corporate Applications
(Meeting Room)
Eco Energy Saving AC/DC
Power Sequencer
with RS-232/485 controls
Model: PWR-DA06C
PRODUCT DESCRIPTION
The ABtUS PWR-DA06C is a energy saving power sequencer that allows programmable sequencing
delay (On/Off) through RS-232. With it’s unique I/O that features both AC and DC outputs, it can
achieve greater flexibly and is suitable of practically any application. RS-485 and RS-232 control
are also integrated so that the power sequencer could control any external audio video equipment
such as TV displays, projectors or audio system etc. Ideal for rack systems, digital signage and
large venues av.
