Romtech e-CAR User Manual

Digital vehicle wireless security system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
e - CAR Vehicle wireless security system
!
Pirated e-CAR, manufacturer does not A/S for
# 301-1, 161 GEUMGOK-Dong, BUNDANG-Gu,
SUNGNAM-Si, GYUNGGI-Do, 463-805 R.O.KOREA
TEL : 031) 782 – 4758 FAX : 031) 782-4756
WWW.ROMTECH.CO.KR
You do not need to carry your car key when you leave your car!
Just have Smart card, then Your fingertips can control the
car by simple touching
The owner well-advised, the most advanced digital controller
Automatic car door open / closed control.
(Manual control possible)
The owner well-advised, the most advanced digital controller.
Without Smart Card or Password, anybody can NOT control your car.
e-CAR Active RFID System realize accurate identifying & faster control.
Even if without Smart Card, You can open & close the door by inputting
the password.
YOU SHOULD~ !
•You should ask the product warranty letter filled in by the Install Technician(=IT)
•You should learn from the IT how to operate e-CAR enough to be familiar with
•You should be aware of the e-CAR main functions
◈
This product features and design somewhat may change for quality increase
User's Guide
User's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the e-CAR and is the answer not in the manual?

Questions and answers

Summary of Contents for Romtech e-CAR

  • Page 1 •You should ask the product warranty letter filled in by the Install Technician(=IT) # 301-1, 161 GEUMGOK-Dong, BUNDANG-Gu, •You should learn from the IT how to operate e-CAR enough to be familiar with SUNGNAM-Si, GYUNGGI-Do, 463-805 R.O.KOREA •You should be aware of the e-CAR main functions TEL : 031) 782 –...
  • Page 2 • The malfunction caused by the damaged product or the abnormal operation, e-CAR is not responsible for. • e-CAR & the intellectual property rights of this operating book belong to ROMTECH CO., LTD. And, without the written permission of ROMTECH CO., LTD., any type of piracy of all or part of this document is prohibited.
  • Page 3 As the auxiliary safety device, e-CAR guarantees the Auto-Owners (AO) more convenience car management only. But, e-CAR is not responsible civilly & criminally for all of theft and damages caused by AO’s abnormal operation. e-CAR is locked automatically, so You should carry Smart card key always And ready for an emergency, Memorize password or Note it.
  • Page 4 ATTENTION All A / S is supported in principle only to visit yourself to where you bought it or to A/S agency regardless of charge or free. If you do not know identify the serial number of Smart card key, normal A/S is not supported. If you do not know identify the serial number of Smart card key, normal A/S is not supported.

  • Page 5: Table Of Contents

    CONTENTS 1. VEHICLE WIRELESS SECURITY SYSTEM VEHICLE WIRELESS SECURITY SYSTEM 2. THE SPECIFICATIONS OF PRODUCTS AND COMPONENTS PRODUCTS SPECIFICATIONS & FEATURES COMPONENTS & THE NAME OF PARTS COMPONENTS & THE NAME OF PARTS 3. KEY FEATURES AUTOMATIC / MANUAL DOOR ON/OFF SYSTEM START BLOCK SYSTEM TOUCH PASSWORD PAD(PASSWORD DOOR ON/OFF) LED MODULE INPUT / CHANGE...
  • Page 6 1. VECHICLE WIRELESS SECURITUY SYSTEM...

  • Page 7: Vehicle Wireless Security System

    So, if you go together with Smart Card, You don’t need to carry the unhandy remote-controller anymore. Key features like that ……. Carrying the smart card within 2M from your car, e-CAR recognize Your Smart Card ID (password) registered in the main control of your car And then, automatically your car door is open.

  • Page 8: The Specifications Of Products And Components

    2. THE SPECIFICATIONS OF PRODUCTS AND COMPONENTS...

  • Page 9: Products Specifications & Features

    2. THE SPECIFICATIONS OF PRODUCTS AND COMPONENTS 1. PRODUCTS SPECIFICATIONS & FEATURES SMART CARD 2.4GHz band wireless Smart card key Best Navigator with the ability to detect once per second Best Navigator with the ability to detect once per second With a wide range of address specifying, collision rate is under 0.0001%.
  • Page 10 2. THE SPECIFICATIONS OF PRODUCTS AND COMPONENTS 1. PRODUCTS SPECIFICATIONS & FEATURES LED Display board module 2.4GHz band wireless receiver Best Navigator with the ability to detect once per second. Best Navigator with the ability to detect once per second. With a wide range of address specifying, collision rate is under 0.0001%.
  • Page 11 2. THE SPECIFICATIONS OF PRODUCTS AND COMPONENTS 1. PRODUCTS SPECIFICATIONS & FEATURES Touch Module Relay control board This is a substantial module which perform the commands from This is a substantial module which perform the commands from This is used when enter the password the Main control.
  • Page 12 2. THE SPECIFICATIONS OF PRODUCTS AND COMPONENTS 1. PRODUCTS SPECIFICATIONS & FEATURES THE NAME OF PARTS THE NAME OF PARTS Basic components in a bundle LED Display board Smart Card 2pcs LED Module KAIO DECO RELAY BOARD Smart card Lithium cell (3V for Smart Card) 4pcs Install wiring RELAY BOARD User’s Guide...

  • Page 13: Key Features

    3. KEY FEATURES...

  • Page 14: Automatic / Manual Door On/Off System

    Carrying the Smart card, when approaching or leaving your car, the door is automatically open or locked. For your convenience driving, you do not need to carry your car key.……It would be always in the keyhole. How to use e-CAR …… 1. To open the Door Carrying Smart card, approach your car.
  • Page 15 Especially, when leaving your car, even if you do not touch password pad, it is locked automatically for anti-theft. How to use e-CAR …… 1. To open the Door 1. Carrying Smart card, approach your car. (within 2M from your car) 2.

  • Page 16: Start Block System

    ENGINE(START_1) ENGINE(START_2) Fuse e-CAR is connected to the starter of ignition switch(key box) and IPM module, Starting relay and to the Anti-theft relay. When Smart Card is recognized by Main control board, it will control Relay.

  • Page 17: Touch Password Pad(Password Door On/Off)

    3. KEY FEATURES 3. TOUCH PASSWORD PAD(PASSWORD DOOR ON/OFF) You can use 4 to 20-digit password, and after changing it, be sure to remember new password. Consumer is responsible for the Damage caused by leaking password. When busy, if you can not find out Smart card, do not look for it any more. When busy, if you can not find out Smart card, do not look for it any more.

  • Page 18: Led Module Input / Change

    3. KEY FEATURES 4. LED MODULE INPUT / CHANGE LED Module setting order Push RESET button one time. Push SELECT button one time Push COUNT button once ( O blinks on No.1_LED) Push COUNT button to get the desire number ex.) Blank –...

  • Page 19: How To Change Battery

    Be sure to use a genuine cell, and exchange 2 cells together at the same time. No battery capacity indicator added-on Smart card, so if e-CAR does not recognize your Smart card, you need to check the batteries and replace them with new ones...

  • Page 20: Various Kind Of Touch Pad

    3. KEY FEATURES 6. VARIOUS KIND OF TOUCH PAD e-CAR has the Touch Pad platform to reflect Consumers' tastes and needs of individuals ..out of the conventional numerical design. numerical design. Various kind of Touch Pad is available..so, You can choose the suitable design for your car, or for Various kind of Touch Pad is available..so, You can choose the suitable design for your car, or for...

  • Page 21: How To Install

    4. HOW TO INSTALL...

  • Page 22: How To Install

    4. HOW TO INSTALL 1. WIRING DIAGRAM RELAY BOARD DOORCON (6Pin) DOORCON (6Pin) ACTUATOR(OPEN) brown ACTUATOR(CLOSE) +12V blue green yellow BAT(-) Black line +12V black Red line BAT(+) LAMPCON (6Pin) LAMPCON (6Pin) LAMP(LEFT) white LAMP(RIGHT) white ENGINE(START_1) orange ENGINE(START_2) orange BAT(-) Purle line Purple DOOR SWITCH...
  • Page 23 Orange wires (ENGINE) are connected to the each cutting-end of START LINE. • CAUTION – Be sure to open your car door or windows before installing e-CAR, because the door suddenly can be lock by worker or the system failure - It is recommended that the direct installation by experts...
  • Page 24 4. HOW TO INSTALL 2. WIRING CONNECTIONS ENGINE(START LINE) & BAT(+ , - ) LINE Ordinary Power Ordinary Power KEY BOX START BAT(-) Black line LOCK Red line BAT(+) ENGINE(START_1) Orange line ENGINE(START_2) Orange line Starting control module Fuse Starting relay Starting motor Automobile gear connection...
  • Page 25 4. HOW TO INSTALL 2. WIRING CONNECTIONS LAMP (Direction Lamp) Automobile gear connection Automobile gear connection LAMP Relay LAMP Relay LAMP(RIGHT) White line LAMP(LEFT) White line Left Lamp Right Lamp Direction indicator lamp...
  • Page 26 4. HOW TO INSTALL 2. WIRING CONNECTIONS • DOOR SWITCH is connected to dashboard or the open / close mark ACTUATOR (ON/OFF) of Door Lamp, it recognizes the contact of door open & close. Ordinary Power Automobile gear connection Door control module Door lock output Lock Un Lock...

  • Page 27: Appendix

    5. APPENDIX...

  • Page 28: Product Specification

    5. APPENDIX PRODUCT SPECIFICATION classification specification remark Mechanical Model Name e – CAR Vehicle wireless security system Specification Smart card 6(D) X 71(W) X 46(H)mm LED display board LED display board 13(D)Top, 38(D)Bottom X 38(W) X 170(H)mm 13(D)Top, 38(D)Bottom X 38(W) X 170(H)mm External Size Caps touch board 0.5(D) X 81(W) X 30(H)mm...
  • Page 29 5. APPENDIX WARRANTY ROMTECH CO., LTD. A/S as this WARRNTY following the examination of the victim compensation of consumers. About A/S When the product malfunctions, please contact where you bought it or install technician carrying WARRANTY. Within warranty period, Free A/S will be supported only for the malfunction of the product itself...

  • Page 30: Customer Management Card

    5. APPENDIX CUSTOMER MANAGEMENT CARD Model Production Name Date Product Add-on Install Date items Brand & Production Model Date Address Customer Name Telephone Purchase Birthday price Agency Telephone Name Install Technician Technician Name President Name Remark...
