Summary of Contents for Intermec Microbar Series
- Page 1 Installation Instructions P/N 962-000-005 Revision A January 2000 5055 Microbar P/N 962-000-005 Revision A *962000005*...
- Page 2 Introduction These instructions show you how to install the Microbar radio device onto the 5055 Data Collection PC. A right angle adapter bracket helps make this an easy installation for you to perform. The adapter bracket can be mounted on either side of the computer. NOTE: Before you begin this installation, you MUST: Perform a standard Windows shutdown...
- Page 3 Attach the Microbar Unit Follow the instructions below to attach the Microbar unit to the 5055 computer. Latch Tang Step 3 Align the back side of the Micro bar unit to the mounting clip. Latch Mounting Slide the unit upward until the Recess Clip latch tang snaps into the latch...
- Page 4 Connect the Microbar Unit Follow the instructions below to connect the Microbar unit to the 5055 Computer. PS/2 Cable (either P/N) Step 5 Align the cable connector to the corresponding connection on the bottom of the Microbar unit. Thumb Use the thumbscrews to tighten Screws the d sub connector to ensure it is firmly engaged.
- Page 5 Enabling the Scanner You have successfully installed and connected the Microbar radio device to the 5055 Data Collection PC. You must power up the computer and make several settings before the wireless scanner and Microbar radio device can actually talk" to the computer. Step 7 Computer Setup (a) Reconnect the external power cable to the computer.
