Nylex 701078 Owner's Manual

Install a new hose on the reel: Continued
2. Replace the original cable tie just back from
the barb with a new one as this secures the hose
attachment from unnecessary stress during full
extension. Fig.15
3. Carefully let the hose rewind over the drum,
helping if necessary by gently pushing down on
the foot pedal. Fig.16
4. When the new hose is wound over the drum,
remove the hose-stop ball from the old hose and
install on the new hose approximately 1m from
the end of the hose Fig.17.
5. Reattach a hose connector and trigger gun.
(Fig.18) – the installation is now complete!
Model
Hose Length
Type of Hose
Working Pressure
I.D of Hose
Material of Outer Casing
Size of Inlet and Outlet
Cyclone Tools Pty Ltd guarantees the Hose Reel and Hose Fittings
for 2 years and the Hose for 12 years from the date of purchase.
If the relevant product proves defective as to materials or workmanship within that period, Cyclone
Tools Pty Ltd will, at its option either replace or refund the purchase price for the relevant product.
In the event of such a defect, the product should be returned to the place of purchase, together with
proof of purchase, for replacement or refund. Any handling and transportation and other expenses
incurred in claiming under this warranty) are not covered by this warranty and will not be borne by
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are
entitled to a replacement or refund for a major failure and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if goods fail to
be of acceptable quality and the failure does not amount to a major failure. The benefits given by this
guarantee are in addition to other rights and remedies which may be available to the consumer under
Made in China to strict Nylex quality standards
Cyclone Tools Pty Ltd317 Abbotts Road, P.O. Box 4339 Dandenong South, Victoria 3175, Australia.
The Nylex brand is licensed to Cyclone Tools Pty Ltd by Wet Technologies Pty Ltd.
Fig.15
Fig.17
SPECIFICATIONS
701078
30m
PVC
150psi
12mm
PP
12mm
GUARANTEE
Cyclone Tools Pty Ltd.
.
www.cyclone.com.au
Fig.16
Fig.18
FOOT PEDAL HOSE REEL
Owner's Manual - 701078
Effortless Foot Pedal Retraction
